IOGear GUWAVKIT Installation Manual

Iogear wireless audio / video kit installation guide
Hide thumbs Also See for GUWAVKIT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Troubleshooting Manual
Installation
Guide
Installation
Wireless Audio / Video Kit
GUWAVKIT
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GUWAVKIT and is the answer not in the manual?

Questions and answers

Related Manuals for IOGear GUWAVKIT

Summary of Contents for IOGear GUWAVKIT

  • Page 1 Installation Guide Installation Wireless Audio / Video Kit GUWAVKIT...

  • Page 3: Table Of Contents

    Table of Contents System Requirements Important Information Package Contents Device Overview Wireless USB Transmitter Wireless VGA Receiver Wireless Audio Receiver Preparing for Setup Software Installation Install Wireless USB Transmitter Install Wireless VGA Receiver Install Wireless Audio Receiver Advanced Settings Wireless USB Manager Video Mode Configuration Screen Resolution Configuration Wireless USB Transmitter Settings...

  • Page 4: System Requirements

    System Requirements • Microsoft Windows® XP (SP2) or Vista (32- / 64-bit) with available USB 2.0 port • 1.6 GHz processor (CPU) with 1GB of system memory (RAM) • Flat-panel (LCD / Plasma / DLP) TV display or Projector with VGA (RGB / D-sub 15-pin / PC) or DVI port (Does NOT work with CRT tube TV) •...

  • Page 5: Important Information

    Important Information Before you get started, please NOTE: Do not place Wireless USB devices under direct sunlight or near high heat emitting devices; Do not place Wireless USB devices near water or wet surfaces to avoid electric hazards; Do not place Wireless USB devices on any moving or unstable surfaces.

  • Page 6: Package Contents

    Package Contents • 1 x Wireless VGA receiver (for display) • 1 x Wireless Audio receiver (for stereo) • 1 x Wireless USB Transmitter (for computer) • 1 x VGA (F) to DVI-A adapter • 1 x USB 2.0 A to mini-B cable (3 ft.) •...
  • Page 7 • 1 x 3.5mm to RCA cable • 1 x Power adapter for Audio Receiver • 1 x Power adapter for Video Receiver • 1 x Hook-and-loop fastener • 1 x Quick Start Guide / User manual • 1 x Installation CD •...

  • Page 8: Device Overview

    Device Overview Wireless USB Transmitter 1. LINK: Data Transfer Activity Indicator LED blinks when data is being transferred 2. PWR: Power LED is solid when powered by the PC 3. USB Connector Connect to any available USB 2.0 port on your computer...

  • Page 9: Wireless Vga Receiver

    Wireless VGA Receiver 6 7 8...
  • Page 10 1. VGA : VGA Activity Indicator LED is solid when display cable is connected LED is blinking when data is being transferred 2. PWR: Power Indicator LED is solid when power is applied 3. Status Indicator Single* solid light: device is wirelessly connected to the selected Wireless USB Transmitter Single* slowly blinking light: device is searching for a Wireless USB Transmitter...

  • Page 11: Wireless Audio Receiver

    Wireless Audio Receiver 1. Power/Activity LED LED is solid when connection is established LED is blinking when power is on and connection is not established 2. 3.5mm Audio Socket Connects to the 3.5mm audio connector of the included 3.5mm or RCA audio cable, and the other end to the available 3.5mm audio socket or RCA audio socket on your display or stereo system 3.

  • Page 12: Preparing For Setup

    Preparing for Setup Before you begin, please make sure to properly remove all previously installed Wireless USB Manager and DisplayLink drivers from your system to avoid driver conflict. To properly remove previously installed drivers, please follow below instructions. For Windows XP users Go to Start ->...
  • Page 13 Remove button to Repeat steps 1 and select any previously installed Wireless USB drivers and click on properly uninstall the program.
  • Page 14 For Windows Vista users Click on the Vista logo. Click on Control Panel then double click on Programs and Features. Select any previously installed Displaylink software and click on the program. Uninstall button to properly uninstall...
  • Page 15 After successfully remove the DisplayLink software, please restart your system. Repeat Step 1 and select IOGEAR Wireless USB to VGA Kit and click on Uninstall.
  • Page 16 After all previously installed DisplayLink and Wireless USB to VGA Kit software are properly removed, please make sure to install the software on the CD following the procedures on the next page before plugging in the Wireless USB Transmitter to your computer. Important Note: If installing on Windows XP, Service Pack 2 (SP2) is required.

