  • Page 1 INSTALLATION MANUAL Steam humidifier Condair RS II Humidification, Dehumidification and Evaporative Cooling...

  • Page 2: Proprietary Notice

    Condair Group AG, except to the extent required for installation or maintenance of recipient's equipment. Liability Notice Condair Group AG does not accept any liability due to incorrect installation or operation of the equipment or due to the use of parts/components/equipment that are not authorised by Condair Group AG.

  • Page 3: Table Of Contents

    Contents Introduction To the very beginning Notes on the installation manual For your safety Product Overview Models overview 3.1.1 Single units Small ("S") , RS 5...10 and Medium ("M"), RS 16...40 3.1.2 Single units Large ("L"), RS 50...80 3.1.3 Double units (2 x "M"), RS 40...80 3.1.4 Device interconnected system (3 x "M"), RS 100...120 3.1.5...
  • Page 4 Wiring diagram Condair RS 50...80 - Single units "L" 5.7.4 Wiring diagram Condair RS 40...80 - Double units 2 x "M" 5.7.5 Wiring diagram Condair RS 100...160 - Device interconnected systems 3 x "M" or 4 x "M" 5.7.6 Installation work external connections 5.7.7 Connecting multiple units (device interconnected system) 5.7.8...

  • Page 5: Introduction

    Further information on options and accessories can be obtained in their respective instructions. This installation manual is restricted to the installation of the Condair RS steam humidifier and is meant for well trained personnel being sufficiently qualified for their respective work.

  • Page 6: Language Versions

    If the documentation gets misplaced, please contact your Condair representative. Language versions This installation manual is available in other languages. Please contact your Condair representative for information. Introduction...

  • Page 7: For Your Safety

    For your safety General Every person, who is in charge of the installation work on the Condair RS must have read and understood this installation manual and the Condair RS operation manual before carrying out any work. Knowing and understanding the contents of the installation manual and the operation manual is a basic requirement for protecting personnel against any kind of danger, to prevent faulty operation, and to operate the unit safely and correctly.
  • Page 8 Preventing unsafe operation All persons working with the Condair RS are obliged to report any alterations to the unit that may affect safety to the owner without delay and to secure the Condair RS against accidental power-up. Prohibited modifications to the unit No modifications must be undertaken on the Condair RS without the express written consent of Condair.

  • Page 9: Product Overview

    Product Overview Models overview Condair RS steam humidifiers are available as single units with different housing sizes (S, M and L), as double units (2 x "M") and as device interconnected systems (3 x "M" or 4 x "M") with dif- ferent heating voltages and steam capacities ranging from 5 kg/h up to a maximum of 160 kg/h.

  • Page 10: Single Units Large ("L"), Rs 50

    3.1.2 Single units Large ("L"), RS 50...80 Housing Condair 230 V/1~ 200V/3~ 230V/3~ 380V/3~ 400V/3~ 415V/3~ 440V/3~ 460V/3~ 480V/3~ 500V/3~ 600V/3~ size kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h RS 50 –– –– –– –– 50.0 53.4...

  • Page 11: Double Units (2 X "M"), Rs 40

    3.1.3 Double units (2 x "M"), RS 40...80 Housing Condair 230 V/1~ 200V/3~ 230V/3~ 380V/3~ 400V/3~ 415V/3~ 440V/3~ 460V/3~ 480V/3~ 500V/3~ 600V/3~ size kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h kg/h RS 40 –– 2*18.1 2*19.7 ––...

  • Page 12: Device Interconnected System (3 X "M"), Rs 100

    3.1.4 Device interconnected system (3 x "M"), RS 100...120 Housing Condair 230 V/1~ 200 V/3~ 230 V/3~ 380 V/3~ 400 V/3~ 415 V/3~ 440 V/3~ 460 V/3~ 480 V/3~ 500 V/3~ 600 V/3~ size kg/h kg/h kg/h kg/h kg/h kg/h...

  • Page 13: Device Interconnected System (4 X "M"), Rs 140

    3.1.5 Device interconnected system (4 x "M"), RS 140...160 Housing Condair 230 V/1~ 200 V/3~ 230 V/3~ 380 V/3~ 400 V/3~ 415 V/3~ 440 V/3~ 460 V/3~ 480 V/3~ 500 V/3~ 600 V/3~ size kg/h kg/h kg/h kg/h kg/h kg/h...

