PX45 and PX65 Interface

Boards and Accessories

User Guide

Need help?

Do you have a question about the PX45 and is the answer not in the manual?

Questions and answers

Summary of Contents for Honeywell PX45

Page 1 PX45 and PX65 Interface Boards and Accessories User Guide...
Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. HII makes no representation or warranties regarding the information provided in this publication.
Page 3 Remarks............................8 Serial Interface.......................... 9 RS232 Non-isolated (Standard) ..................9 RS-422 Isolated, Full Duplex (reconfiguration required) ........10 RS-485 Isolated, Full Duplex (reconfiguration required) ........11 Industrial Interface ......................12 Digital Opto In........................12 PX45 and PX65 Accessory User Guide...
Page 4 Out of the Box .........................32 Installation..........................32 Remarks ............................34 Interfacing..........................34 Applicator Interface IN Signals .................34 Applicator Interface OUT Signals................35 Relay Out..........................37 Max AC Load Breaking Capacity ................38 Max DC Load Breaking Capacity................38 Configuring Applicator Port Settings................39 PX45 and PX65 Accessory User Guide...
Page 5 Installation ..........................50 Chapter 3 - Installing Accessories...............53 Cutter Module..........................53 Contents............................54 Installation ..........................54 Cutter Module and PX45 Printer with Cutter Module Installed ....57 Cutter Module and PX65 Printer with Cutter Module Installed ....57 Controlling the Cutter......................58 Maintenance and Troubleshooting................58 Cleaning..........................58 Troubleshooting ......................58...
Page 6 PX45 and PX65 Accessory User Guide...
Page 7 Technical Support portal. Product Service and Repair Honeywell International Inc. provides service for all of its products through service centers throughout the world. Go to sps.honeywell.com and select Support to find a service center near you or to get a Return Material Authorization number (RMA #) before returning a product.
Page 8 Caution: To reduce the risk of electric shock or fire, keep the cover closed and turn off the printer when not in use. There are no user- serviceable parts inside the power supply unit. viii PX45 and PX65 Accessory User Guide...
Page 9 CHAPTER INTRODUCTION Honeywell offers a full range of optional interface boards and accessories for the PX45 and PX65 printers. The interface boards included in this guide are compatible with both PM45 and PX65 printers. Interface Boards • Industrial Interface Board •...
Page 10 Warning: Follow standard ESD guidelines to avoid damaging the equipment. Remove Electronics Cover To remove the cover for PX45/PX65 printer, Open the media cover and remove the eight screws #T10 torx screws that hold the left-hand cover. Screw (8 places) Put the cover aside on a soft cloth or similar to avoid scratches.
Page 11 You can remove one or two cover plates depending on how many interface boards you are going to install. Each plate is held by two #T10 torx screws. Always start installation at the innermost position. PX45 and PX65 Accessory User Guide...
Page 12 PX45 and PX65 Accessory User Guide...
Page 13 Installation Warning: The installation described in this section must only be performed by an authorized service technician. Honeywell assumes no responsibility for personal injury or damage to the equipment if the installation is performed by an unauthorized person. Caution: Follow standard ESD guidelines to avoid damaging the equipment.
Page 14 Follow the procedure to physically install the Serial/Industrial Interface board in the printer. Note: This procedure applies to both the PX45 and PX65. For simplicity, the PX45 is depicted in the illustrations. Turn off the printer and disconnect the power cord.
Page 15 + uart3: Double Serial uart4: + uart5: Double Serial uart2: + uart3: Serial/Industrial uart4: Double Serial uart2: + uart3: IEEE1284 centronics: Serial/Industrial uart2: Serial/Industrial uart2: Serial/Industrial uart3: Serial/Industrial uart2: Double Serial uart3: + uart4: PX45 and PX65 Accessory User Guide...
Page 16 Serial/Industrial uart2: Remarks • The left-hand slot is the slot closest to the center section. • Always start by fitting an interface board in the left-hand slot. • RS-485 is only supported by “uart2:” PX45 and PX65 Accessory User Guide...
