OfficeSource OSTLPHS27 Assembly Manual

Pair of 27" loop hutch supports
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
OfficeSource
FURNITURE
This assembly manual contains important safety information. Please read and keep for future reference.
Useful Hints Before You Start
1. Read each step carefully before starting.
2. Before beginning assembly,identify,sort and count the parts before assembly.
3. Using the wrong screw will cause damage.
4. Using incompatible hardware might cause damage to prodct.
5. It is important that each step is performed in correct order to avoid difflcuties.
6. Assemble your furniture on packaging cardboard to prevent scratch or damage.
7. Do not tighten any screws or bolt until the unit is completely assembled.
8. Keep all hardware parts out of reach of children.
Necessary Tools
Phillips
Screwdriver
Flat Head
Screwdriver
Distributed exclusively by COE Distributing!
Tel: 800-388-8202 (Mon-Fri | 9am-5pm EST.)
Model No.:
OSTLPHS27
Description:
Pair of 27" Loop Hutch Supports
Hammer
CAUTION - Risk of product damage!
Power Drill can be used on lowest
torque setting.
Customer Service
officesourcefurniture.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the OSTLPHS27 and is the answer not in the manual?

Questions and answers

Related Manuals for OfficeSource OSTLPHS27

Summary of Contents for OfficeSource OSTLPHS27

  • Page 1 Tel: 800-388-8202 (Mon-Fri | 9am-5pm EST.) FURNITURE officesourcefurniture.com This assembly manual contains important safety information. Please read and keep for future reference. Model No.: OSTLPHS27 Description: Pair of 27" Loop Hutch Supports Useful Hints Before You Start 1. Read each step carefully before starting.

  • Page 2: Hardware List

    Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. Hardware List Hutch(1x) OSTLPHS27(2x) (Sold Separately) Parts List Wood Screws Double Sided Bolts M6*20mm(12x) Stickers (4x) M4x40mm(8x) Foam Tape (2x) 16MM SPACER(4x)
  • Page 3 Option 1 1 6x Put Hutch(B) upside down on a clean surface. Attach OSTLPHS27(A) to Hutch(B) with Bolts(1) and Wood Screws(2). Main Top **If additional attachment is required. Insert Wood Screws(2) through the frame and into the top. Cover holes with Stickers(4).
  • Page 4 Flip Hutch(B) right side up. Set the end of the Hutch(B) without a leg on the desk top. Adjust Glides(5) on OSTLPHS27(A) so that the Hutch(B) is level. Attach the Hutch(B) to the desktop with the Double Sided Foam Tape(3).

  • Page 5: Care And Maintenance

    Care & Maintenance Check bolts/screws periodically and tighten them if necessary. Use asoft, clean cloth that will not scratch the surface when dusting. Clean the productwith mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser. Liquid spills should be removed immediately.Using a soft clean cloth,blot the spill gently. Always use protective pads under hot dishes and plates .Heat can cause chemical changes that may create spotting within furniture flnish.
