Summary of Contents for Grandhall GT3211LNG

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Grand Hall GT3211LNG Owner's Manual Shop genuine replacement parts for Grand Hall GT3211LNG Find Your Grand Hall Grill Parts - Select From 203 Models -------- Manual continues below --------...

  • Page 2: Primary Safety Warnings

    Replacement of Damaged or Missing parts properly assembled, installed and maintained. Ÿ visit www.grandhall.com or call: Use your grill at least 3 feet away from any wall or surface. Use your grill at least 3 feet 1-877-934-7455...

  • Page 3: Table Of Contents

    Table of Contents WARNING Primary Safety Warnings......1-3 Pre-Assembly Instructions........3 Do not store or use gasoline or other Part Diagrams and Lists......4-9 flammable liquids or vapors in the Assembly Instructions.........10-19 vicinity of this or any other appli- Use & Care Instructions: ances.

  • Page 4: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety PRE-ASSEMBLY CAUTION Read and perform the following pre-assembly instruc- tions: Failure to comply with these instructions may result Tools Required for Assembly in a hazardous situation which, if not avoided, may • protective work gloves result in injury.

  • Page 5: Part Description

    Hardware Parts List for Model GT3211LLP PART # PART DESCRIPTION QTY PURPOSE OF PART S112G0408A Phillips Head Screw 1/4" x 1/2" Install Grill Bowl S112G0406A Phillips Head Screw 1/4" x 3/8" Install Bowl Support Bracket, Left S112G0406A Phillips Head Screw 1/4" x 3/8" Install Bowl Support Bracket, Right S112G0406A Phillips Head Screw 1/4"...
  • Page 6 Hardware Parts List for Model GT3211LNG PART # PART DESCRIPTION QTY PURPOSE OF PART S112G0408A Phillips Head Screw 1/4" x 1/2" Install Grill Bowl S112G0406A Phillips Head Screw 1/4" x 3/8" Install Bowl Support Bracket, Left S112G0406A Phillips Head Screw 1/4" x 3/8"...
  • Page 7 Countersunk Flat Head Screw W rench 3/16"x1/4" Qty. 1 Qty. 4 Part # P05515021G Part # S142G0304A Hardware Diagram for Models GT3211LNG Flange Nut 3/16" Phillips Head Screw Phillips Head Screw 1/4"x1/2" Qty. 30 3/16"x3/8" Qty. 12 Part # S342G0306A Part # S112G0408A Qty.
  • Page 8 Parts Diagram for Models GT3211LLP & GT3211LNG 74(LP Only) 77 ( LP Only) 25(LP only) 71(NG only) 64(LP only)
  • Page 9 Parts List for Models GT3211LLP & GT3211LNG DESCRIPTION PART# Lid Assembly P0014742E4 Temperature Gauge P00601471A Lid Handle P00213038M Lid Handle Bracket, Left P00307061E Lid Handle Bracket, Right P00308061E Protective Pad P05518002 I Bowl Panel, Left P007611564 Bowl Panel, Right P007621464...
  • Page 10 Parts List for Models GT3211LLP & GT3211LNG DESCRIPTION PART# Side Shelf, Left P01102067D Left Panel, Left Cabinet P07605040B Storage Shelf,Left Cabinet P01001097D Rear Panel, Left Cabinet P07702126B Level Adjuster P05322004A Front Bracket, Left Cabinet P03301068D Door Hinge Bracket P03313049D Door Assem bly, Left...

