• Press <2> to select the Modifier Type Parameter.
• Using the Data wheel to scroll through the Modifier types: MIDI CC number 0 -127 and CHP (Channel
Pressure or Aftertouch), L - 1 (LFO1), L - 2 (LFO2), or DYN (Dynamic).
NOTE: Make sure you store any changes you don't want to lose. See pg. 13 for more information
SETTING UP AN LFO OR DYNAMIC MODIFIER
To link an LFO to a parameter, do the following:
• Press <FX Edit> until you reach the modifiers edit mode. The modifiers icon begins to flash in the bottom
right corner of the screen.
• Use the <NEXT PAGE> and <PREV PAGE> keys to scroll to Page 9. The display reads:
• Press <1> and use the Data wheel to select which LFO you want to adjust.
• Press <2> and use the Data wheel to change the selected LFO's waveform. You can select SINe, TRIangle,
SPecial1, SPecial2 or SPecial3. Refer to pg. 19 for Waveform information.
• Press <3> and use the Data wheel to adjust the speed of the LFO cycle.
The assigned Parameter now follows the modulating waveform of the LFO you selected. See pg. 19 for waveform
diagrams.
To link a Dynamic Modifier to a parameter, do the following:
• Press <FX Edit> until you reach the modifiers edit mode. The modifiers icon begins to flash in the bottom
right corner of the screen.
• To adjust the settings of the Dynamic Modifier, use the <NEXT PAGE> and <PREV PAGE> keys to scroll to
Page 10. The display reads:
• Press <2> and use the Data wheel to adjust LoThrs. This control sets the threshold above which dynamic
modification of the Parameter begins.
• Press <3> and use the Data wheel to adjust HiThrs. The HiThrs control sets the point at which maximum
Parameter modification occurs.
• Press <4> and use the Data wheel to select which input (1 - 4) you want the modifier to "listen" to, or follow.