Page 17 Warning: When fitting driver circuit and straps before installing the interface board, make sure the circuit is not fitted upside down. Protect the board and circuits from the electrostatic charges RS232 Non-isolated (Standard) Connector Configuration (RS-232 on “uart2”) PX45 and PX65 Accessory User Guide...
Page 18 Transmit data Receive data Data set ready Ground Data terminal ready Clear to send Request to send RS-422 Isolated, Full Duplex (reconfiguration required) Note: The RS-422 circuit is available as a spare part. PX45 and PX65 Accessory User Guide...
Page 19 P3:2-3 which spoils the galvanic isolation +TXD +Transmit data +RXD +Receive data GNDE Ground -RXD -Receive data -TXD -Transmit data RS-485 Isolated, Full Duplex (reconfiguration required) Note: The RS-485 circuit is available as a spare part. PX45 and PX65 Accessory User Guide...
Page 20 The industrial interface has no straps or circuits to be fitted or removed. All signals are available on a DB-44pin socket and the various ports are controlled by the Honeywell Fingerprint instructions PORTIN and PORTOUT ON/OFF. For more information, see the Honeywell Fingerprint Command Reference Manual at www.sps.honeywell.com. Digital Opto In The status of the digital IN ports can be read using the PORTIN functions.
Page 21 PORTIN functions. If a current is led through the optocoupler of the port. PORTIN returns the value -1 (true), else it returns the value 0 (false). Signal Description Vceo Collector - emitter Breakdown Voltage Veco Emitter - collector breakdown voltage Collector current (non-saturation) 30mA PX45 and PX65 Accessory User Guide...
Page 22 PORTIN returns the value -1 (true), else it returns the value 0 (false). Max AC Load Breaking Capacity Signal Description Current Psw AC Switching power 100VA AC Usw AC Switching voltage 100V AC PX45 and PX65 Accessory User Guide...
Page 23 Relay 3 Normally Open REL3COM Relay 3 Common REL4NC Relay 4 Normally Closed REL4NO Relay 4 Normally Open REL4COM Relay 4 Common Simplified schematics of a relay OUT port: REL no REL nc REL com PX45 and PX65 Accessory User Guide...
Page 24 Follow the procedure to physically install the Double Serial Interface Kit in the printer. Note: This procedure applies to both the PX45 and PX65. For simplicity, the PX45 is depicted in the illustrations. Turn off the printer and disconnect the power cord.
Page 25 10. The kit contains two flat cables, one with two connectors for use with a single interface board and one with three connectors for use with double interface boards. Connect the appropriate flat cable to connector P1 on the interface board. PX45 and PX65 Accessory User Guide...
Page 26 14. Connect the power cord and switch on the power. 15. In case the interface provides additional serial communication ports, enter the Setup Mode to set the proper communication parameters for these ports. PX45 and PX65 Accessory User Guide...
Page 27 Take ample precautions to protect the board and circuits from electrostatic discharges. Install jumpers and ICs on the board to configure it for the type of serial communi- cation you want to use. PX45 and PX65 Accessory User Guide...
Page 28 For a passive transmitter: Install one jumper at P11B and P12B. Install one IC, 360-013-001 (6N139), on sockets SKT8 and SKT9 with pin 1 located where the arrow is pointing to SKT8 and SKT9 on the board. PX45 and PX65 Accessory User Guide...
Page 29 External +5VDC max 500mA (automatic switch off at overload, short-circuit protected) provided strap is fitted on P4:A or P8:A which spoils the galvanical isolation +TXD +Transmit data +RXD +Receive data GNDE Ground -RXD -Receive data -TXD -Transmit data PX45 and PX65 Accessory User Guide...
Page 30 P8:A which spoils the galvanical isolation +TXD +Transmit data +RXD +Receive data GNDE Ground -RXD -Receive data -TXD -Transmit data Note: Maximum recommended baud rate is 9600 bps. PX45 and PX65 Accessory User Guide...
Page 31 The only tools required for installation are the #T10 and #T20 Torx screwdrivers. Installation Warning: The installation described in this section must be only performed by an authorized service technician. Honeywell assumes no responsibility for personal injury or damage to the equipment if the installation is performed by an unauthorized person.
Page 32 10. The kit contains two flat cables, one with two connectors for use with a single interface board and one with three connectors for use with double interface boards. Connect the appropriate flat cable to connector P1 on the interface board.T PX45 and PX65 Accessory User Guide...
