Stereo Operation

For stereo operation connect the guitar to the Input of the RP255. Connect one cable to the
RP255's Left (Mono) output, and another cable to the RP255's Right output. Connect one cable
to the input of one amplifier, channel of a mixer, or power amp. Connect the second cable to a
second amplifier, second channel of a mixer, or power amp. If connecting to a mixing console, set
the pan controls of the mixer channels hard left and right in order to retain stereo separation. If
connecting to a mixer, set the Amp/Mixer switch to Mixer. If connecting to two amplifiers, set
the Amp/Mixer switch to Amp.
Stereo Amp Setup
Guitar Amp Input/Effect Returns
Outputs
Amp/Mixer
switch set to
Amp.
Input
NOTE: When using a guitar amp,
it may be best to connect the gui-
tar to the Input of the RP255 and
the Output of the RP255 to the
effect return of the amplifier.
13
