Summary of Contents for Redliro JK43
-
Page 2: Table Of Contents
Content 1. CAUTION ..................... 1 2. SAFETY AND NOTIICE ................1 3. CAUTION DURING USE ................. 2 4. TECHNICAL SPECIFICATION ..............3 5. PRODUCT SPARE PARTS ............... 3 6. PRODUCTS MAIN PARTS ..............4 7. ASSEMBLY ...................1 8. CONSOLE INSTRUCTON ...............2 9. -
Page 3: Caution
1. CAUTION To avoid any hurts, please read this manual carefully before using. DO NOT try to install the treadmill while the running belt is moving. DO NOT operate the treadmill if it is damaged or does not work normally. DO NOT operate the treadmill in or around water / sources of heat &... -
Page 4: Caution During Use
furniture. Check the unit before each use and verify that all fasteners are secure. Always maintain the treadmill in good working condition. After using the silicone oil, it must be stored out of the reach of children to avoid serious consequences caused by accidental ingestion. -
Page 5: Technical Specification
4 . TECHNICAL SPECIFICATION Product name Treadmill Voltage 110V Frequency 50/60Hz Speed 0.5-7.5MPH 5. PRODUCT SPARE PARTS Serial NO. Part Name unit Curved washer Screw M8*16 Flat washer Screw M8*40 Safety lock L type wrench Open end wrench Lubricant oil Fender Control panel Treadmill... -
Page 6: Products Main Parts
6. PRODUCTS MAIN PARTS Safety Key Console Heart lnductor Upright Tube Motor Cover Side Rail Running Belt Wheel End Cap... -
Page 7: Assembly
7 . ASSEMBLY Step1 : Remove the premounting screws at the top of the Upright Tube, put the control panel(No.10) on the rack near the top of the Upright Tube, Pick up the lever slightly and place it on the control panel(No.10). Then, the left and right Upright Tubes and the control panel(No.10) are fixed together with the removed M6*25 cylindrical head hex screws and M6 locknut... - Page 8 Step2 : Get the Upright Tubes in position , With half round head hex socket screw M8*40 (No.4), M8*16(No.2) and Flat washer(No.3) to the vertical rod with the bottom frame fixed; Connect the connecting wire at the top of the right side of the Upright Tube, And insert the connector into the Upright tube.
- Page 9 Step3 : Press the control panel handrail to the horizontal position , Fix the control panel to the Upright Tubes with HEX socket screws M8*16(No.2)and Flat washer(No.3) (Please check the connection line before the armrest of the pressure instrument, be careful to clip the connection line);...
- Page 10 Step4: Place the safety lock and finish the assembly.
-
Page 11: Console Instructon
8. CONSOLE INSTRUCTON 1. Press "START" key, the machine will start at 0.5 MHP a er 3 seconds. 2. Press"+" key for speed up and "-" key for low down. The fastest speed is 7.5 MHP and lowest is 0.5 MHP. 3. -
Page 12: Folding Up And Setting Down
9.FOLDING UP AND SETTING DOWN NOTE: Ensure the Power Switch is in the 'OFF' position and the power cord is unplugged from the electrical outlet. FOLDING UP Holding the rear end of deck directly and then lift the deck up until the Cylinder(A) 'pops' down into the locked position. -
Page 13: Usage Of Silicone Oil
If the running surface becomes slipping, tighten bolts on both ends 1/2 turn clockwise (see fig3) with Allen key. Repeat if necessary until the belt is properly adjusted. Note: You can search “REDLIRO” in YouTube to see the video for how to adjust the belt. -
Page 14: Trouble Shooting
1 2 . TROUBLE SHOOTING...