  • Page 17: Software Installation

    Software Installation – Windows XP Important Note: For Windows XP users, if you do not have Mi- crosoft .NET Framework 2.0 installed, you will be prompted to have it installed. Please follow below instructions for installation. Click “ Yes” to install .NET 2.0 Framework Check “License Agreement”...
  • Page 18 Click on “Next” to continue. Note – If you previously installed IOGEAR Wireless USB Hub and Adapter Kit (GUWH104KIT) software, please follow detail instructions on P.72 Appendix. Click on “ Yes” to accept the software License Agreement and continue the installation.
  • Page 19 The InstallShield Wizard will continue loading the drivers. Do not click on any button, other- wise, it will interrupt the installation process and cause malfunction of the product. The installation wizard will continue to install the video driver provided by DisplayLink. Click on “I Accept”...
  • Page 20 The DisplayLink driver starts to load. Do not click on any button, otherwise, it will interrupt the installation process and cause malfunction of the product. Click on “ Finish” to complete the software installation. It is highly recommended to restart your system after the software installation to ensure all drivers are loaded correctly.

  • Page 21: Software Installation - Windows Vista

    Software Installation – Windows Vista For Windows Vista users Insert the installation CD into the CD-ROM on your computer and click on Run setup.exe to begin the installation. Click on Allow when prompted User Account Control window to continue. The InstallShield Wizard will start loading.
  • Page 22 Click on “ Next” to continue. Click on “Yes” to accept the software License Agreement and continue the installation.
  • Page 23 The InstallShield Wizard will continue loading the drivers. Do not click on any button, otherwise, it will interrupt the installation process and cause malfunction of the product. The installation wizard will continue to install the video driver provided by DisplayLink. Click on “I Accept”...
  • Page 24 The DisplayLink driver starts to load. Do not Click “ Yes” to restart your system. click on any button, otherwise, it will interrupt the installation process and cause malfunction of the product.

  • Page 25: Install Wireless Usb Transmitter

    Install Wireless USB Transmitter Make sure the antenna is securely connected to the Wireless USB Transmitter. Plug the Wireless USB Transmitter to your computer via option 1 or 2. Windows will detect the device and complete the driver installation process automatically. Option 1: Plug the Wireless USB Transmitter into any available USB 2.0 port on your computer.
  • Page 26 Option 2: To properly connect the Wireless USB Transmitter and avoid interfering with other USB devices connected to your computer, you can use the included USB extension cable to connect the Wireless USB Transmitter with your computer. Place the USB extension cable on a flat surface, preferably the top of the desk or work area to ensure a good line-of-sight signal with the Wireless Video and Audio Receivers.

  • Page 27: Install Wireless Vga Receiver

    Install Wireless VGA Receiver Make sure the antenna is connected to the Wireless Video Receiver Connect one end of the included VGA cable to the Wireless Video Receiver, and the other end to your display’s VGA port. PWR 1 2 3 PWR 1 2 3 Input 1 Input 2...
  • Page 28 Input 3 Input 4 Example 1: For LCD monitor / Flat-Panel TV PWR 1 2 3 Input 1 Input 2 PC Port Audio Input 3 Input 4 PWR 1 2 3 Input 1 Input 2 PC Port Audio Input 3 Input 4...
  • Page 29 Example 2: For Projector...
  • Page 30 Install Wireless Video Receiver – With DVI Connector For monitor or TV that comes with DVI connector, you may use the included VGA to DVI-A adapter to connect the Wireless Video Receiver to your display. Connect one end of the VGA cable to the VGA connector of the VGA to DVI-A adapter, then connect the DVI end of the adapter to the DVI port on your display.
  • Page 31 Plug the power cable into Wireless VGA Receiver and make sure the Power Indicator LED is solid. Windows will automatically install the drivers for the Wireless VGA Receiver. Note: Please use the included power adpater as shown. This power adapter is slightly different from the one for Audio Receiver on P.35...
  • Page 32 Upon successful installation of your Wireless Video Receiver, double click on the Wireless USB Manager software icon located in your system tray. If you do not see the Wireless USB Manager icon appears in your system tray, please click on Start, then select All Programs, then click on Wireless USB Manager and click again on Wireless USB Manager to launch the application.
  • Page 33 Please change your display’s source setting to select VGA / RGB / PC as your video input source. Refer to the operating instructions supplied with your display. Note: You may use the included fabric hook-and- loop fastener to attach the Wireless VGA Receiver to your projector or LCD display / TV in order to ensure a good line-of-sight signal with the Input 1...
  • Page 34 Upon successful connection, the installation will set the best resolution supported by your display and extend your desktop to the right. This is called the Extended Mode. You will see the wallpaper displaying on the monitor/display that is connected to the Wireless VGA Receiver. You can click on the Restore Down button on the top right corner of the application window, then drag the window to the right side of your...

