- Page 1 Open Energy for All Low Voltage Battery USER MANUAL HBX-5LV-G1 HBX-10LV-G1 Region: Global REV1.3 hoymiles.com...
-
Page 2: Table Of Contents
5.3.5 Battery Shutdown 6. Cable Assembling (if required) 6.1 Power Cable 6.2 Communication Cable 7. Overcurrent Protection Requirement 8. Routine Maintenance 9. Handling Precautions and Guidelines for Product 10. Technical Datasheet © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 3: General Information
(BESS). The latest version of this document and further information on the BESS are available in PDF format at https://www.hoymiles.com. It is recommended that this document be readily accessible at all times. 1.2 Product Validity This document is valid for the following models: •... -
Page 4: Safety Introduction
• Alterations to the product are not allowed unless authorized in writing by the supplier. • Unauthorized alterations will void the guarantee and warranty claims. Hoymiles will not be liable for any damage caused by such unauthorized alterations. • It is not suitable for supplying power to life-sustaining medical devices. -
Page 5: Symbols On The Label
The battery is recyclable. The battery can be recycled by a professional recycling organization. Please refer to the relevant local regulations. Observe the documentation. Read and understand all documentation supplied with the product. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 6: Unpacking And Storage
Keep the package away from flammable, explosive, and corrosive materials. • If the battery has been stored for three months or longer, it must be fully inspected and tested by authorized personnel before it can be put into operation. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 7: Product Introduction
Low Voltage Battery User Manual 4. Product Introduction 4.1 Product Overview HBX-5LV-G1 165 mm 144 mm 460 mm ON/OFF 652 mm 640 mm HBX-10LV-G1 165 mm 144 mm 550 mm ON/OFF 867 mm 855 mm © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 8 Inverter Communication Terminal Parallel Communication Terminal Power Switch Description Definition INVERTER RS485-A RS485-B CAN-H CAN-L BMS- BMS- LINK IN BMS-CAN-H BMS-CAN-L RS485-A RS485-B BMS- BMS- LINK OUT BMS-CAN-H BMS-CAN-L RS485-A RS485-B © 2024 Hoymiles Power Electronics Inc. All rights reserved.
-
Page 9: System Diagram
× 6.14 kW) (10LV). • Cables for parallel connection are not provided by Hoymiles and should be purchased separately. • A circuit breaker must be installed between the inverter and the battery. Install the circuit breaker in accordance with local laws and regulations. For details about the circuit breaker, please refer to “7... -
Page 10: Installation Instruction
SOC is above 70%, the output power is 5.12 kW (5LV) and 6.14 kW (10LV). • In this wiring mode, the charge and discharge power of HBX-5LV-G1 must not be more than 3.07 kW; the charge and discharge power of HBX-10LV-G1 must not be more than 6.14 kW. -
Page 11: Mounting
The product must be protected from direct sunlight. If the product is installed under direct sunlight, the exterior components may age prematurely, and overheating might occur. When the temperature rises, the power may be derated, and the battery lifespan will be reduced. 200-300 mm 200-300 mm © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 12: Wall Mounting Steps
Handle the battery to the installation place; (Remove the top cover before handling.) Step 5 • Mount the battery on the bracket as shown below. • Use screws to secure the battery. 3 N·m 12 N·m © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 13: Electrical Connection
5.3.2 Power Cable Connection Single Unit Procedure INVERTER LINK IN LINK OUT Parallel Connection with Busbar Procedure INVERTER INVERTER INVERTER LINK IN LINK IN LINK IN LINK OUT LINK OUT LINK OUT © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 14: Communication Cable Connection
Insert the other end of the communication cable into the inverter BMS port. Inverter INVERTER LINK IN LINK OUT Parallel Connection Procedure INVERTER LINK IN LINK OUT Inverter INVERTER INVERTER INVERTER LINK IN LINK IN LINK IN LINK OUT LINK OUT LINK OUT © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 15: Battery Activation
The indicator stays lit. Shutdown The indicator is off. Note: • When the battery is started, the red indicator and blue indicator flash alternatively, indicating that the battery self-test is normal. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 16: Battery Shutdown
(The red plug is used for the Step 3 positive cable, and the black plug is used for the negative cable.) Step 4 Tighten the isolation cap and plug contact. © 2024 Hoymiles Power Electronics Inc. All rights reserved. -
Page 17: Communication Cable
(Please refer to the Product Packaging List for cable specifications). • For HBX-5LV-G1, circuit breaker selection: DC 60 V, x A (X = 105*n*1.2) (n is the number of batteries, and x is the calculated value.) •... -
Page 18: Routine Maintenance
Additional experimentation may be required to verify performance and safety under such conditions. Statement (2): Hoymiles will take no responsibility for any accidents in the event the product is used for applications or under conditions other than those described in this document. •... - Page 19 Read the instructions regarding the installation and operation to avoid damages due to incorrect operations. • The battery may have insufficient power capacity after long storage. • Knockoff or counterfeit battery. • Any inconsistency among serial number, model number, and product code. © 2024 Hoymiles Power Electronics Inc. All rights reserved.
-
Page 20: Technical Datasheet
Protection Degree IP65 Cooling Natural Convection Altitude ≤2000 m Cycle Life (25°C, 0.6C) ≥6000 Cycles Certification IEC 62619, IEC 62040, IEC 61000, UN 38.3 Warranty 5 Years Country of Manufacture China © 2024 Hoymiles Power Electronics Inc. All rights reserved. - Page 21 Floor 6-10, Building 5, 99 Housheng Road, Gongshu District, Hangzhou 310015 P. R. China +86 571 2805 6101 General inquiry: info@hoymiles.com Technical support: service@hoymiles.com Visit https://www.hoymiles.com/ for more information.
