SETTING UP AN LFO OR DYNAMIC MODIFIER
• Use the Data wheel to scroll to the Parameter you want assigned
to Modifier link #1. As you scroll, the MIN and MAX values for
each Parameter show in the display.
Note: The MUTE and THRU effect types do not have any
Parameters to connect to, so they will not appear in the
parameter list.
• Press <3> to select the Minimum Value Parameter.
• Use the Data wheel to select the minimum Parameter value you
want when the controller is in the minimum position. These val-
ues vary because different Parameters have different value
units, such as milliseconds or percent.
• Press <4> to select the Maximum Value Parameter.
• Use the Data wheel to select the maximum Parameter value you
want when the controller is in the maximum position.
• Press <2> to select the Modifier Type Parameter.
• Using the Data wheel to scroll through the Modifier types. Select
a MIDI CC number 0 -127 and CHP (Channel Pressure or
Aftertouch), L - 1 (LFO1), L - 2 (LFO2), or DYN (Dynamic).
Note: Make sure you store the settings after you made any
changes. See pg. 16 for more information.
To setup an LFO, do the following:
• Press <FX Edit> until you see "modifiers" flashing in the bottom
right corner of the screen.
• Use the <NEXT PAGE> and <PREV PAGE> keys to scroll to
Page 9. The display reads:
1
LFO WvFrm
C C C C
L-1 5in
%kHz %kHz
1 2
m Sec m Sec
CHANGED CHANGED
MIDI CLIP CLIP
LEVEL 1
FACTORY PRG - CHANGED
S-DISC ™
CLIP CLIP
USER PRG - CHANGED P ROCESSING
LEVEL 2
CLIP CLIP
FX EDIT PAGE UTILITY PAGE
LEVEL 3
1 2 3 4 5 6 7 8 9 10 CLIP CLIP
LEVEL 4
• Press <1> and use the Data wheel to select which LFO you
want to adjust.
• Press <2> and use the Data wheel to change the selected
LFO's waveform. You can select SINe, TRIangle, SPecial1,
SPecial2 or SPecial3. Refer to pg. 23 for Waveform information.
Speed
C C C C
¡00 100
%kHz %kHz
3 4
m Sec m Sec
CHANGED
IN 1 OUT 1
IN 2 OUT 2
IN 3 OUT 3
IN 4 OUT 4
DIGITAL CLIP DIGITAL CLIP MODIFIERS