  • Page 14: Product Designation

    The identification of the unit is found on the specification label. Production Type designation Serial number (7 digits) Month/Year Condair Group AG, Gwattstrasse 17, 8808 Pfäffikon SZ, Switzerland Heating voltage Type: Condair RS 24 Serial-No: XXXXXXX 03.24 Voltage: 400V 3~ / 50...60Hz El.

  • Page 15: Model Designation

    Model designation Example: RS 24 400V/3~ M P VE Device type: Device model: Heating voltage: 230V/1~/50...60Hz: 230V/1~ 200V/3~/50...60Hz: 200V/3~ 230V/3~/50...60Hz: 230V/3~ 380V/3~/50...60Hz: 380V/3~ 400V/3~/50...60Hz: 400V/3~ 415V/3~/50...60Hz: 415V/3~ 440V/3~/50...60Hz: 440V/3~ 460V/3~/50...60Hz: 460V/3~ 480V/3~/50...60Hz: 480V/3~ 500V/3~/50...60Hz: 500V/3~ 600V/3~/50...60Hz: 600V/3~ Housing size: S: small housing M: medium housing L: large housing Control accuracy:...

  • Page 16: Options

    Mounting rail 1xMP-S 1xMP-M 2xMP-M 1xMP-L 3xMP-M 4xMP-M Mounting rail for mounting the Condair RS to a wall or the mounting rack basic. LonWorks board Supplementary board to connect the Con- 1xLW dair RS to a building management system via LonWorks.
  • Page 17 Set of cable glands 1xCG 2xCG 1xCG 3xCG 4xCG Set with cable glands for the control com- partment of the Condair RS. Total drain valve Set including solenoid drain valve and 1xSV 2xSV 3xSV 4xSV hose for automatic draining of the lime collector tank.

  • Page 18: Accessories

    (see details in chapter 3.4.2.3). Pure water system Condair RO-E For the correct size of the Condair RO-E pure water system, Pure water system for operating the Con- please contact the Condair representative dair RS with RO water.
  • Page 19 Condair RS Housing size Voltage Small Medium Double Large Device inter- Device inter- (2xM) connected connected system system (3xM) (4xM) 230V/1~ 5...10 ––– ––– ––– ––– ––– 200V/3~ ––– 16...30 40...60 ––– ––– ––– 230V/3~ 5...10 16...30 40...60 ––– –––...

  • Page 20: Accessory Details

    3.4.2 Accessory details 3.4.2.1 DV81-... steam distribution pipe The steam distribution pipes are selected on the basis of the duct width "B" (for horizontal installation) or the duct height "H" (for vertical installation) and the capacity of the steam humidifier. Important! Always select the longest possible steam distribution pipe (opti mum humidification distance).

  • Page 21: 3.4.2.2 Optisorp Steam Distribution System

    3.4.2.2 OptiSorp steam distribution system The OptiSorp steam distribution system is used in ventilation ducts with a short humidification distance (for the calculation of the humidification distance refer to chapter 5.4.2). When ordering an OptiSorp system the duct dimension must be specified. Please consult the data in the following table: System 1 System 2 System 3...

  • Page 22: 3.4.2.3 Blower Pack

    3.4.2.3 Blower pack The blower packs – in combination with the steam humidifiers Condair RS – are used for direct room humidification. The blower packs are mounted directly on the humidifier or separately above the humidi- fier to the wall.

  • Page 23: Receiving And Storage

    Check packing slip to ensure all parts has been delivered. All material shortages are to be reported to your Condair supplier within 48 hours after receipt of the goods. Condair Group AG assumes no responsibility for any material shortages beyond this period.

  • Page 24: Storage And Transportation

    Storage and Transportation Storing Until installation store the Condair RS in its original packaging in a protected area meeting the following requirements: – Room temperature: 5 ... 40 °C – Room humidity: 10 ... 75 %rh Transportation For optimum protection always transport the unit and components in their original packaging and use appropriate lifting/transporting devices.

  • Page 25: Mounting And Installation Work

    DANGER! Danger of electric shock! The Condair RS is mains powered. Live parts may be exposed when the unit is open. Touching live parts may cause severe injury or danger to life. Prevention: The Condair RS must be connected to the mains only after all mounting and installation work has been completed, all installations have been checked for correct workmanship and the unit is closed and properly locked.

  • Page 26: Installation Overviews

    – must not touch funnel (with optional drain water cooling 2...10 bar / 1...25 °C) Open funnel with trap (supplied by others) Condair RO-E pure water system (accessory) Fig. 8: Typical installation for duct humidification Mounting and installation work 2611991-A EN 2506...
  • Page 27 – must not touch funnel (with optional drain water cooling 2...10 bar / 1...25 °C) Open funnel with trap (supplied by others) Condair RO-E pure water system (accessory) Fig. 9: Typical installation for room humidification 2611991-A EN 2506 Mounting and installation work...

