- Page 1 Quick Start Guide Wireless HDMI Transmitter and Receiver Kit GWHD11 PART NO. Q1292-b www.iogear.com...
-
Page 2: Package Contents
Package Contents 1 x Wireless HDMI Transmitter 2 x AAA Battery 1 x Wireless HDMI Receiver 1 x HDMI Cable 1 x Mini USB to USB Cable 1 x Quick Start Guide 2 x USB Power Adapters 1 x Warranty Card 1 x Remote Control System Requirements Display:... - Page 3 Overview Wireless HDMI Receiver: 1. Power Button with LED Indicator: - Lights green when powered on - - Lights red when in Standby Mode or when pairing 2. Source Button 3. Video Status LED - Off when in Standby Mode - Blinks at initial boot up / warm up (15~20 seconds) - When in wireless linked mode: a.
-
Page 4: Hardware Installation
Hardware Installation Step 1: Setup the Wireless HDMI Transmitter 1. Power on your PC or media source (Bluray, Sattelite box, etc.) 2. Power the transmitter through one of two options: a. If used with a Blu-Ray player or similar device, connect the Wireless HDMI Transmitter to the USB power adapter first, then plug the transmitter’s HDMI connector into the Blu-Ray HDMI output port. - Page 5 Hardware Installation Step 2: Setup the Wireless HDMI Receiver 1. Power on the TV / projector. 2. Connect the USB power adapter to the Mini-USB power jack on the receiver and a wall outlet for power supply. 3. Connect the HDMI cable to the HDMI connector on the receiver and to the HDMI Input on the TV / Projector.
- Page 6 Computer Display Setting You can adjust your display by going to your computer screen resolution preferences to change the display setting to “Duplicate,” “Extend” or “Project Only” on your HDTV / HD projector. If all operation is normal, the LED lights on both should be static (not blinking).
- Page 7 Pairing Additional Transmitters The Wireless HDMI Receiver can be paired with up to 3 additional Wireless HDMI Transmitters (Part #GWHDSTX sold separately). Please visit http://www.iogear.com/product/GWHDSTXB/ for more information. Note: When adding an additional transmitter: 1. Look at your serial numbers to see if * mark precedes the serial number on the receiver.
- Page 8 Transmitter No. button on the Remote Control. 2. The On-screen Display (OSD) Select Transmitter Number: will appear on the HDTV / HD → GWHD11 projector. Use the UP or DOWN buttons to select SETUP menu. SETUP 3. Select Add New Transmitter SETUP: to search for an available transmitter.
- Page 9 Searching Mode, press the Transmitter No. button on the remote control. 4. When both the transmitter and Adding GWHD11... receiver are in Pairing Mode, they will search for each other and automatically pair. 5. After the pairing is complete, both the transmitter and receiver will re-boot and establish the link to each other automatically.
- Page 10 If more than one transmitter is linked to the receiver, use the following steps below to modify a transmitter’s name: 1. Press Transmitter No. to display the list of linked transmitters. Select Transmitter Number: → GWHD11 → GWHDSTX SETUP 2. Select SETUP menu by using the Up / Down buttons;...
- Page 11 4. Use the Up / Down buttons to select the transmitter you want to modify. Edit Transmitter name: → GWHD11 → GWHDSTX Return 5. Then use the Up / Down buttons on the remote to select alphanumeric characters; use the Left / Right buttons on the remote to move the cursor;...
-
Page 12: Switching Between Transmitters
1. Press the Transmitter No. button. The OSD will show a list of transmitters linked to the receiver. Select Transmitter Number: → GWHD11 → GWHDSTX SETUP 2. Use the Up / Down buttons to select the transmitter you want to display on your HDTV / HD projector. - Page 13 Removing a Paired Transmitter 1. Press Transmitter No. to display the list of linked transmitters. Select Transmitter Number: → GWHD11 → GWHDSTX SETUP 2. Select SETUP menu by Select Transmitter Number: using the Up / Down → GWHD11 buttons; press OK →...
-
Page 14: Warranty
Warranty Warranty Information This product carries a 1 Year Limited Warranty. For the terms and conditions of this warranty, please go to https://www.iogear.com/support/warranty Register online at https://www.iogear.com/register Important Product Information Product Model Serial Number... - Page 15 Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support IOGEAR https://iogear.custhelp.com support@iogear.com www.iogear.com...
-
Page 16: Compliance Information
Compliance Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital service, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
