- Page 1 Installation Installation Guide Wireless HD Kit GWAV8141K...
-
Page 3: Table Of Contents
Table of Contents Package Contents Overview Wall Mount Installation Remote Control Selecting Specific Ports LED Indication IR Blast IR Extender Video Format Support Audio Format Support Connection Between the Transmitter Unit and Receiver Unit Factory Reset Firmware Upgrade / Configuration Update Streaming Mode FCC Statement CE Compliance... -
Page 4: Package Contents
Package Contents 1 x Wireless HD Transmitter 1 x Wireless HD Receiver 1 x Remote Control 2 x Wireless HD Stand 1 x Component to VGA Adapter 1 x IR Blast 2 x Power Adapter 1 x Installation Guide 1 x Warranty Card... -
Page 5: Overview
*Note: For the audio part of a Component media source, please use the PC Audio Input Port with a 3.5mm to RCA Cable (Not included and sold separately – IOGEAR Part No: G2LMMRCA006). **Note: If you wish to use the PC Video Input Port for Component (YPbPr) media source, please use the... - Page 6 DC Power Jack *Note: IR Extender not included. **Note: For the audio part of a Component media source, please use the PC Audio Input Port with a 3.5mm to RCA Cable (Not included and sold separately – IOGEAR Part No: G2LMMRCA006).
-
Page 7: Wall Mount
Wall Mount Hang the unit on the wall by using the two screw holes on the unit. -
Page 8: Installation
(Not included and sold separately - IOGEAR Part No: G2LMMRCA006) from the media source’s audio output to IOGEAR Part No: G2LMM006) from the transmitter unit’s PC Audio-In port the media source’s audio output to the transmitter unit’s PC Audio-In port... - Page 9 Step 2 Connect the IR Blast to the IR-Out Port from the Transmitter unit. Then stick the IR blast directly in front of each of the IR sensor of your media source devices Note: If the location of the IR sensor for your media source is not found, you can point the media source’s remote directly in front of the media source, then search for the IR sensor’s location by controlling the media source in different area in the front panel until you find the spot that the media source can be able to received the signal from the remote control.
- Page 10 Audio – Connect a 3.5mm to RCA Cable Connect a Composite cable from the receiver (Not included and sold separately – unit’s AV output to your display’s Composite IOGEAR Part No: G2LMMRCA006) input from the receiver unit’s PC Audio Output port to RCA ports of the...
- Page 11 If none of the above works, please refer to the Factory Reset section to perform a factory reset on both transmitter unit and receiver unit. If the connection has been established and you can see the IOGEAR screen; however, when you play a media from a source and it’s not showing on your display: Please make sure the cables are properly connected.
-
Page 12: Remote Control
Remote Control POWER INFO TRANSMITTER HDMI1 HDMI1 RECEIVER HDMI HDMI2 HDMI2 COMP VIDEO OUT VIDEO IN AUDIO IN WiFi WiFi CH 1 CH 2 POWER • If the transmitter unit and receiver unit are powered off with the Power/Link LED on, press the power button will turn on both transmitter unit and receiver unit simultaneously •... - Page 13 INFO Press to display information* of the transmitter unit, receiver unit and display: Transmitter unit** • WiFi Channel • Firmware Version Video/Audio Input • Receiver unit Connection • Firmware Version • • Video Output • Display Resolution WiFi Reception (1 to 5, 1 being weakest and 5 being strongest) •...
-
Page 14: Selecting Specific Ports
Selecting Specific Ports Front Panel Pushbutton You can cycle through the ports by pressing the front panel pushbutton Note: For the front panel pushbutton, both video and audio will switch port simultaneously. Remote Control You can press the specific port’s button from the remote control Note 1: Video and audio will always switch simultaneously when switching receiver unit’s output port. -
Page 15: Ir Blast
IR Blast This allows you to control your media source by aiming your official remote that comes with your media source at the receiver unit. The signal will then send from the receiver unit back to the transmitter unit. Finally, it will send to your media source via the IR blast. IR Extender This is an optional feature that allows you to hide the receiver unit and still able to control your media sources... -
Page 16: Connection Between The Transmitter Unit And Receiver Unit
Connection Between the Transmitter Unit and Receiver Unit There are two different kinds of connection between the transmitter unit and receiver unit WiFi – Wireless Connection This is a wireless connection and there are 2 channels to choose from. The default channel is Channel 1;... -
Page 17: Firmware Upgrade / Configuration Update
Firmware Upgrade / Configuration Update Please visit our website at http://avior.iogear.com/support/custom/wirelesshdkit and follow the instructions to upgrade the firmware or configure the units*. Note: Please make sure all units are using the same firmware version in order to function correctly. -
Page 18: Limited Warranty
NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Use the live chat at avior.iogear.com to try and solve any issues you may be having with the product 2. Visit the Tech Info Library/FAQ on avior.iogear.com (under the Support tab) 3. - Page 20 About Us About Us IOGEAR offers connectivity solutions that are innova- tive, fun, and stylish, helping people enjoy daily life using our high technology products. GREEN IOGEAR is an environmentally conscious company that emphasizes the importance of conserving natural resources. The use of our technology solutions helps reduce electronic waste.