  • Page 28: Mounting The Unit

    Mounting the unit 5.3.1 Notes on locating the unit e.g. RS 60 5 0 0 5 0 - 2x "M" * recommended: 250 mm d u l d u l . 5 0 m i n e.g. RS 120 3x "M" 5 0 0 5 0 - .
  • Page 29 The steam humidifier Condair RS must only be installed in rooms with a floor drain. CAUTION! If for some reason the Condair RS must be installed in a location without floor drain, it is manda- tory to provide a leakage monitoring device to safely interrupt the water supply in case of leakage.

  • Page 30: Mounting The Humidifier

    5.3.2 Mounting the humidifier 5.3.2.1 Standard mounting Overview standard mounting single units Small and Medium Dimension Housing size RS 5...10 ("S") RS 16...40 ("M") "a" in mm 54.0 54.0 "b" in mm 446.0 556.0 "c" in mm 80.2 88.6 "d" in mm 304.8 406.4 Weights...
  • Page 31 Overview standard mounting single units Large Dimension Housing size RS 50...80 ("L") "a" in mm 164.0 "b" in mm 426.0 "c" in mm 117.2 "d" in mm 406.4 Weights Housing size RS 50...80 ("L") Netweight in kg 83.5 Operating weight in kg 134.5 Fig.
  • Page 32 Mounting procedure standard mounting 1. Mark the attachment points "A" and "B" at the desired position with the help of a level. Then, drill holes diameter: 10 mm, depth: 50 mm. 2. Insert the supplied plastic plugs, and screw in supplied screws into the dowels of the attachment points "A"...

  • Page 33: Rail Mounting (Option)

    5.3.2.2 Rail mounting (option) Overview rail mounting single units Small and Medium Dimension Housing size RS 5...10 ("S") RS 16...40 ("M") "a" in mm 193.5 193.5 "b" in mm 304.8 406.4 "c" in mm 57.6 61.8 Weights Housing size RS 5...10 ("S") RS 16...40 ("M") Netweight in kg 28.5...
  • Page 34 Overview rail mounting single units Large Dimension Housing size RS 50...80 ("L") "a" in mm 263.5 "b" in mm 406.4 "c" in mm 117.2 Weights Housing size RS 50...80 ("L") Netweight in kg 83.5 Operating weight in kg 134.5 Fig. 14: Overview rail mounting single units Large Mounting and installation work 2611991-A EN 2506...

  • Page 35: Inspecting The Installed Unit

    Procedure 1. Mark the attachment points "A" for the mounting rail at the desired position with the help of a spirit level. Then, drill holes diameter: 10 mm, depth: 50 mm. 2. Insert the supplied plastic plugs, and fix the mounting rail to the wall with the screws and washers supplied.

  • Page 36: Steam Installation

    Steam installation 5.4.1 Overview steam installation for duct humidification . 4 . 2 u c t i p t e b s t r c h a n y o s e e t o a o w n a n c n k n .
  • Page 37 Blower Pack (mounted separated from the steam humidifier) Steam line – As short as possible (max. length 4 m) – Adequate upslope/downslope min.15 % (8.5°) – No restrictions – Condensate trap at the lowest point Condsensate line – Hose or fixed pipe (with same inner diameter as –...

  • Page 38: Positioning Of The Steam Distributor

    5.4.2 Positioning of the steam distributor The location of the steam distributor should be determined at the time of dimensioning the air condition- ing system. Please note the following instructions to ensure proper humidification of the duct air. Calculating the absorption distance The steam, emitting from the steam distributor, requires a certain distance to be absorbed by the air so that it is no longer visible as steam.
  • Page 39 Note: If the absorption distance has to be reduced for technical reasons, the amount of steam per unit must be divided between several steam distribution pipes or the steam distribution system OptiSorp must be used. If this is the case, contact your Condair representative. Minimum distances to be observed...
  • Page 40 before diffuser before humidity controller/ humidity sensor before/after filter/heater " ) ( 1 . 1 . 5 2,5 x B before aerosol filter before/after fan, zone exit " ) ( 1 . Mounting and installation work 2611991-A EN 2506...

