- Page 1 Open Energy for All High Voltage Battery USER MANUAL HB-10S-G2 HB-15S-G2 HB-19S-G2 HB-23S-G2 Region: Global REV1.0 hoymiles.com...
-
Page 2: About This Document
(BESS). Please carefully read this manual before the installation, operation, and maintenance. This document is subject to update without notice. The latest version of this document and further information on the BESS are available in PDF format at https://www.hoymiles.com. Scope of Validity This document is valid for the following models: •... - Page 3 Copyright © Hoymiles Power Electronics Inc. All rights reserved. No part of this document can be reproduced, transmitted, transcribed, or stored in any form or by any means without the prior written permission of Hoymiles Power Electronics Inc. © 2024 Hoymiles Power Electronics Inc. All rights reserved.
-
Page 4: Table Of Contents
5.2 Power Cable Connection 5.3 Communication Cable Connection Operation and Maintenance 6.1 System Power-on 6.2 System Power-off 6.2 Routine Maintenance 6.4 Troubleshooting Handling Precautions and Guidelines for Product Disposal Technical Datasheet © 2023 Hoymiles Power Electronics Inc. All rights reserved. -
Page 5: Safety Precaution
• Alterations to the product are not allowed unless authorized in writing by the supplier. • Unauthorized alterations will void the guarantee and warranty claims. Hoymiles will not be liable for any damage caused by such unauthorized alterations. • It is not suitable for supplying power to life-sustaining medical devices. -
Page 6: Symbols On The Package And Label
The product must be stored and installed far from flammable materials. Please wear protective goggles when installing, operating, and maintaining the product. Observe the documentation. Read and understand all documentation supplied with the product. © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 7 Keep dry! The package/product must be protected from excessive humidity and must be stored under cover. No more than six (6) identical packages are to be stacked on each other. © 2023 Hoymiles Power Electronics Inc. All rights reserved.
-
Page 8: Product Introduction
Pack B Note: The quantity of Pack A can be 2, 3, 4, and 5. Description DC Switch Positive Terminal Negative Terminal PCS Communication Terminal (RS485/CAN) (COM1) Reserved (COM2) Wi-Fi Ground Terminal © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 9: Indicator Definition
The maximum output power is 11.52 kW. For the maximum output power of different models, please refer to ”9 Technical Datasheet”. • A circuit breaker must be installed between the inverter and the battery. Install the circuit breaker in accordance with local laws and regulations. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 10: Unpacking And Storage
Control Box Packing List Control Box*1 Bracket A*1 Bracket B*1 Bracket C*1 Ground Cable*1 Screw M4*12*4 Power Cable*2 Communication Cable*1 Screw M4*6*1 Certificate*1 Quick Installation Guide*1 Expansion Screw M6*80*1 © 2023 Hoymiles Power Electronics Inc. All rights reserved. -
Page 11: Product Storage
During the storage period of the system, professionals should regularly check the system to check whether the cables are loose, and clean the surface of the system; if any defects are found, please contact the dealer in time. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 12: Installation Instruction
Keep distance from doors, windows, driveway, or other batteries. b) Keep away from the heating device. c) Keep away from corrosive chemicals. d) The product should be installed in an environment with good ventilation and heat dissipation conditions. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 13: Space Requirements
The following tools are recommended in the installation process, and other auxiliary tools can also be used on-site if necessary. Detector Screwdriver Tape Measure Level Hammer Drill Marker Hammer Torque Wrench Protective Goggles Dust Mask Safety Gloves Safety Shoes © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 14: Installation Steps
Place Pack B on a level ground (0°-3°), parallel to the wall, and keep a distance of at least 20 mm. The handles are used to lift the pack off the ground and move it. 20 mm Handle © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 15 Use bracket C to secure the connection between Pack A and Pack B. The remaining Step 5 battery packs can be stacked layer by layer as shown in these figures. 5 N·m Step 6 Mark the hole position on the wall using a marker. © 2024 Hoymiles Power Electronics Inc. All rights reserved.
- Page 16 Φ: 6 mm 90° 90 mm • Place the anchor into the hole, insert the M6 screw into the anchor, and tighten it with a Step 8 torque of 8 N·m. 8 N·m © 2024 Hoymiles Power Electronics Inc. All rights reserved.
-
Page 17: Electrical Connection
6 mm²/10 AWG Negative Cable 6 mm²/10 AWG Communication Cable Standard communication network cable 5.1 Ground Cable Connection Procedure 4 N·m 5.2 Power Cable Connection Procedure 5.3 Communication Cable Connection Procedure © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 18: Operation And Maintenance
The first inspection is 6 months after the initial commissioning, • Check whether the ground cables are Grounding Reliability and the subsequent inspections firmly connected. can be carried out once every 6 to 12 months. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 19: Troubleshooting
The battery voltage is too low, or After the inverter is connected to The battery doesn’t work the battery SOC is lower than the the grid, charge the battery. shutdown protection value. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 20: Handling Precautions And Guidelines For Product
Additional experimentation may be required to verify performance and safety under such conditions. Statement (2): Hoymiles will take no responsibility for any accidents in the event the product is used for applications or under conditions other than those described in this document. •... -
Page 21: Disposal
Do not dispose of the battery system with your household waste. • Avoid exposing the battery to high temperatures or direct sunlight. • Avoid exposing batteries to high humidity or corrosive environments. For more information, please contact the original manufacturer. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 22: Technical Datasheet
6000 Cycles, @90% DOD, @70% EOL Certification IEC 62619, UN 38.3 Warranty 5-10 Years *Parallel connection between battery towers is not supported. (1) Please refer to Hoymiles Warranty Terms & Conditions for more details. © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 23 Floor 6-10, Building 5, 99 Housheng Road, Gongshu District, Hangzhou 310015 P. R. China +86 571 2805 6101 General inquiry: info@hoymiles.com Technical support: service@hoymiles.com Visit https://www.hoymiles.com/ for more information.
