Wali CGRP-B Installation Manual

INSTALLATION MANUAL
Reinforcement Plate
CGRP-B
(05210403)
Supplied Parts List
Plate Plate
A (x1) B (x1)
Option A
C-Clamp Installation
1
Tear off the protect paper and attach Anti-Skid Pads C & D to the C
Plates A & B as image shown. A B
A
C
Option B
Grommet Base Installation
1
Please check the Grommet mounting hole position on your desk.
www.walielectric.com
support@walielectric.com
1-844-SATTLER (18447288537)
Anti-skid Pad Anti-skid Pad
C (x1) D (x1)
2
D Place the Plates A & B on and under the desktop. Please make sure the A B
anti-skid pads are fully attached to the desk.
D
A
B
2
Tear off the protect paper and attach Anti-Skid Pads C & D to
the Plates A & B as image shown. A B
B
D
WARNING
！
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may
cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect
assembly or inappropriate use.
TIPOVER WARNING
！
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER:
● NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF MONITOR OR STAND.
● USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL.
USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIP OVER.
SMALL PARTS- NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
Product Dimension
10.63"
0.67"
3
B
3
Place the Plates A & B on and under the desktop. Please make sure
C D A B
the anti-skid pads are fully attached to the desk.
C
B
A
6.02"
9.49"
0.43"
Secure the Clamp to the Desktop with Plates A & B . A B
B
4
Insert the hand knob through the center hole of Plates A & B and
desk hole, rotate the hand knob clockwise to fasten for stability.
A
5.5"
0.43"
A
A B
B
A