  • Page 41: Installation Notes

    Installation notes The steam distribution pipes are designed for either horizontal installation (on the duct wall) or, with ac- cessories, for vertical installation (in the duct floor). The outlet orifices should always point upwards and at right angles to the airflow. If possible, the steam distribution pipes should be installed on the pressure side of the duct (max.
  • Page 42 1 / 4 1 / 4 gm i 1 / 4 gm i 1 / 4 2 / 5 2 / 5 1 / 5 1 / 5 1 / 5 1 / 5 1 / 5 1 / 5 H min.= 600 mm H min.= 500 mm H min.= 400 mm...

  • Page 43: Installing The Steam Distributors

    – Steam distribution pipes must not be mounted to round ducts. If you have questions relating to the dimensioning of ventilation ducts in combination with steam humidi- fiers Condair RS, contact your Condair representative. 5.4.3 Installing the steam distributors Detailed information on the installation of steam distribution pipes DV81-... and OptiSorp steam distribu- tion system can be found in the separate mounting instructions for these products.

  • Page 44: Positioning And Mounting Of The Blower Packs (Accessory Bp)

    If you have questions concerning the direct room humidification, please contact your Condair representative. Further information is provided in the separate installation and operating instructions for the correspond- ing blower pack.

  • Page 45: Installing The Steam And Condensate Lines

    Installing the steam and condensate lines Installations notes – Use original steam and condensate hose from your Condair representative or solid steam pipes from copper or stainless steel (min. DIN 1.4301) exclusively. Steam and condensate lines from other material may cause undesired operational malfunctions.

  • Page 46: Installation Examples

    Installation examples Accessory: VS-DV81 Ømin. 200 mm Ømin. 200 mm Fig. 18: Steam distributor mounted more than 500 mm above the top edge of the humidifier Mounting and installation work 2611991-A EN 2506...
  • Page 47 Ensure adequate cooling according to local codes Obstacle Ensure adequate cooling according to local codes Install condensate drain (full size T) at the lowest point Fig. 19: Steam distributor mounted less than 500 mm above the top edge of the humidifier 2611991-A EN 2506 Mounting and installation work...
  • Page 48 Steam line must be insulated over the entire length! Ømin. 200 mm Fig. 20: Steam line with solid piping and insulation Mounting and installation work 2611991-A EN 2506...

  • Page 49: Common Steam And Condensate Line Errors

    5.4.6 Common steam and condensate line errors Wrong Correct Steam line not led at least 11.81" (300 mm) perpendicularly Lead steam line at least 11.81" (300 mm) perpendicularly upwards before first bend (forming of condensate). upwards before first bend. Minimum bend radius of steam hose/solid steam line not The minimum bend radius of 11.81"...

  • Page 50: Inspecting The Steam Installation

    5.4.7 Inspecting the steam installation Use the following check list to ensure that the steam installation was performed correctly: – Steam distributor Steam distributors (steam distribution pipe or OptiSorp steam distribution system) correctly positioned and secured (screws tightened)? Are the outlet orifices at right angles to the air flow for horizontal installation, or at 45 degree angle for vertical installation? –...

  • Page 51: Water Installation

    Water installation 5.5.1 Overview water installation Water drain connector ø30 mm Water supply connector G 3/4" Water supply line (min. inner diameter 8 mm, Recommendation: Drain hose (supplied) use armored hose, supplied by others) – internal diameter ø30 mm Filter valve or –...
  • Page 52 Water drain connectors ø30 mm Water supply connectors G 3/4" Drain hoses (supplied) Water supply lines – internal diameter ø30 mm (min. inner diameter 8 mm, Recommendation: – Drain hoses must be led to the left use armored hose, supplied by others) –...

  • Page 53: Notes On Water Installation

    The indicated connection specifications must be observed. Note: The Condair RS can also be fed with reverse osmosis water from the optional Condair RO-E pure water system (see installation overviews in chapter 5.2).
  • Page 54 – Draining rates: Note: The draining rates shown in the table below apply to the operation of the Condair RS with un- treated drinking water and the factory settings for the water reduction interval time. When operating with reverse osmosis or deionized water, the water reduction interval time can be reduced according to the table in the operation manual, which reduces the draining rate accordingly.

  • Page 55: Inspecting The Water Installation

    5.5.3 Inspecting the water installation Check the following topics: – Water supply Has filter valve (accessory "Z261") or shut-off valve and 125 µm water filter respectively been installed in supply line to each unit module? Has acceptable water pressure (without drain water cooling: 1 – 10 bar, with drain water cooling: 2 –...

