Summary of Contents for Zanussi ZOUKE0K2
- Page 1 EN User Manual | Oven ZOUKE0K2 zanussi.com\register...
-
Page 2: Table Of Contents
Welcome to Zanussi! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................8 5. -
Page 3: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. -
Page 4: Safety Instructions
• WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements or the surface of the appliance cavity. • Always use oven gloves to remove or insert accessories or ovenware. •... -
Page 5: Electrical Connection
The isolation device must have a contact opening width of minimum 3 mm. Type Maximum power • This appliance is supplied without a main ZHDN670X 6400 W plug and a main cable. • The hob connection socket is at the top of ZHDN640X 6000 W the oven cabinet. - Page 6 • Do not let sparks or open flames to come in contact with the appliance when you Connecting to terminal board open the door. • Do not put flammable products or items 1 2 3 4 5 that are wet with flammable products in, 230V 3~ near or on the appliance.
-
Page 7: Internal Lighting
2.6 Service use abrasive products, abrasive cleaning pads, solvents or metal objects. • To repair the appliance contact the • If you use an oven spray, follow the safety Authorised Service Centre. instructions on its packaging. • Use original spare parts only. 2.5 Internal lighting 2.7 Disposal WARNING! -
Page 8: Product Description
3.2 Securing the oven to the cabinet 4. PRODUCT DESCRIPTION 4.1 General overview Control panel Knobs for the hob Power lamp / symbol Knob for the heating functions Control knob (for the temperature) Temperature indicator / symbol Air vents for the cooling fan Heating element Lamp Cavity embossment - Aqua cleaning... -
Page 9: Using The Double Zone (If Applicable)
1. To activate the double zone, turn the knob clockwise 9. Do not turn it through Knob indication Function the stop position. Double zone switch 2. Turn the knob slowly to the symbol until you can hear a click. The two 1. -
Page 10: Using The Accessories
7.1 How to set: Heating function Heating Application function Step 1 Turn the knob for the heating functions to select a heating function. To roast large meat joints or poultry with bones on one shelf position. To Step 2 Turn the control knob to select the tem‐ make gratins and to brown. -
Page 11: Additional Functions
Wire shelf: Push the shelf between the guide bars of the shelf support and make sure that the feet point down. Baking tray: Push the tray between the guide bars of the shelf support. 9. ADDITIONAL FUNCTIONS 9.1 Cooling fan 9.2 Safety thermostat When the appliance operates, the cooling fan Incorrect operation of the oven or defective... -
Page 12: Cooking Times
condensation, add water each time after it Initially, monitor the performance when you dries up. cook. Find the best settings (heat setting, cooking time, etc.) for your cookware, recipes Cooking times and quantities when you use this appliance. Cooking times depend on the type of food, its consistency, and volume. -
Page 13: Information For Test Institutes
(°C) (min) Cookies, 16 pieces baking tray or dripping pan 20 - 30 Macaroons, 20 pieces baking tray or dripping pan 40 - 45 Muffins, 12 pieces baking tray or dripping pan 30 - 40 Savory pastry, 16 baking tray or dripping pan 35 - 45 pieces Short crust biscuits, 20... -
Page 14: Care And Cleaning
( °C) (min) Short bread Fan Cooking Baking tray 20 - 35 Preheat the oven for 10 min. Toast Grill Wire shelf max. 1 - 5 Preheat the oven for 10 min. Beef burger, Grill Wire shelf max. 20 - 30 Put the wire shelf on 6 pieces, 0.6 and dripping... - Page 15 Step 1 Turn off the oven and wait until it is cold. Step 2 Pull the front of the shelf support away from the side wall. Step 3 Pull the rear end of the shelf support away from the side wall and remove Step 4 Install the shelf supports in the oppo‐...
- Page 16 Step 2 Lift and pull the latches until they click. Step 3 Close the oven door halfway to the first opening position. Then lift and pull to remove the door from its seat. Step 4 Put the door on a soft cloth on a stable sur‐ face and release the locking system to re‐...
-
Page 17: Troubleshooting
Step 8 After cleaning, install the glass panel and the oven door. If the door is installed correctly, you will hear a click when closing the latches. When installed correctly the door trim clicks. Make sure that you install the internal glass panel in the seats correctly. -
Page 18: Energy Efficiency
13. ENERGY EFFICIENCY 13.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name Zanussi Model identification ZOUKE0K2 944068425 Energy Efficiency Index 95.1 Energy efficiency class Energy consumption with a standard load, conventional mode 0.89 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.78 kWh/cycle... -
Page 19: Environmental Concerns
cooking. The residual heat inside the Moist Fan Baking appliance will continue to cook. Function designed to save energy during cooking. Use the residual heat to warm up other dishes. Keep food warm Choose the lowest possible temperature setting to use residual heat and keep a meal warm. - Page 20 867377475-A-362023...