Page 33 The left-hand slot is the slot closest to the center section. • Always start by fitting an interface board in the left-hand slot. • Only one IEEE 1284 parallel interface board can be fitted. PX45 and PX65 Accessory User Guide...
Page 34 +Receive data DATA2 DATA3 Ground DATA4 DATA5 -Receive data DATA6 -Transmit data DATA7 BUSY SELECT Not Connected SCREEN External +5VDC max 500mA (automatic switch-off at overload, short-circuit protected) 19-30 INIT ERROR 33-35 Not Connected SELECTIN PX45 and PX65 Accessory User Guide...
Page 35 The RFID kit provides RFID functionality for PX45 and PX65 printers. With this kit installed, the PX45 or PX65 printer can read and write to RFID tags. This section describe how to install the RFID interface board and the connector configuration.
Page 36 Turn off the printer and disconnect the power cord. Open the front door and right side door. Remove the electronics cover (See page Release the lower media guide latch. Lower media guide latch PX45 and PX65 Accessory User Guide...
Page 37 Route the antenna cable from the RFID lower media guide through the opening in the print engine base. Make sure to route the cable in front of the label stop sensor (LSS) guide bar. PX45 and PX65 Accessory User Guide...
Page 38 1 or slot 2, and remove the cover plate. Note: You need to use the first available slot on the printer starting from the left (slot 1) 12. Connect the dual slot I/O cable to the main board. PX45 and PX65 Accessory User Guide...
Page 39 For slot 1, use the spacer screw on the main board. For slot 2, use the spacer screw in the kit. 17. Connect the antenna cable to the RFID interface board. 18. Attach the left side door to the printer. 19. Close the front and right side doors. PX45 and PX65 Accessory User Guide...
Page 40 Follow the procedure to physically install the Applicator Interface Board in the PM45 printer. Note: This procedure applies to both the PX45 and PX65 printers. For simplicity, the PX45 is depicted in the illustrations. Turn off the printer and disconnect the power cord.
Page 41 11. The flat cable should run as illustrated. CPU Board Spacer (existing) Cable Inner Interface Board Screw (existing) 12. Put the cover back on the electronics compartment. 13. Connect the communication cables to the connectors on the printer’s rear plate. PX45 and PX65 Accessory User Guide...
Page 42 The Applicator Interface supports 8 digital input ports with optocouplers. All in signals are asserted by setting the pin LOW and de-asserted by setting the pin HIGH. IN Signals Specification Signal Description Min. Typical Max. Vin [High] Input Voltage High Vin [Low] Input Voltage Low PX45 and PX65 Accessory User Guide...
Page 43 The recommended/default connection is Active Low, in accordance with this user guide’s logic (Assert = LOW, De-assert = HIGH). Active Low (Recommended) Output level is V+ when de-asserted, Output level is V- when asserted. PX45 and PX65 Accessory User Guide...
Page 44 6, 8, 20, 22, 24, 35, 37, 39 Emitter Pins: 5, 7, 9, 21, 23, 25, 36, 38 OUT Signals Specification Signal Description Max. Vceo Collector-Emitter breakdown voltage Veco Emitter-Collector breakdown voltage Collector Current 15mA PX45 and PX65 Accessory User Guide...
Page 45 DC 5V and DC 24V settings are legacy applicator card settings, no power is sup- plied by PX45/65 applicator card. Any signals that are within the max load break- ing capacity of the relay can be connected to the relays.
Page 46 Relay 2 Normally Open REL2com Relay 2 Common REL3nc Relay 3 Normally Closed REL3no Relay 3 Normally Open REL3com Relay 3 Common REL4nc Relay 4 Normally Closed REL4no Relay 4Normally Open REL4com Relay 4 Common PX45 and PX65 Accessory User Guide...
Page 47 (by using the Reprint signal) Error on Pause Enable this setting to set the ”Service Required” signal when the printer is paused. This setting supported by Z-Style only. Error Port Enables/disables the printer external error port. PX45 and PX65 Accessory User Guide...
Page 48 Reprints the last valid label. Apperr1 Applicator error 1. Apperr2 Applicator error 2. Apperr3 Applicator error 3. RTWINEXT External input signal, which you can use to monitor the operational status of the entire system. PX45 and PX65 Accessory User Guide...
Page 49 This signal is also asserted when the Error on Pause option is enabled. Programming Applications for the printer The printer includes Honeywell Fingerprint, a programming language that resides on the printer. Fingerprint is an easy-to-use programming tool for label formatting and printer customization.
