- Page 1 REDLIRO TREADMILL JK1608P MODEL PRODUCT USE GUIDE...
-
Page 2: Table Of Contents
SERVICE CONTENT Thank you for purchasing this Redliro product. Questions, problems, missing parts? Before returning to your retailer, contact our Customer Service Department to receive more complete service, please email your order number to: service@redliro.com Response Service Time Safety Information... -
Page 3: Safety Information
SAFETY INFORMATION PRODUCT SPECIFICATIONS Product configuration Technical parameters TO REDUCE THE RISK OF INJURY, PLEASE READ INSTRUCTIONS IN FULL BEFORE USE. Input voltage 110V Speed range 0.5-4 mph Maximum load bearing 300 lbs Package size 54.3 x 24.6 x 6.5 inches Assembly size 51 x 20.5 x 6 inches... -
Page 4: Package List
PACKAGE LIST PRODUCT STRUCTURE NOTE: THE RUNNING BELT IS MADE OF HEAD AND TAIL SPLICING, THERE ARE SEAM MARKS, IT IS NORMAL PROCESS PHENOMENON, AND DOES NOT AFFECT THE NORMAL USE OF THE TREADMILL. Motor Upper Cover Display Panel... -
Page 5: Introduction To Display
INTRODUCTION TO DISPLAY REMOTE CONTROL INSTRUCTIONS NOTE: TO USE THE REMOTE CONTROL, YOU MUST FIRST ESTABLISH A NEW CONNECTION Increase Speed Mode The “TIME” window has two display modes. • Standard mode counts from 00:00 ~ 99:00 and resets to 0 when it reaches 99:00. - Page 6 FUNCTION OF THE REMOTE CONTROL The 12 preset programs have the following speeds: Start/Stop button: SET TIME/20=RUNNING TIME FOR EACH SECTION Press Start/Stop button in standby mode and the treadmill will start after 3 seconds. The default speed is 0.5...
-
Page 7: Battery Replacement
BATTERY REPLACEMENT INSTRUCTIONS FOR USING THE TREADMILL Step 1: PREPARATION BEFORE USE: Push back to remove the cover and install the battery. 1. Plug in the power cord 2. Establish the connection between the treadmill and the remote control 3. - Page 8 HOW TO USE THE TREADMILL IN PRESET MODE Time setting: In standby mode, press the M button on remote control and adjust time by pressing the +/- buttons to adjust 1. How to choose a program its duration in 1 minute increments. Hold for over 0.5 seconds for timer to roll quickly. The selectable time In standby mode, you can select from 12 preset automatic programs (P1-P12) by pressing the P button on range is 5-99 minutes.
-
Page 9: Product Maintenance
PRODUCT MAINTENANCE 3. How to turn on the treadmill Once you've set up your desired program, press the Start/Stop button on the remote control and the running belt will begin moving at 0.5mph in 3 seconds 4. How to adjust the treadmill speed To change the speed of the running belt, you can press the +/- buttons on the remote control. -
Page 10: Routine Maintenance
The running belt may deviate from its ideal position over time, which can be caused by the following. Note: Search “REDLIRO” on YouTube to find videos on how to adjust the running belt. 1. The main body is not in kept in a stable position. -
Page 11: Troubleshooting And Handling
TROUBLESHOOTING AND HANDLING Issue 4: "----" is displayed and the treadmill doesn’t work. • If the power indicator of the lower control board is on, please re-insert the connecting wire between the lower control board and the display board when the power is off (the glue on the terminal can be removed by rubbing with an alcohol soaked cotton swab and leaving for 3 minutes before scraping it off.) Check whether... - Page 12 Issue 12: Abnormal noise from the running board. (2) Reset the machine. If the problem persists, please contact customer service to replace the communication • Please check whether the running board is damaged line. • Please turn the treadmill upside down, and observe whether there is contact between the bottom running board and the square tube on both sides of the fixed metal frame.
-
Page 13: Workout Guide
6. Improper Operation, modification, handling, storage, misuse or neglect of the product. Stretched parts: Hamstrings, lower back and groin. 7. Redliro will, at its sole discretion, repair or replace, any part that proves to be defective in normal 3. Calf/ tendon stretch household use. - Page 14 If you have any problem, please feel free contact us, within 24 hours we will replay ASAP JK1608P Find Assembly Tutorial on Redliro YouTube Email: service@redliro.com Company: MIXDOLLAR INC Address: 4975 Miller ST, Wheat Ridge CO, 80033, United States @Redliro...
