- Page 1 THERMODYNAMIC STEAM TRAP SU2N/SU2H USER'S MANUAL...
-
Page 2: Table Of Contents
SAFETY GUIDE The models SU2N and SU2H are medium and high-pressure disc-type steam traps equipped with an automatic blow-off mechanism. In order to get maximum benefit from this product, be sure to read this manual before installing it. The following warnings and cautions are shown at appropriate places in this manual. -
Page 3: Specifications And Markings
The models SU2N & SU2H fully comply with the requirements of the European Pressure Equipment Directive 2014/68/EU. They are classified according to Article 4, Section 3 of the PED, which does not allow to bear the CE marking. -
Page 4: Construction Details
2 CONSTRUCTION DETAILS SU2N/SU2H SU2NW/SU2HW SU2NF/SU2HF Body Plug Cover 12. Cap Gasket Disc 38. Bimetal 39. Stopper Ring Screen... -
Page 5: Installation
2) Check the flow direction indicated on the side of the body. 3) The models SU2N and SU2H can be used for both horizontal and vertical lines. However, when installing the models in a horizontal line, be sure to maintain a slight slope to the line, so that any condensate will flow smoothly. -
Page 6: Operation
4 OPERATION CAUTION Before starting operation, open the bypass valve or blow valve completely and blow off the scale in the piping. 4.1 Operation procedure 1) After blowing off the scale from the piping, close the bypass valve or blow valve. 2) Open the stop valve on the trap outlet side. -
Page 7: Maintenance
CAUTION ⚫ When replacing parts, make sure the replacement parts are supplied by MIYAWAKI. The performance of steam traps deteriorates gradually over time due to wear, corrosion or dirt accumulating around the valve and the valve seat. Please conduct periodic diagnosis of traps in order to keep steam control systems and equipment working well. - Page 8 Repairs When a trap fails, it is necessary to clean the internal parts and to replace damaged parts. Take the failed trap apart following the steps below. 5.2.1 Disassembling the trap 1) Remove the cover (2). *Use a flat-blade screwdriver to remove the cover. 2) Remove the cap (5) by turning it counterclockwise.
- Page 9 Body Cover (39) Disc (38) Screen Plug (12) 12. Cap Gasket 38. Bimetal 39. Stopper Ring...
-
Page 10: Troubleshooting
Replace the damaged part. *2 the seat. The back pressure is too high. (The back pressure of the Replace the trap with an SU2N or SU2H must be less appropriate trap. than 50% of the inlet pressure.) Steam leaks From the cap The cap (5) is loose. -
Page 11: Warranty
Problems caused by devices or equipment other than MIYAWAKI’s, or a disallowed use environment When a repair or modification has been performed by anyone other than MIYAWAKI or people who are authorized to make such repairs Intrusion of salt or other substances that promote significant rust or corrosion or problems from fluids that contain the same substances Consumable parts such as Packing, Gasket, O-ring, Diaphragm, etc. -
Page 12: Serial Number (S. No.) Designation
1 7 1 1 → Jan.1, 2017 2 9 X M → Oct. 21, 2029 ●For 9-digit display S.No. □□□□□□□□□ MIYAWAKI identification number Represents the month. Represents the year. (last two digits of the year according to the Western calendar) Example of serial number designation 1 7 1 1 2 C 0 2 0 →... -
Page 13: Guidance For Reading Special Product Name
GUIDANCE FOR READING SPECIAL PRODUCT NAME 〇〇〇-○○-□ Special symbol: The symbol applies only to special products (Please refer to table 1 for details) Model symbol: Product model number Table 1 Symbol description Suffix Special contents Trap for high-pressure gas installed property (only for Gas Trap) Blow valve attached Change of gasket Special face to face dimension... - Page 14 If you have any question, please contact MIYAWAKI, our local authorized agent, or the company where you purchased the product. ⚫ In the interest of the development and improvement of our products, MIYAWAKI Inc. reserves the right to change the specification of the products without prior notice.
- Page 15 If you need any assistance regarding this manual, please contact MIYAWAKI INC.’s International Sales Dept. or its local representative. By scanning QR Code, you can access inquiry form. INTERNATIONAL SALES DEPT. 2-1-30, Tagawakita, Yodogawa-ku, Osaka, 532-0021, Japan Tel: +81-6-6302-5549 e-mail: export@miyawaki-inc.co.jp www.miyawaki-inc.com/en...
