18
Compaq StorageWorks Model 4300 Family Ultra3 LVD Disk Enclosure
Example Storage Map - Model 4354R Disk Enclosure
Figure 12 shows an example of three Model 4354R disk enclosures (dual-bus).
Unit D100 is a 6-member RAID 3/5 storageset named R1. R1 consists of Disk10000,
Disk20000, Disk30000, Disk 40000, Disk50000, and Disk60000.
Unit D101is a 6-member RAID 3/5 storageset named R2. R2 consists of Disk10100,
Disk20100, Disk30100, Disk 40100, Disk50100, and Disk60100.
Unit D102 is a 2-member striped mirrorset named S1. S1 consists of M1 and M2:
M1 is a 2-member mirrorset consisting of Disk10200 and Disk20200.
M2 is a 2-member mirrorset consisting of Disk30200 and Disk40200.
Unit D103 is a 2-member mirrorset named M3. M3 consists of Disk50200 and
Disk60200.
Unit D104 is a 2-member striped mirrorset named S2. S2 consists of M3 and M4:
M3 is a 2-member mirrorset consisting of Disk10300 and Disk20300.
M4 is a 2-member mirrorset consisting of Disk30300 and Disk40300.
Unit D105 is a 2-member stripeset named S3. S3 consists of Disk50300 and
Disk60300.
Unit D1 is 4-member stripeset named S4. S4 consists of Disk10400, Disk20400,
Disk30400, and Disk40400.
Unit D2 is a 2-member mirrorset named M5. M5 consists of Disk50400 and
Disk60400.
Unit D3 is a 2-member striped mirrorset named S5. S5 consists of M6 and M7:
M6 is a 3-member mirrorset consisting of Disk10500, Disk20500, and Disk30500.
M7 is a 2-member mirrorset consisting of Disk40500 and Disk50500.
Unit D4 is a single (JBOD) disk named Disk60500.
Unit D5 is a 4-member RAID 3/5 storageset named R3. R3 consists of Disk10800,
Disk20800, Disk30800, Disk and 40800.
Disk50800 and Disk60800 are spareset members.