  • Page 11: Assembly Instructions

    Assembly Instructions for GT3211LLP/NG CAUTION : To assemble this grill, you should obtain assistance from another person when handling some of the larger, heavier pieces. Install Left Cabinet Right and Left Panel Open carton and remove all packaging materials. Install the Right Panel onto the Rear Panel using 3 Phillips Head Screws 3/16"x 3/8" and tighten securely using 3 Flange Nuts 3/16".
  • Page 12 Install Level Adjusters and Door Hinge Bracket onto Left Cabinet Install Level Adjusters onto the bottom of the Left Cabinet and tighten securely by hand. Install Door Hinge Bracket onto the Bottom Shelf using 2 Countersunk Flat Head Screws 3/16"x1/4" and tighten securely.
  • Page 13 Install Front Bracket, Bowl Support Bracket and Left Side Shelf onto Left Cabinet Install Front Bracket between Left and Right Panel using 2 Phillips Head Screws 3/16"x3/8" and tighten securely using 2 Flange Nuts 3/16". Install Bowl Support Bracket, Left onto the Right Panel using 3 Phillips Head Screws 1/4"x3/8" and tighten securely.
  • Page 14 Bottom Shelf with Fuel (Only for GT3211LLP) Gauge Set (Only for GT3211LNG) Bottom Shelf Install Level Adjusters, Door Hinge Bracket and Storage Shelf onto Right Cabinet Install Level Adjusters onto the bottom of the Right Cabinet and tighten securely by Hand.
  • Page 15 Install Front Bracket, Bowl Support Bracket and Battery Box Bracket onto Right Cabinet Install Front Bracket between the Left and Right Panels using 2 Phillips Head Screws 3/16"x3/8" and tighten securely using 2 Flange Nuts 3/16". Install Battery Box Bracket onto the Left Panel using 2 Phillips Head Screws 3/16'"x3/8" and tighten securely using 2 Flange Nuts 3/16".
  • Page 16 Install Grill Bowl Remove all componets from the Grill Bowl. Install 4 Phillips Head Screws 1/4"x1/2" to the bottom of the Grill Bowl. Tighten the Screws only half way. With the help of your assistant, lift and position the Grill Bowl into the holes on the Bowl Support Brackets, then slide the Grill Bowl to front (as shown in Fig.1) and tighten all screws.
  • Page 17 Install Doors Place the Door Assembly Left Upper Hinge into the Door Bracket Left/Upper. Press the spring lever mechanism and Position the Door into the Door Bracket Left/Lower. Release the spring lever to lock the Door into the Door Lower Bracket. Repeat steps for installing the Door Assembly Right.
  • Page 18 Install NG Regulator into the Right Cabinet(Only for GT3211LNG) Install the NG Regulator into the Right Cabinet Panel using 2 Phillips Head Screws 3/16"x1/4" and tighten securely. See Fig. 1. Phillips Head Screw 3/16"x1/4" Qty. 2 Part # S112G0304A Fig.1...
  • Page 19 Fig.2 17-2 Install Batteries and Connect Electric Wires(Only for GT3211LNG) Open the cap of the Battery Box and put 2 AA batteries inside. Make sure the "+" and "-" ends are placed correctly as shown. Close the cap and then Put the Battery Box into the Battery Box Bracket.(see Fig.4) Remove the Grease Tray Bracket.
  • Page 20 Install Cooking Components and Hot Plate Install Ignitor Battery Place Cooking Grids on bowl ledge. see Fig.1 Remove Ignitor Cap from Control Panel. Place the Secondary Cooking Rack into the Place supplied AA battery into the Ignitor slots on Grill Bowl Rear Panel. see Fig.2 Slot with positive pole facing you.

  • Page 21: Use & Care Instructions

    USE AND CARE INSTRUCTIONS Use of alcohol, prescription or non-prescription drugs CORRECT LP GAS TANK USE can impair your ability to properly assemble and LP Gas grill models are designed for use with a standard safely operate your grill. 20 lb. Liquid Propane Gas (LP Gas) tank (sold sepa- rately).
  • Page 22 USE AND CARE INSTRUCTIONS NOTE about LP Gas Tank Exchange Programs Secure a 20lb LP Gas Tank to Gas Grill Many retailers that sell grills offer you the option of replac- Turn your LP Gas Tank Valve clockwise to the closed ing your empty LP Gas tank through an exchange service.
  • Page 23 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.

