- Page 1 INSTALLATION MANUAL Topline 160 series...
-
Page 2: Table Of Contents
Service & questions......................16 1. Introduction General This is the installation manual for the Thetford SHB165, SHB167, and SHB169. The manual is meant for qualified installers who will install the appliance in a caravan, camper or holiday home. Read the information and instructions carefully and follow them strictly to install the appliance safely and correctly. -
Page 3: Safety
Attention. Important information. Note. Additional information. Video. Additional instruction video available. 2. Safety READ THESE INSTRUCTIONS FOR USE CAREFULLY . FAMILIARISE YOURSELF WITH THE APPLIANCE. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. General Risk of serious injury through burning, explosion, clamping, electrocution, suffocation and poisoning or damage to the product. - Page 4 ■ The surrounding surfaces must be able to withstand the allowable temperature rise of 65°C above ambient temperature, as specified in the EN30-1-1 standard and in accordance with the design of this unit. ■ The temperature of the surrounding surfaces may rise if there are other additional devices besides the appliance.
-
Page 5: Serviceability
In terms of serviceability, this means that a dealer or authorised Thetford service partner must be able to remove and re-install the Thetford product within the time that is allowed according to the Thetford time-list, using standard tools and equipment. -
Page 6: Technical Specifications
4. Technical specifications Table 1: Burner specifications SHB165 SHB167 Gas input Injector Gas input Injector g/hr g/hr Gas burners 1 x 2.24 0.77 2 x 1.50 0.61 1 x 1.44 0.61 1 x 0.99 0.52 Total 3.68 3.99 Electrical 12V DC 12V DC supply SHB169... -
Page 7: Before Installation
Table 3: Gas category Class 3 Appliance Gas category & Pressure CAT I CAT I 3 + (28-30/37) 3 B/P (30) BUTANE (G30) 28 – 30mbar BUTANE (G30) 30mbar PROPANE (G31) 37mbar PROPANE (G31) 30mbar For installation in BE, CH, CY, CZ, ES, FR, GB, AT, BE*, CH, CY, CZ, DE, DK, GR, IE, IT, LT, PT, SI, TR EE, FI, FR, GB*, GR, HR, HU,... -
Page 8: Cabinet Requirements
Cabinet requirements The location must provide: ■ Wood cabinetry and worktop. ■ Support for at least the weight of the appliance as stated in Technical specifications plus any items placed on top. The total weight placed on top of the hob should not exceed 10kg. ■... - Page 9 If you are unable to maintain the minimum distances mentioned in the table below, protect with non-flammable material. Table 4: Cabinetry protection dimensions Model / ① ② ③ ④ Dimension (mm) SHB165 SHB167 SHB169 For models with a glass lid, the distance from the edge of the burner to the rear wall can be reduced to 110mm.
-
Page 10: Installation Dimensions
To ensure correct operation and prevent changes in air pressure affecting appliance performance, the appliance must be built into a securely fixed self- contained cabinet which is not connected to externally vented chambers in adjacent furniture, other than the gas drop hole described above. Protect the underside of the appliance with a heat shield made from non- combustible material, if the space below the hob is used for storage or another appliance. - Page 11 SHB167 worktop cut-out: 29 . 3° 73 . 1° R86.4mm R182.9mm 106.2mm 590.4mm SHB169 worktop cut-out: R211.5mm 12 . 6° 177.2mm 70 . 1° R82.5mm 149mm R1276mm 538.5mm...
-
Page 12: Flush Mount Option
Schematic overview of mounting the appliance into the cabinet ■ Place the hob in the worktop cut-out. ■ Position the unit so it is centred and level in the cut-out. ■ There must also be a gap of 2-3mm between the appliance and sides of the cut-out. Flush mount option ■... -
Page 13: Installation
Schematic overview of mounting the appliance into the cabinet ■ Place the hob in the worktop cut-out. ■ Position the unit so it is centred and level in the cut-out. ■ There must also be a gap of 2-3mm between the appliance and sides of the cut-out. 6. -
Page 14: Connect The Gas Supply
■ Place the appliance into the opening. ■ Fix the appliance in place using the fastener positions as shown in chapter 'Before installation'. Make sure the appliance is located correctly in the aperture. Check the position of the Hob in the worktop and perimeter seal before tightening the fasteners. -
Page 15: After Installation
7. After installation Read the applicable instructions in chapter Safety first. Visual checks Check if: ■ All packaging materials have been removed. ■ The appliance is placed, mounted and levelled on a stable structure. ■ Vents and gas dispersal hole are not blocked/obstructed. ■... -
Page 16: Service & Questions
For our warranty clause, please refer to the conditions mentioned on www.thetford.com. Declaration of Conformity Thetford hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the applicable Regulations, Directives and Standards. A copy of the Declaration of Conformity can be found at www.thetford.com. - Page 17 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2015-2025 Thetford B.V. All rights reserved. SINS2107/0125-V04...
