Summary of Contents for ICON Health & Fitness PFTL99513.1
Page 1
USER’S MANUAL Model No. PFTL99513.1 Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com.
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
Page 4
20. The treadmill is capable of high speeds. 24. When folding or moving the treadmill, make Adjust the speed in small increments to sure that the storage latch is holding the avoid sudden jumps in speed. frame securely in the storage position. 21.
BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this PROFORM Power 995i treadmill. The Power 995i manual. To help us assist you, please note the product ® treadmill offers an impressive selection of features model number and serial number before contacting us.
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 8. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex key materials until you finish all assembly steps.
Page 10
2. Make sure that the power cord is unplugged. Wire Press a Base Cap (74) into each side of the Base (94). Remove the tie securing the Upright Wire (81) to the front of the Base (94). Identify the Right Upright (90). Have a second person hold the Right Upright near the Base (94).
Page 11
4. Insert a Wheel Spacer (63) into a Front Wheel (62). Hold the Front Wheel inside the lower end of the Right Upright (90), and insert a 3/8" x 4" Screw (7) with a 3/8" Star Washer (13) into the Right Upright and the Front Wheel.
Page 12
6. Identify the Left and Right Base Covers (82, 83). Slide the Left Base Cover onto the Left Upright (89), and slide the Right Base Cover onto the Right Upright (90). Do not press the Base Covers into place yet. Identify the Right and Left Bottom Handrail Covers (84, 85).
Page 13
8. If there are four screws (C) in the locations shown, remove and discard them. 9. Set the console assembly face down on a soft surface to avoid scratching the console assem- Console bly. Remove and save the four 5/16" x 1/2" Assembly Screws (4).
Page 14
11. Attach the console assembly to the Handrails (86, 87) with four #10 x 3/4" Screws (9) and four #10 Star Washers (5) as shown. Start all four Screws, and then tighten them. Console Assembly 12. See the inset drawing. Connect the Upright Wire (81) to the console wire (D).
Page 15
13. Attach the Right Handrail Cover (92) to the Right Handrail (87) with three #8 x 1/2" Screws (1). Do not overtighten the Screws. Attach the Left Handrail Cover (79) to the Left Handrail (86) in the same way. 14. Slide the Left Bottom Handrail Cover (85) up against the Left Handrail Cover (79), and attach the Left Bottom Handrail Cover with two #8 x 1/2"...
Page 16
15. Note: If assembled on a smooth surface, the treadmill may roll forward during this step. Raise the Frame (56) to the upright position. IMPORTANT: Do not raise the Frame past the Brackets vertical position. Have a second person hold the Frame until step 17 is completed.
Page 17
17. Align the upper end of the Storage Latch (53) with the bracket on the Latch Crossbar (38), and insert the 5/16" x 2 1/4" Bolt (3) through the bracket and the Storage Latch. This will push a spacer (F) out of the Storage Latch; discard the spacer.
HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same circuit.
CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s sound system while you The treadmill console offers an impressive array of exercise. features designed to make your workouts more effec- To turn on the power, see page 20.
Page 20
HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
Page 21
4. Change the incline of the treadmill as desired. during that segment. Note: When you select the Calorie tab, the calorie display will show the To change the incline of the treadmill, press the approximate number of calories burned per hour. Incline increase or decrease button or one of the numbered Quick Incline buttons.
Page 22
7. Turn on the fan if desired. HOW TO USE AN ONBOARD WORKOUT The fan features multiple 1. Insert the key into the console. speed settings. Press the fan increase or de- See HOW TO TURN ON THE POWER on page 20. crease button to select a fan speed or to turn off 2.
Page 23
HOW TO USE A SET-A-GOAL WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the last segment ends. The walking belt will then slow 1. Insert the key into the console. to a stop.
Page 24
HOW TO USE AN IFIT WORKOUT 5. Start the workout. Note: To use an iFit workout, you must have access See step 3 on page 22. to a wireless network (see page 25). An iFit account is also required. Go to www.iFit.com to register for an During some workouts, an audio coach may guide iFit account.
Page 25
HOW TO USE THE SOUND SYSTEM The lower section of the display will show instruc- tions for the selected optional screen. Make sure To play music or audio books through the console to follow the instructions shown in the lower part of the display.
Page 26
The WiFi–Normal option will allow you to set up A list of networks will appear in the matrix. Press a wireless network connection using the console. the up and down buttons to highlight the desired See step 4 for instructions. network.
Page 27
If you cannot complete any part of this Log in to your iFit account on the web page. Then, enter the numerical code into the indicated field. process, or if you have any questions, go to Follow any other instructions on the web page. support.ifit.com for assistance.
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regularly clean the treadmill and keep the walking a. Check the power switch (see drawing c at the left). belt clean and dry. First, press the power switch into If the switch has tripped, wait for five minutes and the off position and unplug the power cord.
Page 30
Locate the Reed Switch (52) and the Magnet (50) b. If the walking belt is overtightened, treadmill per- on the left side of the Pulley (49). Turn the Pulley formance may decrease and the walking belt may until the Magnet is aligned with the Reed Switch. become damaged.
Page 31
SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first when walked on remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the walking belt is off-center, first remove the screws clockwise, 1/4 of a turn.
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
PART LIST Model No. PFTL99513.1 R0814A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Reed Switch Clip #8 x 3/4" Screw Reed Switch 5/16" x 2 1/4" Bolt Storage Latch 5/16" x 1/2" Screw Drive Motor...
Page 35
Key No. Qty. Description Key No. Qty. Description Base Pad #8 x 3/4" Truss Head Screw Left Foot Pad Left Rear Cap Right Foot Pad Right Rear Cap Left Front Cushion Top 1/4" x 1 3/4" Screw Right Front Cushion Top 1/4"...
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
