- Page 1 Quick Start Guide Expandable Wireless TV Connection Receiver GWMHDRX PART NO. Q1558 www.iogear.com...
- Page 2 1 x 5 VDC/2A Switching Power Supply 1 x Quick Start Guide 1 x Warranty Card System Requirements • 1 HDMI display device (SDTV, HDTV, projector with HDMI port, etc.) • IOGEAR Expandable Wireless TV Connection Kit GWMHDKIT22 or GWMRHDKIT...
- Page 3 Overview Receiver Front A. Input Channel indicator B. Channel selector button C. IR remote control window Receiver Back D. Power input E. Data transmission indicator F. Wireless connection indicator G. HDMI output connector H. IR receiver extender cable connector I. Antenna connector...
- Page 4 Hardware Installation Please read safety instructions carefully before installation and operation: 1. Please pay attention to all the warnings and hints for this device. 2. Do not expose this unit to rain, moisture or liquid. 3. Do not insert any foreign object into the device. 4.
- Page 5 Hardware Installation Receiver STEP 1 Install the antenna to the receiver STEP 2 Connect the IR receiver extender cable to the connector STEP 3 Connect one side of the HDMI cable to the receiver and the other side to your HDMI display device STEP 4 Connect DC5V/2A power adapter to the Receiver power input port...
- Page 6 Hardware Installation STEP 5 You can now connect to the transmitter by selecting the same channel number as the transmitter from either of the receiver(s) connected to your TV(s) CHANNEL CHANNEL Transmitter Receiver STEP 6 Wireless connection indicator of the transmitter and receiver will light up when the transmitter and receiver connection is established wirelessly If your video source and your display is on, you should be able to...
- Page 7 Q Transmitter and receiver will not connect wirelessly A 1. Please check if the wireless connection light is on and blinking 2. Restart both transmitter and receiver 3. Reconnect HDMI cables Q My transmitter and receiver are not connecting A Make sure the channel numbers are the same on the receiver to the transmitter that you want to connect to Q The wireless indicator is on but nothing on the display A Please check and see if the video source is working correctly by...
- Page 8 Important Product Information Product Model Serial Number Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support IOGEAR iogear.custhelp.com support@iogear.com www.iogear.com...
