- Page 1 RP2f/RP4f Mobile Printers DC/DC Voltage Converter (12 V to 60 V) Installation Guide RPFVC-EN-II-03 Rev A 04/25...
- Page 2 12VDC, which is suitable for charging. This document describes the installation and use of the power converter for the RP2f and RP4f mobile printers. Keep this documentation for future reference.
- Page 3 Out of the Box Make sure that your shipping box contains these items: • Power converter • Input cable • Output cable • Mounting hardware (two screws and two washers) Mounting Determine the best location for mounting the power converter, taking into consideration the ease of accessing the power converter and mounting requirements.
- Page 4 • The power converter must be mounted to 330.2 to 406.4 square cm (51.2 to 63 square in.) of metallic surface, aluminum material with a minimum 6.1 mm (0.24 in.) thickness. Power Converter Dimensions 4.68 198.9 Tolerances: ±0.25 (0.01) (0.18) (7.83) Units: mm (in.) 2 X Ø7.14 (0.28)
- Page 5 • Cables or wiring that obstruct or hang up on places such as the steering wheel, gear lever, brake pedals, etc. can be extremely hazardous. Make sure that cable routing does not interfere with other equipment or vehicle controls. Warning: Bare or frayed wires can result in electrical short circuits, which can cause system or vehicle damage, or a fire hazard resulting in property damage, serious injury, and/or...
- Page 6 • Use a listed circuit breaker or non-renewable cartridge fuse suitable for DC branch circuit protection, rated 20 A, on the positive side of the supply (see Inline Fuse). Cable Connections The transformer is mounted on a metal surface. Output 2 1: - (Input): 6 - 60VDC;...
- Page 7 Determine the best method for connecting the power converter to the power source and for routing the cable, taking into consideration the following principles. • On electric forklifts, connect the power as close to the battery as possible, but not directly from the battery terminals or before any main fuse.
- Page 8 • Operating temperature @ -30 to 30°C, Output ratings = V1@4.5A; V2@4.0A • Operating temperature @ 30 to 60°C, Output ratings = V1@4.5A; V2@0.0A Input Power Cable Note: Keep the cable as short as possible. Extra cable picks up noise, adds power loss, and can snag on equipment. The input power cable may be shortened as needed, but should not be extended on 12V or lower systems.
- Page 9 Recommended Fuse Values Lift Voltage Fuse Rating Description Fast blow Slow blow Slow blow (maximum fuse value) Slow blow (maximum fuse value) Recommended Fuse Holder Part Description Manufacturer Number BK/HFA-R 1/4 in. x 1 1/4 in. in-line Eaton Electronics water-resistant fuse holder Division Reference: Input Power Cable Fuse Assembly...
- Page 10 Strip the input power cable jacket back 31 to 36 cm (12 to 14 in.). Install heat shrink tubing on the input power cable jacket. Battery cable jacket Black wire Red wire Ground wire Heat shrink tubing* Heat shrink tubing* Fuse* Green wire White wire...
- Page 11 Assemble the negative wire: Strip 0.60 cm (0.25 in.) of insulation from the green and white wires. Twist the wires together. Crimp a 3/8-inch terminal ring onto the wires. Assemble the positive wire: Cut a strip of red wire that is 5.08 cm (2 in.) long. Strip 0.60 cm (0.25 in.) of insulation from the red and black wires.
- Page 12 How to Connect to the Vehicle Battery The procedure you use to connect to the vehicle battery depends on the location of the battery terminal, top or side. Warning: Verify that the cable to battery connections are correct. Electrical energy from vehicle batteries can harm equipment and people.
- Page 13 Remove the nuts and bolts from the positive battery terminal. Place a 3/8-inch washer onto each end of the battery clamp bolt. Slide the positive fuse link terminal ring from the input power cable onto positive battery clamp bolt. Place another 3/8-inch washer onto the battery clamp. Thread a 3/8-inch nut onto the battery clamp bolt and tighten the nut securely.
- Page 14 Connect to the Side Battery Terminal Negative wire (green and white) Positive wire (red and black) Ground wire Positive wire (red) Fuse assembly* Positive battery Washers terminal post bolt * See Reference: Input Power Cable Fuse Assembly. Remove the positive battery terminal side post bolt from the vehicle battery.
- Page 15 Insert the post bolt assembly (Steps 2 through 6) into the positive battery terminal. Tighten the battery terminal post bolt securely. Repeat Steps 1 through 9 for the negative wire. Connect the ground wire. For help, see Ground Wire Connection. Ground Wire Connection The braided wire on the vehicle battery cable is the grounding strap.
- Page 16 Output Power Cable The 14 ft. (4.3 m) long output power cable has a durable 2-pin connector to mate with the power converter. The connector on the other end of the cable is specific to the mobile printer or vehicle docking device in your particular installation.
- Page 17 Troubleshooting Information Identifying and Correcting Problems Three basic procedures within this section identify and correct most power converter problems you may encounter during installation. Connector pin-out information is also furnished for your convenience. Troubleshooting the Power Converter Basic diagnostic procedures include the following: •...
- Page 18 LED will flicker until the problem is resolved. In some cases, you may have to remove power to reset the power converter. Inspecting the Cables and Connections Visually inspect all cable connectors and connections to the vehicle power source. Correct any obvious faults. •...
- Page 19 Testing for continuity Caution: Cables must be disconnected at both ends before you conduct any continuity tests. Failure to disconnect cables completely may result in damage or destruction of your test equipment, or incorrect/misleading readings. Thorough continuity testing takes longer than either substitution or voltage measurements.
- Page 20 Troubleshooting Charts The following troubleshooting charts assume that your vehicle mount printer or other equipment does not work and that the problem is caused by the power converter or its associated cables. Power Converter Reset Where the troubleshooting chart instructs you to “reset the power converter,”...
- Page 21 Meaning Remedy Still not lit Still no output Disconnect power output from power cable, reset the power converter. converter, check fuse. Flickers Intermittent Check connection to main main power power source. connection. Flickers Power converter Vehicle noise spikes detected over- exceeding voltage rating for voltage power converter.
- Page 22 Meaning Remedy Flickers Power supply Check case temperature of detected over- the power converter. If too hot temperature to touch, provide better heat condition. sink and more air flow. Replace damaged cables. Protect from direct sunlight, mount in the shade. Advanced Troubleshooting Assuming steps in the previous troubleshooting chart were taken, proceed to these next steps to resolve power failure...
- Page 23 LED/ Meaning Remedy Voltage Voltage still Still no input Replace input power cable not present power to the if input voltage is still not power present at connector. converter. Fuse Power system is Have the forklift vendor blowing, but drawing too recommend in-line filter, no LED lit much current.
- Page 24 Output 1 Pin 3 Pin 2 Pin 1 Note: Only Output 2 is utilized for RP2f/RP4f printer installations. Support To search our knowledge base for a solution or to log in to the Technical Support portal and report a problem, go to honeywell.com/PSStechnicalsupport.
- Page 25 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made.