  • Page 56: Notes On Humidity Control Systems/Humidity Control

    Notes on humidity control systems/humidity control 5.6.1 System 1 – Room humidity control System 1 is suited for direct room humidification and air conditioning systems with mainly recir- culated air. The humidity sensor or humidistat respectively is preferably located in the room itself or in the exhaust air duct.

  • Page 57: System 3 - Supply Air Humidity Control With Continuous Output Limit Ation

    System 3 Direct room humidification System 1 — Please contact your Condair supplier, if your application meets the following conditions: – Humidification of small rooms up to 200 m – Air conditioning systems with a high number of air exchanges –...

  • Page 58: Admissible Control Signals

    5.6.5 Admissible control signals Control with external controller Control with internal PI controller Control signals Humidity sensor signals 0...5 VDC 0...5 VDC 1...5 VDC 1...5 VDC 0...10 VDC (Potentiometer 140 Ω ... 10 kΩ) 0...10 VDC (Potentiometer 140 Ω ... 10 kΩ) 2...10 VDC 2...10 VDC 0...20 VDC...

  • Page 59: Electrical Installation

    DANGER! Danger of electric shock The Condair RS is mains powered. Live parts may be exposed when the unit is open. Touching live parts may cause severe injury or danger to life. Prevention: The Condair RS unit must be connected to the mains only after all mounting and instal- lation work has been completed, all installations have been checked for correct workmanship and the unit is closed and properly locked.

  • Page 60: Wiring Diagram Condair Rs 5

    SW1 Rotary switch Module identification (must be left on position "0") THV Terminal Heating voltage supply (option) Drain water cooling valve (option) Total drain valve (option) Fig. 28: Wiring diagram Condair RS - Single units "S" and "M" (5...40 kg/h) Mounting and installation work 2611991-A EN 2506...

  • Page 61: Wiring Diagram Condair Rs 50

    Jumper for activating the terminating resistor for Modbus RTU or BACnet MS/TP communication via the RS485 interface "X3". Jumper must be connected, if Condair RS is the last unit in the Modbus network. Jumper connected: Terminating resistor CAN bus active Jumper removed: Modbus RTU or BACnet MS/TP communication via RS485 interface "X3"...

  • Page 62: Wiring Diagram Condair Rs 40

    Jumper for activating the terminating resistor for Modbus RTU or BACnet MS/TP communication via the RS485 interface "X3". Jumper must be connected, if Condair RS is the last unit in the Modbus network. Jumper connected: Terminating resistor CAN bus active 6.3 A, slow acting...

  • Page 63: Wiring Diagram Condair Rs 100

    5.7.5 Wiring diagram Condair RS 100...160 - Device interconnected systems 3 x "M" or 4 x "M" Control compartment "Main unit module A" Control compartment "Main unit module B" LEVEL POWER DRN2 J3 DRN1 J2 INLET J1 UNIT BOARD SUPPLY L1 L2 Driver board "Main unit module B"...
  • Page 64 Jumper connected: Terminating resistor internal communication driver/control board active (do not remove) Jumper for activating the terminating resistor for Modbus RTU or BACnet MS/TP communication via the RS485 interface "X3". Jumper must be connected, if Condair RS is the last unit in the Modbus network.