  • Page 35: Install Wireless Audio Receiver

    Installing Wireless Audio Receiver Plug the power cable into the Wireless Audio Receiver. Make sure the Link Activity LED turns on and starts blinking. The next step is to create the association of the Wireless Audio Receiver and the Wireless USB Transmitter. Note: The Wireless Audio Receiver will NOT function until the following association process is completed.
  • Page 36 Connect the mini-B end of the USB cable to the mini-B port on the Wireless Audio Receiver, and connect the other end of the USB cable to your computer.
  • Page 37 Once connected, the Wireless USB Cable As- sociation window will prompt and please click on “Accept Association” to continue. Click on OK to complete the association process.
  • Page 38 Disconnect the USB cable from the Wireless Audio Receiver and your computer. Double click on the Wireless USB manager icon located in the Windows system tray to verify the connection has been established successfully. The Wireless USB Manager will display the Wireless Audio icon and show the signal strength when connected.

  • Page 39: Connecting The Audio Receiver To Speakers

    Connecting the Audio Receiver to Speakers There are 3 options to connect the Wireless Audio Receiver to your TV, home stereo system, or power speakers. Option 1: Connect one end of the 3.5mm audio cable to the Wireless Audio Receiver, and the other 3.5mm end to the 3.5mm port on your display or stereo system.
  • Page 40 When connecting the 3.5mm audio cable to the 3.5mm port on your TV or display, make sure you connect to the 3.5mm port next to the VGA port used to connect your Wireless Video Receiver. Please refer to the original user manual that came with your TV or display for further instructions. Input 1 PC Port Audio...
  • Page 41 Option 2: Connect the 3.5mm end of the 3.5mm to RCA cable to the Wireless Audio Receiver, and the RCA (Red & White) end to your stereo system or TV’s RCA input sockets.
  • Page 42 Congratulations, your Wireless Audio / Video Kit is ready for use. Note: For quick trouble-shooting guide, please go to P.56. For more information on using your Wireless Audio / Video Kit for different applications, please visit IOGEAR’s website for detail instructions.

  • Page 43: Advanced Settings

    Advanced Settings – Wireless USB Manager The Wireless USB Manager is a simple and easy- to-use interface that allows you to manage your Wireless USB devices and control your Wireless USB Transmitter settings. The Wireless USB Manager can be accessed via the Wireless USB Manager icon located in the Windows system tray.
  • Page 44 If your Wireless VGA Receiver is connected and working, then the icon will change and show the current signal strength. The View menu will give the option of what type of devices you wish to display (All Devices, Con- nected Devices and Disconnected Devices). The Options menu will give the option to launch Host Settings window and turn the Wireless USB Transmitter radio on or off.

  • Page 45: Video Mode Configuration

    Advanced Settings – Video Mode Configuration Note: If no output is seen on the monitor connected to the Wireless VGA Receiver, it may be in a mode which cannot be displayed by the monitor. This can happen if the monitor is not adjusted to the mode supported by the Wireless VGA Receiver.
  • Page 46 Extended Mode Extended mode enables the extension of the desktop across multiple monitors. To set up extended mode, click on the monitor icon located in your system tray to access the DisplayLink menu. You can choose to extend your desktop to 4 different orientations: right, left, above, and below, of your desktop.
  • Page 47 Mirror Mode Mirror mode duplicates the primary display (your desktop) to the monitor connected to the Wireless VGA Receiver. After setting up the display settings, you may now click on the monitor icon located in your system tray to access the DisplayLink menu. You can choose Mirror from the menu to enable the mirror mode.

