Disk Enclosures
The Model 4300 family of Ultra3 SCSI disk enclosures is made up of four models:
Model 4310R disk enclosure - 10 drive bays, single-bus I/O module.
Model 4350R disk enclosure - 10 drive bays, dual-bus I/O module.
Figure 1 shows the drive enclosure bay numbering for Models 4310R and 4350R.
1
2
Figure 1. Model 4310R and 4350R 10-Drive Enclosure Bay Numbering
Model 4314R disk enclosure - 14 drive bays, single-bus I/O module.
Model 4354R disk enclosure - 14 drive bays, dual-bus I/O module.
Figure 2 shows the drive enclosure bay numbering for Models 4314R and 4354R.
1
2
3
Figure 2. Model 4314R and 4354R 14-Drive Enclosure Bay Numbering
Addendum for Use with the MA8000/EMA12000 Storage System
3
4
5
6
7
8
9
4
5
6
7
8
9
1 0 1 1
1 2 1 3
1 4
1 0
CXO7381A
CXO7380A
3
