ICON Health & Fitness PRO-FORM POWER 995c User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
www.proform.com
Model No. PFTL99912.2
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-FORM POWER 995c and is the answer not in the manual?

Questions and answers

Related Manuals for ICON Health & Fitness PRO-FORM POWER 995c

Summary of Contents for ICON Health & Fitness PRO-FORM POWER 995c

  • Page 1 www.proform.com USER’S MANUAL Model No. PFTL99912.2 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care. IMPORTANT: Please register this product (see the limited warranty on the back cover of this manual)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 20. Keep fingers, hair, and clothing away from 25. When folding or moving the treadmill, make the moving walking belt. sure that the storage latch is holding the frame securely in the storage position. 21. The treadmill is capable of high speeds. Adjust the speed in small increments to 26.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM reading this manual, please see the front cover of this ® POWER 995 C treadmill. The POWER 995 C treadmill manual. To help us assist you, please note the product offers an impressive selection of features designed model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • To hire a service technician to assemble this • Left parts are marked “L” or “Left” and right parts product in your home, call 1-800-445-2480. are marked “R” or “Right.” • Assembly requires two persons. • To identify small parts, see page 6. •...
  • Page 8 2. Pull the Upright Wire (78) and the base ground wire (A) through the indicated hole in the Base (95). If there is a screw (B) pre-installed in the side of the Base (95), remove and discard it. Attach Hole the ground wire (A) to the Base with a #8 x 1/2"...
  • Page 9 4. Hold the Left Upright (79) against the Base (95). Be careful not to pinch the Upright Wire (78). Insert two 3/8" x 1 1/4" Screws (6) with two 3/8" Star Washers (13) and two 3/8" x 2 3/4" Screws (5) into the Left Upright.
  • Page 10 6. Attach the Left Handrail (83) to the Left Upright (79) with two 5/16" x 2 1/2" Screws (10) and two 5/16" Star Washers (11). Make sure that the Upright Wire (78) is resting to the side as shown and is not pinched. Fully tighten the Screws.
  • Page 11 8. Set the console assembly face down on a soft surface to avoid scratching the console assem- bly. Remove and discard the three Screws (D). Next, lift off the Console Cover (100). Console Assembly 9. Set the console assembly on the Left Handrail (83) and the Right Handrail (86).
  • Page 12 10. Attach the console assembly to the Handrails (83, 86) with four #10 x 3/4" Screws (7) and four Console #10 Star Washers (14) as shown. Start all four Assembly Screws, and then tighten them. 11. Connect the Upright Wire (78) to the console wire (E).
  • Page 13 12. Attach the Left Handrail Cover (82) and the Right Handrail Cover (85) to the Handrails (83, 86) with three #8 x 1/2" Screws (1) each. Do not over- tighten the Screws. 13. Slide the Left Bottom Handrail Cover (84) up against the Left Handrail Cover (82) and attach the Left Bottom Handrail Cover with two #8 x 1/2"...
  • Page 14 15. Firmly tighten the four 3/8" x 2 3/4" Screws (5) and then the four 3/8" x 1 1/4" Screws (6) (only one side is shown). Press the Left Base Cover (81) and the Right Base Cover (89) onto the Base (95) until they snap into place.

  • Page 15: The Chest Heart Rate Monitor

    THE CHEST HEART RATE MONITOR HOW TO PUT ON THE HEART RATE MONITOR • Do not expose the heart rate monitor to direct sun- light for extended periods of time; do not expose it The heart rate to temperatures above 122° F (50° C) or below 14° monitor consists of F (-10°...

  • Page 16: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same circuit.

  • Page 17: Console Diagram

    CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s stereo sound system The treadmill console offers an impressive array of while you exercise. This treadmill has been designed features designed to make your workouts more effec- specifically to work with iPod and has been certified by tive and enjoyable.
  • Page 18 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 19 4. Change the incline of the treadmill as desired. The Distance dis- play—This display will To change the incline of the treadmill, press the show the distance that Incline increase or decrease button or one of the you have walked or run. numbered Quick Incline buttons.
  • Page 20 6. Measure your heart rate if desired. 7. Turn on the fan if desired. Note: If you use the handgrip heart rate moni- The fan features mul- tor and the chest heart rate monitor at the same Increase tiple speed settings. time, the console will not display your heart Press the fan increase rate accurately.
  • Page 21 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
  • Page 22 HOW TO USE A SET-A-GOAL WORKOUT 7. When you are finished exercising, remove the key from the console. 1. Insert the key into the console. See step 8 on page 20. See HOW TO TURN ON THE POWER on page 18. 2.
  • Page 23 To re-run a recent iFit workout from your schedule, race you have completed. The other lines will show first press the Track button. Next, press the in- your top four competitors. The end of the matrix crease and decrease buttons to select the desired represents the end of the race.
  • Page 24 THE INFORMATION MODE displays will remain lit, although the buttons will not function. If the demo mode is turned on, the word The console features an information mode that keeps ON will appear in the center display. To turn on or track of treadmill information and allows you to person- turn off the demo mode, press the Enter button or alize console settings.

  • Page 25: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.

  • Page 26: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regularly clean the treadmill and keep the walking a. Check the power switch (see drawing c at the left). belt clean and dry. First, press the power switch into If the switch has tripped, wait for five minutes and the off position and unplug the power cord.
  • Page 27 Locate the Reed Switch (52) and the Magnet (53) b. If the walking belt is overtightened, treadmill per- on the left side of the Pulley (54). Turn the Pulley formance may decrease and the walking belt may until the Magnet is aligned with the Reed Switch. become damaged.
  • Page 28 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first when walked on remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the walking belt is off-center, first remove the screws clockwise, 1/4 of a turn.

  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 30: Part List

    PART LIST Model No. PFTL99912.2 R1114A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Reed Switch Clip #8 x 3/4" Screw Reed Switch 3/8" x 2" Bolt Magnet 3/8" x 1 3/4" Bolt Drive Roller/Pulley 3/8" x 2 3/4" Screw Cable Tie 3/8"...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Console Fan Cover Left Tray Fan Grill Right Tray Incline Motor Spacer Console Base Power Cord Console Trim Controller Clamp Pulse Bar Controller Bracket Clip Pulse Bar Bottom – User’s Manual Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL99912.2 R1114A...
  • Page 33 EXPLODED DRAWING B Model No. PFTL99912.2 R1114A...
  • Page 34 EXPLODED DRAWING C Model No. PFTL99912.2 R1114A...
  • Page 35 EXPLODED DRAWING D Model No. PFTL99912.2 R1114A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