  • Page 48: Screen Resolution Configuration

    Advanced Settings - Screen Resolution Configuration You may change the video resolution under extended or mirror mode. Extended Mode To change the screen resolution when in Extended Mode, please follow below instructions. Click on the monitor icon located in your system tray to access the DisplayLink menu.
  • Page 49 Mirror Mode When using in the Mirror Mode, click on “Advanced” from the menu to bring up the Display Settings window. Windows XP For Windows XP users, you can then click and drag the arrow bar to switch between different resolutions and click on Apply then OK to confirm.
  • Page 50 Windows Vista For Windows Vista users, you can click and drag the arrow bar to switch between different resolutions, and click on Apply then OK to confirm.

  • Page 51: Wireless Usb Transmitter Settings

    Advanced Settings - Wireless USB Transmitter Settings To manage the Wireless USB Transmitter settings, double click on the Wireless USB Manager icon in the system tray to bring up the Wireless USB Manager window. Click on Options and select Host Settings. •...
  • Page 52 • Advanced Settings Channel selection: this function allows you to manually set a radio channel (not recommended) for the wireless communication (combination of Band Group and Channel). For optimal performance, the automatic setting is recommended.

  • Page 53: Wireless Usb Transmitter Selection

    Advanced Settings - Wireless USB Transmitter Selection If you purchase more than one Wireless USB Transmitter (GUWA200), then you can use the HOST button on the Wireless Video Receiver to select and connect to different Wireless USB Transmitter. However, before you pressing this button to select another Wireless USB Transmitter, please make sure to go through the cable association process to associate the...

  • Page 54: Wireless Usb Transmitter Reset

    Advanced Settings - Wireless USB Transmitter Reset To erase all Wireless USB Transmitters (except the Wireless USB Transmitter included in this kit) associated* to your Wireless VGA Receiver, hold down the “RESET” button on the Wireless VGA Receiver for 10 seconds. This will cause the Wireless VGA Receiver to erase all Wireless USB Transmitters that have been associated from its list.

  • Page 55: Wireless Vga Receiver In Wired Mode

    Advanced Settings - Wireless VGA Receiver in Wired Mode Your Wireless VGA Receiver can also be used in wired mode. Make sure the position of the WIRED / WIRELESS switch is in the WIRED position. Plug the USB cable between your computer and the Wireless VGA Receiver.

  • Page 56: Trouble Shooting Guide

    Trouble Shooting Guide Installation and setup related Q&A …………………………………. P.57 Connection and signal quality related Q&A ………………………... P.64 Video and Audio Receivers configuration related Q&A …………… P.68...
  • Page 57 Trouble Shooting Guide For the latest FAQs, please go to IOGEAR website (www.iogear.com). Why can’t I install .NET? You may have an older version of .NET, preventing the newer one from being installed. Using Add/ Remove Programs (For Windows XP users) or Programs and Features (For Windows Vista users) in the Control Panel, uninstall any version of Microsoft .NET Framework older than version 2.0.
  • Page 58 If you see an icon that is grayed out in the Wireless USB Manager, try resetting the Wireless VGA Receiver by unplugging its power cord and plugging it back in. You should see the icon in the Wireless USB Manager appearing in color when it is connected.
  • Page 59 3. My Wireless USB Transmitter is plugged into my computer and my Wireless Audio Receiver is powered on but I do not hear anything. What’s wrong? Check the Wireless USB Manager to see if there is an icon for your Wireless Audio Receiver. If there is no icon, try unplugging and plugging your Wireless USB Transmitter to your computer, then unplugging and plugging your...
  • Page 60 4. My Wireless USB Transmitter is plugged into one of the USB ports on my computer and my Wireless Audio and Video Receivers are pow- ered on, but I get this window and I do not hear or see anything. What do I do? Please try to unplug and re-plug the Wireless USB Transmitter into the USB port, and you should see the USB logo becomes colored.
  • Page 61 5. I already reset my Wireless USB Host Transmitter and Audio Receiver, and the icon does show up in the Wireless USB Manager. But there is still no sound, what’s wrong? Windows XP For XP users, please go to Start -> Control Panel ->...
  • Page 62 Windows Vista For Vista users, right click on the Speaker icon at the bottom right corner of your system tray, then make sure the “2- USB Multimedia Audio Device” is checked then click Set Default and OK.
  • Page 63 6. Why do I get this window during the association process? If you idle for more than 45 seconds during the cable association process, you will see this window prompt. Just click OK to close the window, and repeat the association process again and you should not see this window again.
  • Page 64 7. I successfully installed everything and I can see video and hear audio from my TV, but the signal is bad and I can not get smooth video and audio quality. What can I do to get a better signal? First of all, please make sure the distance between the Wireless USB Transmitter and Wireless Video and Audio Receivers is within 30 feet.
  • Page 65 8. The video and audio signals seem to drop out when I walk in front of the Wireless USB Transmitter or put my hands around the antenna. What should I do to get a better signal? It is the most important thing to ensure a good line-of-sight between the Wireless USB Transmitter and the Wireless Receivers.
  • Page 66 9. If you are experiencing video or audio quality problems, please try following procedures for solutions. • Adjust the screen resolution to the appropriate setting supported by your monitor/display, please refer to P.48 for detail instructions. • The Wireless Audio / Video Kit requires certain level of system resource for smooth operation.
  • Page 67 10. I accidentally unplug the power from my Wireless Video Receiver, and the movie becomes playing on my main display of my computer. How do I bring it back to the other (extended) monitor? Please stop the movie that is currently playing and close the player on the computer.
  • Page 68 12. I already setup my Wireless USB Transmitter and Audio Receiver, and the icon does show up in the Wireless USB Manager. However, I would like the sound to be streaming from the built-in speakers of my computer, how do I do that? First of all, close the multimedia application you are currently running, and you have to change...
  • Page 69 For Vista users, right click on the Speaker icon at the bottom right corner of your system tray, then right click on your default speaker device and select Set as default device on the device and click OK. DO NOT select 2- USB Multimedia Audio Device as this is the driver for the Wireless Audio Receiver.