Page 50 Fingerprint also includes a slave protocol, Honeywell Direct Protocol, which allows layouts and variable data to be downloaded from a host and combined into labels, tickets, and tags with a minimum of programming. Honeywell Direct Protocol also includes a versatile error handler and a flexible counter function.
Page 51 Using External Applicator Signals The printer responds to external applicator port signals differently, depending on whether your application is using Fingerprint or Honeywell Direct Protocol. Fingerprint and Applicator Signals When you use Fingerprint, all in signals and the Data-ready out signal are handled by Fingerprint.
Page 52 For internal system errors, the system error signal status can be read at any time within the application so appropriate measures can be taken. When any of these errors occur, the appropriate out signal (including the error) is asserted: • Printhead lifted PX45 and PX65 Accessory User Guide...
Page 53 Pause on the printer front panel. When the printer is in pause state, you can press Setup on the printer front panel and place the print engine in Setup Mode for manual configuration. PX45 and PX65 Accessory User Guide...
Page 54 When any of these errors occur, the appropriate out signal (including the error) is asserted: • Printhead lifted • Ribbon out • Media out • General print engine fault • Exceed maximum barcodes Error Messages ERRNOAPP Operation not allowed. Applicator Port disabled. Message: PX45 and PX65 Accessory User Guide...
Page 55 Cause: Activates event in System Health Monitor (SHM). Result: 1342 Error Number: ERTWINEXT RTW Extenal Error. Message: RTWExternal in signal detected. Cause: Activates event in System Health Monitor (SHM). Result: 1343 Error Number: ENODATAREADY PX45 and PX65 Accessory User Guide...
Page 56 The mapping of the applicator interface ports are detailed below. DB-44 Connector Pin. Applicator Interface External Error Port (8 pin) (44 pin) Type Signal Type Description Input AppErr_1 Input Applicator error#1 Input AppErr_2 Input Applicator error#2 Input AppErr_3 Input Applicator error#3 PX45 and PX65 Accessory User Guide...
Page 57 Output Service Output Error Output Required Output End Print Output End Print Output Output Media Out Output Media Out Output Output Ribbon Out Output Ribbon Out Output Output Data Ready Output Output VOID Output PX45 and PX65 Accessory User Guide...
Page 58 Follow the procedure to physically install the 802.11 WIFI Kit in the printer. Note: This procedure applies to both the PX45 and PX65. For simplicity, the PX45 is depicted in the illustrations. Turn off the printer and disconnect the power cord.
Page 59 Trim the excess cable tie. Insert the SDIO board assembly into the 44-pin connector. Secure the SDIO board assembly with the M3x8mm screw that shipped with the kit. PX45 and PX65 Accessory User Guide...
Page 60 11. Trim the excess from the cable tie. 12. Close the printer. 13. Connect the antenna to the antenna connector on the back plate. 14. Affix the labels to the appropriate locations on the printer. PX45 and PX65 Accessory User Guide...
Page 61 CHAPTER INSTALLING ACCESSORIES Cutter Module The PX45 and PX65 printers can easily be fitted with an optional cutter, provided the printer is not already fitted with a label-taken sensor. The cutters are almost identical with exception for the width. The cutter unit is fitted by replacing the front door and the printer hinges, and is connected by a single cable to the DIN-connector on the printer’s front.
Page 62 Installation Follow the procedure to physically install the cutter. Note: This procedure applies to both the PX45 and PX65 Printers. For simplicity, the PX45 Printer is depicted in the illustrations. You will need a Torx screwdriver to install the cutter module.
Page 63 Fit the cutter unit to the vacant hinges. Make sure that the locking plate snaps into the groove of the right-hand hinge and that the angled plate at the bottom of the cutter is inserted under the printer’s bottom plate. PX45 and PX65 Accessory User Guide...
Page 64 (also see the User’s Guide). Then tilt up the cutter again and lock it in closed position. 12. Check that the printhead is lowered and switch on the power. Now the printer is ready for operation. PX45 and PX65 Accessory User Guide...
Page 65 Cutter Module and PX45 Printer with Cutter Module Installed Cutter Module and PX65 Printer with Cutter Module Installed PX45 and PX65 Accessory User Guide...
Page 66 Cutter cable came loose from DIN Reconnect cutter cable “Cutter device not found” connector. connector to DIN connector. Error 1059 Cutter cable came loose from DIN Reconnect cutter cable “Cutter does not respond” connector. connector to DIN connector. PX45 and PX65 Accessory User Guide...
