01-217
cooler/ rod holder rack
(universal)
installation instructions
included:
Cooler/Rod Holder Rack
Hardware Pack
Mounting Bracket
1
Note: Cooler/Rod Holder rack will fit on any 2" trailer hitch receiver.
*2" Hitch Receiver not included with this kit.
Insert Mounting Bracket into hitch
receiver and attach using supplied
pin and clip.
Cooler/Rod Holder Rack
tools needed:
17mm Socket
17mm Wrench
Mounting Bracket
2
Tool Needed: 17mm Socket & Wrench
Attach Cooler/Rod Holder Rack to
the Mounting Bracket using the
supplied 10mm hardware. Once all
4 bolts are in place then tighten.
Advertisement
Related Manuals for GTW 01-217
Summary of Contents for GTW 01-217
- Page 1 01-217 cooler/ rod holder rack (universal) installation instructions included: tools needed: Cooler/Rod Holder Rack 17mm Socket Hardware Pack 17mm Wrench Mounting Bracket Mounting Bracket Cooler/Rod Holder Rack Note: Cooler/Rod Holder rack will fit on any 2” trailer hitch receiver. *2” Hitch Receiver not included with this kit.
- Page 2 Hardware Pack 4- - 10mm x 70mm Hex Head Bolts 8- - 10mm Flat Washers 4- - 10mm Nylock Nuts Installation Complete...
