6 Compaq StorageWorks Model 4300 Family Ultra3 LVD Disk Enclosure
Figure 4. Single-Bus MA8000/EMA12000 Storage System
5. Connect the AC power cords from the appropriate rack AC outlets to the controller and
disk enclosures.
8
7
SCSI Bus 1 Cable SCSI Bus 2 Cable
SCSI Bus 3 Cable SCSI Bus 4 Cable
SCSI Bus 5 Cable SCSI Bus 6 Cable
AC Power Inputs Fibre Channel Ports
6
5
4
1
2
3
CXO7382A
