- Page 1 Open Energy for All Low Voltage Battery Quick Installation Guide HBX-5LV-G1 HBX-10LV-G1 Region: Global REV1.4 hoymiles.com...
-
Page 2: Packing List
Low Voltage Battery Quick Installation Guide 1 General Declaration • Read this quick installation guide carefully before installation to learn about product features and safety precautions. •Only qualified personnel are allowed to install, operate, and maintain the equipment. • Installers should be well-trained to fully understand grid-connected photovoltaic power systems and national/regional standards. -
Page 3: Product Overview
Low Voltage Battery Quick Installation Guide 3 Product Overview HBX-5LV-G1 165 mm 144 mm 460 mm ON/OFF 652 mm 640 mm HBX-10LV-G1 165 mm 144 mm 550 mm ON/OFF 867 mm 855 mm © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 4 BMS- BMS- BMS- BMS- Link Out RS485-A RS485-B CAN-H CAN-L Specification Cable HBX-5LV-G1 HBX-10LV-G1 Ground Cable 6 mm²/10 AWG 6 mm²/10 AWG Positive Cable 25 mm²/4 AWG 35 mm²/2 AWG Negative Cable 25 mm²/4 AWG 35 mm²/2 AWG Communication Cable...
-
Page 5: Installation Instruction
Keep away from the heating device. c) Keep away from corrosive chemicals. Space Requirements ≥300 mm ≥300 mm ≥300 mm ≥200 mm ≥200 mm 200-300 mm 200-300 mm ≥0 mm ≥0 mm ≥0 mm © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 6 Low Voltage Battery Quick Installation Guide Wall Mounting Steps 12 N·m 3 N·m...
- Page 7 5 System Diagram Single Unit Inverter INVERTER LINK IN LINK OUT Parallel Connection with Busbar Inverter INVERTER INVERTER INVERTER LINK IN LINK IN LINK IN LINK OUT LINK OUT LINK OUT © 2024 Hoymiles Power Electronics Inc. All rights reserved.
- Page 8 The cable from the circuit breaker to the inverter is provided by the installation personnel. (Please refer to the Product Packaging List for cable specifications). • For HBX-5LV-G1, circuit breaker selection: DC 60 V, x A (X = 105*n*1.2) (n is the number of batteries, and x is the calculated value.) •...
-
Page 9: Electrical Connection
LINK IN LINK OUT LINK OUT LINK OUT Step 2 Power Cable Connection (Parallel Connection without Busbar) INVERTER INVERTER INVERTER LINK IN LINK IN LINK IN LINK OUT LINK OUT LINK OUT © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 10 Low Voltage Battery Quick Installation Guide Step 3 Communication Cable Connection (Single Unit) Inverter INVERTER LINK IN LINK OUT Step 3 Communication Connection (Parallel Connection) INVERTER LINK IN LINK OUT Inverter INVERTER INVERTER INVERTER LINK IN LINK IN LINK IN LINK OUT LINK OUT LINK OUT...
-
Page 11: Step 4 Battery Activation
On for 0.5s; Off for 0.5s. Inverter Communication Fault On for 0.5s; Off for 0.5s. Parallel Communication Fault On for 0.25s; Off for 3.75s. Alarm/Fault The indicator stays lit. The indicator is off. Shutdown © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 12 User Manual in the QR code or at www.hoymiles.com/resources/download/ Hoymiles Power Electronics Inc. Add: Floor 6-10, Building 5, 99 Housheng Road, Gongshu District, Hangzhou 310015, P. R. China Tel: +86 571 2805 6101 Email: service@hoymiles.com support@hoymiles.com www.hoymiles.com...