  • Page 65: Installation Work External Connections

    5.7.6 Installation work external connections Connecting the external safety loop The potential-free contacts of external moni t or ing de- MAINS SUPPLY CONTROL vices (e.g. ventilation interlock "B1", airflow monitor "B2", VOUT IN GND L N SC1SC2PEPE safety high limit humidistat "B3", etc.) are connected in series (safety loop "SL") to the terminals "SC1"...
  • Page 66 Humidity control wiring Connecting a demand or humidity signal The signal cable of an external controller or of a humid- ity sensor (if the internal P/PI controller is used) are to be connected according to the wiring diagram to the terminals "IN"...
  • Page 67 Connecting a 24V On/Off humidistat The signal cable of 24V On/Off humidistat is to be con- nected according to the wiring diagram to the terminals "VOUT" and "IN" on the driver board in the control compartment. The connecting cable must be led through a cable gland CONTROL into the control compartment.
  • Page 68 Control a warning is indicated. compartment – "Running" (Terminals 7 and 8): This relay closes as soon as the Condair RS hu- midifies. – "Unit on" (Terminals 9 and 10): Error Service...
  • Page 69 Note: if the optional drain water cooling valve is retrofit- ted, it must be activated via the control software. In this case contact your Condair representative. Connecting the total drain valve (option) The connecting cable of the optional total drain valve "Y2"...
  • Page 70 Connecting the control voltage Note: if the Condair RS is equipped with option "CVI" or "TR", a separate control voltage supply is not required. The control voltage supply (L1, N, PE) is to be con- MAINS SUPPLY nected in accordance with the wiring diagram to the...
  • Page 71 Connecting the heating voltage supply L1 L2 L1 L2 L2 L3 L2 L3 Control compartment Control compartment (Module A) (Module B) 200-600 V/3~/50..60 Hz 200-600 V/3~/50..60 Hz 230 V/1~/50..60 Hz 230 V/1~/50..60 Hz The heating voltage supply (L1, L2, L3 and PE or L1, N and PE) is to be connected in accordance with the wiring diagram to the corresponding terminals of the main contactor "K1"...
  • Page 72 Connecting the heating voltage supply via option TR (for 3 phase single voltage system) MODULE B MAINS SUPPLY MODULE B MAINS S L1 L2 L1 L2 L N SC1SC2PEPE L N SC1 Supply cable 6.3 A, (Module A / Module B) slow acting L2 L3 Option TR...
  • Page 73 Connecting the voltage supply via Option CVI (for 3 phase/neutral single voltage system) MODULE B MAINS SUPPLY MODULE B MAINS S L1 L2 L1 L2 L N SC1SC2PEPE L N SC1 Supply cable (Module A / Module B) L2 L3 6.3 A, slow acting Option CVI Control compartment...

  • Page 74: Connecting Multiple Units (Device Interconnected System)

    • Lead the pre-assembled CAN Bus cable(s) from below via a cable gland into the control com- partment of the Condair RS or the remote control unit (if applicable). • Pinch the freed shielding of the pre-assembled CAN Bus cable comming from the coming from...
  • Page 75 3. Make sure that the jumper "JP7" on the control board of the two devices with the longest physical connection (cable length) is connected. 4. Finally, refer to the Condair RS operation manual to set up the configuration for device interconnected system in the control software.

  • Page 76: Performance Data / Fuses "F3" Heating Voltage Supply

    5.7.8 Performance data / Fuses "F3" Heating voltage supply 230V/1~/50...60 Hz 200V/3~/50...60 Hz 230V/3~/50...60 Hz 380V/3~/50...60 Hz 400V/3~/50...60 Hz 415V/3~/50...60 Hz RS 5 16.4 –– –– –– –– –– RS 8 26.0 –– –– –– –– –– 15.0 RS 10 32.1 10.0 ––...

  • Page 77: Inspecting The Electrical Installation

    5.7.9 Inspecting the electrical installation Check the following points: Do the supply voltages for heating and control voltage comply with the relevant voltages stated on the specification label? Are the voltage supplies (heating and control voltage) correctly fused? Are the service switches "Q.." installed in the supply lines for to the heating and control voltage? Are all components correctly connected according to the wiring diagram? Are all connecting cables fastened? Are the connecting cables free of tension (passed through cable glands?)

  • Page 78: Appendix

    Appendix Unit dimensions 6.1.1 Unit dimensions unit "S" (RS 5...10) 173.5 71.7 123.8 80.2 304.8 57.6 304.8 57.6 G 3/4" 211.5 Fig. 34: Unit dimensions unit "S" (dimensions in mm) Appendix 2611991-A EN 2506...

  • Page 79: Unit Dimensions Unit "M" (Rs 16

    6.1.2 Unit dimensions unit "M" (RS 16...160) 167.5 65.5 88.5 406.5 73.5 G 3/4" 321.5 Fig. 35: Unit dimensions unit "M" (dimensions in mm) 2611991-A EN 2506 Appendix...

  • Page 80: Unit Dimensions Unit "L" (Rs 50

    6.1.3 Unit dimensions unit "L" (RS 50...80) 524.5 422.7 167.5 65.7 178.8 535.8 1033 1033 1000 406.5 406.5 123.5 G 3/4" G 3/4" 321.5 678.5 Fig. 36: Unit dimensions unit "L" (dimensions in mm) Appendix 2611991-A EN 2506...
  • Page 81 Notes...
  • Page 82 Notes...
  • Page 84 CONSULTING, SALES AND SERVICE: CH94/0002.00 Condair Group AG Gwattstrasse 17, 8808 Pfäffikon SZ, Switzerland Phone +41 55 416 61 11, Fax +41 55 588 00 07 info@condair.com, www.condairgroup.com...
