Compaq 4354R - StorageWorks Enclosure Storage Addendum page 11

Bay 1 2 3
SCSI ID 00 01 02
DISK ID
Bay 1 2 3
SCSI ID 00 01 02
DISK ID
Bay 1 2 3
SCSI ID 00 01 02
DISK ID
Figure 8. PTL addressing in a dual-bus configuration, using three Model 4354R disk enclosures
Addendum for Use with the MA8000/EMA12000 Storage System
Model 4354R Disk Enclosure Shelf 1 (dual-bus)
SCSI Bus A
4 5 6 7
03 04 05 08
Model 4354R Disk Enclosure Shelf 2 (dual-bus)
SCSI Bus A
4 5 6 7
03 04 05 08
Model 4354R Disk Enclosure Shelf 3 (dual-bus)
SCSI Bus A
4 5 6 7
03 04 05 08
SCSI Bus B
8 9 10 11
00 01 02 03
SCSI Bus B
8 9 10 11
00 01 02 03
SCSI Bus B
8 9 10 11
00 01 02 03
11
12 13 14
04 05 08
12 13 14
04 05 08
12 13 14
04 05 08
