CONTENT Thank you for purchasing our product. If you have questions, need product information or parts replacement, please contact our customer service department to obtain a complete service experience. Please email us at hi@mixdollar.com with your order number. Service Response Safety Information Time Product Structure...
hi@mixdollar.com hi@mixdollar.com SAFETY INFORMATION PRODUCT SPECIFICATIONS Product configuration TO REDUCE THE RISK OF INJURY, PLEASE READ INSTRUCTIONS IN FULL BEFORE USE. 110 V 0.5-4.0 mph Speed range 350 lbs 48x26.77x9.25 inches • lntended for at-home use only. Please only use in an area with 3 - 6 feet of free space around your device 43x22.5x7.95 inches Do not operate your device on a carpet more than 0.5 inches thick or near water.
hi@mixdollar.com hi@mixdollar.com PACKAGE LIST PRODUCT STRUCTURE NOTE: THE RUNNING BELT IS MADE OF HEAD AND TAIL SPLICING, THERE ARE SEAM MARKS, IT IS NORMAL PROCESS PHENOMENON, AND DOES NOT AFFECT THE NORMAL USE OF THE TREADMILL. Motor Upper Cover Foot Edge Strip Running Belt Motor Lower Cover Rear Shield(Left)
Page 5
hi@mixdollar.com hi@mixdollar.com INTRODUCTION TO DISPLAY SPEED In preset mode, the speed will be displayed corresponding to the preset programs you have selected. TIME DISTANCE In custom mode, the distance will be reduced from the inputted data (setting range: 1~99.9 miles) to 0. When CALORIES the display is 0, your device will slowly stop and enter the standby state.
Page 6
hi@mixdollar.com hi@mixdollar.com REMOTE CONTROL INSTRUCTIONS FUNCTION OF THE REMOTE CONTROL Start/Stop button: Note: In order to utilize the remote control, it is necessary to insert your own three AAA batteries Press button in standby mode and the treadmill will start after 3 seconds. The default speed is 0.5 mph. and create a new pairing.
hi@mixdollar.com hi@mixdollar.com THE BATTERY OF REMOTE CONTROL The 12 preset programs have the following speeds: Battery Installation SET TIME/20=RUNNING TIME FOR EACH SECTION TIME Remove the cover and assemble three AAA batteries for first-time use. PROGRAMA SPEED SPEED SPEED SPEED SPEED Battery Replacement SPEED...
Page 8
hi@mixdollar.com hi@mixdollar.com INSTRUCTIONS FOR USING THE TREADMILL Time setting: In standby mode, press the P/M button on the remote control and adjust time by pressing the +/- buttons to adjust its duration in 1 minute increments. Hold for over 0.5 seconds for timer to roll quickly. The selectable time range is 5-99 minutes.
Page 9
hi@mixdollar.com hi@mixdollar.com Calorie setting: HOW TO USE THE TREADMILL IN PRESET MODE In standby mode, press the P/M button on the remote control 3 times, and then adjust the number of calories 1. How to choose a program you wish to burn by pressing the +/- buttons. Adjustments made in units of 10 calories. Hold for more than In standby mode, press the P/M button on the remote control 4 times to select 12 preset programs from P1 to P12.
hi@mixdollar.com hi@mixdollar.com PRODUCT MAINTENANCE ROUTINE MAINTENANCE Use of Silicone Lubricant REGULAR MAINTENANCE IS IMPORTANT FOR YOUR SAFETY AND TO EXTEND THE LIFE OF YOUR PRODUCT. PLEASE CHECK AND TIGHTEN ALL PARTS BEFORE YOUR FIRST USE AND The treadmill has been lubricated prior to shipment. Friction between the running belt and the running board REPLACE WORN PARTS OVER TIME AS NEEDED.
Page 11
hi@mixdollar.com hi@mixdollar.com TROUBLESHOOTING AND HANDLING Running Belt is Off Center Note: Unplug the treadmill. Running belt shifted to the left Use the L-Wrench wrench to turn the left rear roller bolt clockwise 1/4 of a turn to tighten the running belt. Running belt shifted to the right IF YOU ARE EXPERIENCING ISSUES THAT YOU CAN NOT FIND A SOLUTION Use the L-Wrench to turn the right rear roller bolt clockwise 1/4 of a turn to tighten the running belt.
Page 12
hi@mixdollar.com hi@mixdollar.com Issue 6: The treadmill shakes or has poor stability. Issue 12: Fault code on display. Check the treadmill is placed on a level surface. If the problem is not solved, please contact customer service. E05: Over current protection. (1) Please confirm whether your weight is within the load bearing range of the product.
hi@mixdollar.com hi@mixdollar.com WORKOUT GUIDE WARRANTY Manufacturer’s Limited Warranty This product is under warranty by Mixdollar covering manufacturing defects in material and workmanship. THE CORRECT FORM FOR SEVERAL BASIC STRETCHES IS SHOWN AT THE RIGHT. MOVE SLOWLY AS YOU STRETCH — NEVER BOUNCE. Warranty period of parts All components are under warranty for 1 year.
Page 14
Need help? We've got you covered 24/7! Reach out anytime for friendly assistance with any questions or concerns. JK03W-T Mixdollar Find Turtorial on YouTube...