  • Page 70: Technical Specifications

    Video Resolution Video Streaming Color Depth Interface Frequency Band Number of Channel GUWAVKIT 2 CH DAC output 95db, THD+N -85db ~ -91db 8KHz, 16KHz, 44.1KHz, to 48KHz with 16-bit resolution Omni directional Up to UXGA 1600x1200 or WSXGA+ 1680x1050 Up to 720p 32-bit true color Audio: 3.5mm TRS audio connector ;...
  • Page 71 Security USB Specification Power Supply Environment Humidity Operation Temperature Storage Temperature GUWAVKIT Up to 30 feet (10 meters) Microsoft XP 32-bit; Vista 32/64-bit 53.3Mbps, 80Mbps, 106.6Mbps, 160Mbps, 200Mbps, 320Mbps, 400Mbps, 480Mbps QPSK/DCM Highly secured wireless connection (AES 128-bit) Certified Wireless USB 1.0; Certified USB 2.0 Audio Adapter: 5V, 1Ah, 100-240VAC;...

  • Page 72: Appendix

    Complete the installation of the Wireless Audio / Video Kit as shown in the Wireless VGA Software Installation section. Install the GUWH104 software “Driver Hub Only” for your Wireless USB Hub from IOGEAR website. Please make sure that you are in the correct product page.
  • Page 73 II. Cable association with other devices Association Concept: In order to establish a secure wireless connection between both the Wireless USB Transmitter and the Wireless USB devices, you will need to go through the cable association process. The association process will allow the Wireless USB Transmitter and the Wireless USB device to exchange security information about each other necessary to operate in a secured wireless mode.
  • Page 74 Cable association steps: Make sure that the Wireless USB Manager is running. Check your Windows tray for the Wireless USB Manager icon. Power on your Wireless USB device. Connect the USB cable between an available USB port on your computer and your Wireless USB device.
  • Page 75 Associated Wireless USB devices will appear as icons in the Wireless USB Manager. When the Wireless USB device is connected to your computer, the icon will appear in color.

  • Page 76: Limited Warranty

    The direct vendor also reserves the right to revise or update the device or documentation without obligation to notify any individual or entity of such revisions, or updates. For further inquiries please contact IOGEAR.

  • Page 77: Fcc) Statement

    Federal Communications Commission (FCC) Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device is authorized under 47 CFR 15.519 (the FCC Rules and Regulations).

  • Page 78: Contact

    All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR, Inc. assumes no responsibility for any inaccuracies or errors that may appear in this...
  • Page 79 Customer’s Record The model number and serial number of this product can be found on the product package. You should note this serial number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase to aid in identification for Warranty Service purposes. Model Number Serial Number Note...
  • Page 80 About Us About Us IOGEAR offers connectivity solutions that are innovative, fun, and stylish, helping people enjoy daily life using our high technology products. GREEN IOGEAR is an environmentally conscious company that emphasizes the importance of conserving natural resources. The use of our technology solutions helps reduce electronic waste.