  • Page 24: Natural Gas Connection

    Natural Gas Connection Natural Gas Model only: Gas Line Piping: Connecting Natural Gas To Your Grill If the length of line required does not exceed 50 feet, Connect the Swivel nut of the 12' Natural Gas use a 5/8" O.D. tube. One size larger should be used Hose to the horizontal fitting of NG Regulator as for lengths greater than 50 feet.

  • Page 25: Lighting & Fuel Gauge Instructions

    Parts List. Also make sure all gas supply connections are securely tightened. Familiarize yourself with all Safety and Use and Care instructions in this manual. Do not smoke while (for GT3211LNG) Main Burner lighting your grill or when checking the gas supply connections.
  • Page 26 USE AND CARE INSTRUCTIONS Manually Lighting Your Grill By Paper Match To light your gas grill by match, insert a match into the Lighting WARNING Stick and follow steps 1 through 5 of the Grill Lighting Instructions. Then, light the match and place Lighting Stick through the Cooking Grids and underside of the Hot Plate on Never lean over the grill cooking area while lighting the grill (See Diagrams Below).

  • Page 27: Troubleshooting

    USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset If the grill fails to light : the regulator excess gas flow device: Turn gas off at source and turn Control Knobs to OFF. Wait Turn Control Knobs to the OFF position. at least 5 minutes for gas to clear, then retry.

  • Page 28: Transformer Instructions

    USE AND CARE INSTRUCTIONS WARNING CORRECT TRANSFORMER AND LIGHT USE Read all instructions before initial use. IMPORTANT: When using transformer appliances, basic To protect against electrical shock, do not immerse safety precautions should always be used. The Transformer is set for 120V, 60Hz AC current input, electrical cord, plugs or motor in water or expose to 12VAC, 25W output.

  • Page 29: Cleaning And Maintenance

    Cleaning Exterior Stainless Steel Surfaces: CLEANING AND MAINTENANCE Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operating the appearance and corrosion resistance of stainless condition and prolong its life. Follow these cleaning procedures steel.
  • Page 30 2. 2. CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you To reduce the chance of FLASHBACK FIRE you must clean use, we recommend that you also complete the follow- the Burner Tubes as follows at least once a month in summer and fall or whenever spiders are active in your ing cleaning regimens to help prolong Burner life.

  • Page 31: Cooking Instructions

    Cooking Instructions Indirect Cooking using Main Burners Burn-Off The indirect cooking method can also be used with the Before cooking on your gas grill for the first time, you supplied Cooking Grids. To cook indirectly, the food should "burn off" the grill to eliminate any odor or foreign should be placed on the left or right side of your grill with matter.
  • Page 32 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on , close the Lid and preheat your T-bone steak Medium: 10-14 minutes grill 3 to 5 minutes.
  • Page 33 Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings shown are approximate. There string to retain shape if desired. Bacon strips can be used to are many factors such as outside temperature, wind condi- cover the outside surface of lean meat and poultry to help tions and grill location that affect your grill performance.
  • Page 34 Guide to Stir-Frying and Deep-Frying DEEP-FRYING TECHNIQUES STIR-FRYING TECHNIQUES A wide variety of foods can be deep-fried outdoors on your This method of cooking is popular around the world and can grill, from potatoes, to seafood and chicken. Deep-frying be easily accomplished outdoors on your gas grill. It's a quick uses a large portion of oil, preferably saturated.
  • Page 35 Question: Question: Sometimes I hear a humming sound coming from my Can I convert my grill from one fuel type to another in regulator. What causes this? And - My grill has a low other words from LPG to NG or vice versa? flame and sometimes will not light.
  • Page 36 To help maintain the finish of stainless steel follow these cleaning procedures for the best results: You may also review FAQ’s, Troubleshooting and Care & Maintenance Tips online at www.grandhall.com.
  • Page 37 All remaining parts - 2 Year Limited Warranty Grand Hall will require reasonable proof of your date of purchase. Therefore, you should send in the owner registration card or register online at www.grandhall.com. Save your receipt in case it is required as proof of purchase.

This manual is also suitable for:

Gt3211llp
