INSTALLATION MANUAL
HOB
Argent SHB145 & Basic SHB330,
SHB340, SHB345 series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Argent SHB145 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Thetford Argent SHB145 Series

  • Page 1 INSTALLATION MANUAL Argent SHB145 & Basic SHB330, SHB340, SHB345 series...
  • Page 2: Table Of Contents

    Service & questions......................19 1. Introduction General This is the installation manual for the Thetford SHB145, SHB330, SHB340 and SHB345 series. The manual is meant for qualified installers who will install the appliance in a caravan, camper or holiday home. Read the information and instructions carefully and follow them strictly to install the appliance safely and correctly.
  • Page 3: Safety

    Attention. Important information. Note. Additional information. Video. Additional instruction video available. 2. Safety READ THESE INSTRUCTIONS FOR USE CAREFULLY . FAMILIARISE YOURSELF WITH THE APPLIANCE. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. General Risk of serious injury through burning, explosion, clamping, electrocution, suffocation and poisoning or damage to the product.
  • Page 4 ■ The surrounding surfaces must be able to withstand the allowable temperature rise of 65°C above ambient temperature, as specified in the EN30-1-1 standard and in accordance with the design of this unit. ■ The temperature of the surrounding surfaces may rise if there are other additional devices besides the appliance.
  • Page 5: Serviceability

    In terms of serviceability, this means that a dealer or authorised Thetford service partner must be able to remove and re-install the Thetford product within the time that is allowed according to the Thetford time-list, using standard tools and equipment.
  • Page 6: Technical Specifications

    4. Technical specifications Table 1: Burner specifications SHB145 SHB330 Gas input Injector Gas input Injector g/hr g/hr Gas burners 2 x 1.47 2 x 106 0.61 3 x 1.42 3 x 102 0.61 1 x 2.23 1 x 161 0.77 Total 5.17 4.26...
  • Page 7 SHB340 SHB345 Dimensions Appliance 5.6kg 5.6kg weight This appliance is suitable for use with LPG [Liquefied Petroleum Gas] and should not be used with any other gas. Table 3: Gas category Class 3 Appliance Gas category & Pressure CAT I CAT I 3 + (28-30/37) 3 B/P (30)
  • Page 8: Before Installation

    5. Before installation Content of the box For the single-piece packaged appliance, check the contents: ■ Appliance ■ Template ■ User manual ■ Installation manual Table 4: Mounting materials specifics SHB145 SHB300 - SHB340 - SHB345 ■ ■ Rubber seal Surface &...
  • Page 9 Cabinetry protection dimensions The distances below are between the edge of the burners and the sides and between the pan rests and overhanging parts. Caution: the surface temperature exceeds 95°C. To avoid a hazard, under bench access must be restricted. If you are unable to maintain the minimum distances mentioned in the table below, protect with non-flammable material.
  • Page 10: Installation Dimensions

    Cabinetry ventilation and protection dimensions Maintain provision for the dispersal of unburnt gas beneath the appliance. Ensure any gas drop hole is located away from the burners. The gas drop hole must vent to the outside of the leisure vehicle. 1.
  • Page 11 SHB145 surface mount ■ Prepare the cut-out as shown. ■ Position the unit so it is centred and level in the cut-out. ■ There must also be a gap of 2-3mm between the appliance and sides of the cut-out. SHB145 worktop cut-out: 38mm 153.5mm 162mm...
  • Page 12 Schematic overview of the appliance mounting There are 4 fixing positions, 2 on either side of the appliance. The upper image repres- ents the front left fixing position. The bottom image represents the other 3 fixing posi- tions. 1. Optional rubber seal 2.
  • Page 13 Prepare the SHB330 worktop cut-out: 452 . 9 R112.0 88 . 4 236 . 0 R80.0 R690 R112.0 Prepare the SHB340/SHB345 worktop cut-out: 527 . 0 R73.5 R73.5 110 . 5 25 . 0 25 . 0 256 . 0 R73.5 R73.5...
  • Page 14 Schematic overview of mounting the appliance into the cabinet 1. Surface mounting bezel 2. Bump stop 3. Glass lid 4.5mm 4. Clamping bush 5. Pressing 6. Clamping screw 7. Clamping arm 8. Worktop ■ Fit the mounting bezel (1) to the hob , prior to fitting it into the aperture. ■...
  • Page 15 Prepare the SHB330 worktop cut-out: 484 . 0 18 . 5 453 . 0 R87.0 R112.0 88 . 4 236 . 0 R80.0 R122.0 R690 R702.0 R112.0 R122.0 Prepare the SHB340/SHB345 worktop cut-out: 544 . 0 8 . 5 527 . 0 R82.0 R82.0 110 .
  • Page 16: Installation

    1. Flush mounting bezel 2. Bump stop 3. Glass lid 4. Clamping bush 5. Pressing 6. Clamping screw 7. Clamping arm 8. Worktop ■ Fit the mounting bezel (1) to the hob , prior to fitting it into the aperture. ■...
  • Page 17: Install The Appliance

    Install the appliance ■ Remove all packaging materials from the appliance. ■ Slide the appliance half way into the opening. ■ Connect the 12V DC cables for spark ignition (and cooling fans where applicable) to a 12V DC battery or power supply, using suitable connectors and observing the correct polarity.
  • Page 18: After Installation

    7. After installation Read the applicable instructions in chapter Safety first. Visual checks Check if: ■ All packaging materials have been removed. ■ The appliance is placed, mounted and levelled on a stable structure. ■ Vents and gas dispersal hole are not blocked/obstructed. ■...
  • Page 19: Service & Questions

    For our warranty clause, please refer to the conditions mentioned on www.thetford.com. Declaration of Conformity Thetford hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the applicable Regulations, Directives and Standards. A copy of the Declaration of Conformity can be found at www.thetford.com.
  • Page 20 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2017-2025 Thetford B.V. All rights reserved. SINS2301/0125-V03...
