- Page 1 All manuals and user guides at all-guides.com LCD TELEVISION INSTRUCTION MANUAL DLM-26C3(AMBS/SMBS/LMBS/AMR/LMR/SMR) DLM-32C1(AMBS/SMBS/LMBS/AMR/LMR/SMR) DLM-3212(AMBS/SMBS/LMBS/AMR/LMR/SMR) DLM-32C3(AMBS/SMBS/LMBS/AMR/LMR/SMR) DLM-37C3(LMB) DLM-37C3(LMBS) DLM-42C1(LMR) DLM-42C4(LMR)
- Page 2 All manuals and user guides at all-guides.com Caution CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulat- ed “dangerous voltage”...
-
Page 3: Important Safeguards
All manuals and user guides at all-guides.com Important Safeguards Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. Read, Retain and Follow All Instructions Read all safety and operating instructions before operating the TV. Retain them safely for future reference. - Page 4 All manuals and user guides at all-guides.com Important Safeguards 13. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
- Page 5 All manuals and user guides at all-guides.com Warning This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user's own safety, and the proper operation of the product. In case of an accident, please unplug the unit from the outlet immediately.
- Page 6 All manuals and user guides at all-guides.com Warning This section must be read carefully and followed by the user prior to the operation of the product. The manual states important instructions for the user's own safety, and the proper operation of the product. Please keep the user's manual in a safe place for future reference.
-
Page 7: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents Installation and Maintenance Antenna Connection Video Connection Camcorder & Video Game Connection DVD Player Connection STB Connection PC Connection Cable TV Broadcasting Connection Connect with the Dolby Digital AMP Name of Each Part Basic Guide Parts of the Remote Controller Method To Use Basic Menu... -
Page 8: Supplied Accessories
All manuals and user guides at all-guides.com Supplied Accessories Make sure that the following accessories are provided with the product. AC cord AC cord Instruction manual Remote controller Batteries Microfiber sheet Cable holder (32/42C1 ONLY) Cover Bottom -When you install wall mounting you set up cover bottom like upper picture. -
Page 9: Antenna Connection
All manuals and user guides at all-guides.com Antenna Connection Indoor Antenna Connection 1. Connect the feeder cable of the antenna to the combining adapter. WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of wrong antenna connection. - Page 10 All manuals and user guides at all-guides.com Antenna Connection CTV Antenna Connection Such community TV Antenna installation may be found in most of co-op apartments. When a coaxial cable is used : Plug the coaxial cable to the antenna socket, and fix it firmly by turning it to the right.
- Page 11 All manuals and user guides at all-guides.com Antenna Connection Outdoor Antenna Connection Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses Single Antenna Connection VHF Antenna BACK OF THE TV SET UHF Antenna INPUT SERVICE INPUT HDMI AUDIO OPTICAL...
-
Page 12: Video Connection
All manuals and user guides at all-guides.com Video Connection Connecting with an External Source You may connect an S-Video input to enjoy clearer and brighter picture images. You can make the connection with the AV1,AV2 inputs. BACK OF THE TV SET INPUT SERVICE HDMI... -
Page 13: Camcorder & Video Game Connection
All manuals and user guides at all-guides.com Camcorder & Video Game Connection Watching the Camcorder Recording on TV 1. Prepare the S-video and RCA connector. 2. These connectors connect to S-Video1, S-Video2 or AV1, AV2 as shown in the picture below. 3. -
Page 14: Dvd Player Connection
All manuals and user guides at all-guides.com DVD Player connection When connecting with a component cable BACK OF THE TV SET INPUT SERVICE INPUT HDMI AUDIO OPTICAL DIGITAL MONITOR OUT L - AUDIO - R AUDIO VIDEO L - AUDIO - R S-VIDEO 1 COMPONENT Note :... -
Page 15: Stb Connection
All manuals and user guides at all-guides.com STB(Set Top Box) Connection When connecting with a HDMI cable BACK OF THE TV SET INPUT SERVICE INPUT HDMI AUDIO OPTICAL DIGITAL MONITOR OUT L - AUDIO - R AUDIO VIDEO L - AUDIO - R COMPONENT S-VIDEO 1 Set Top Box... - Page 16 All manuals and user guides at all-guides.com Connection When connecting with PC(D-Sub) cable. 1. First adjust resolution of the PC. (640 X 480, 800 X 600, 1024 X 768) 2. Connect between PC and TV set using the D-sub and Audio cable as shown in the picture below. 3.
-
Page 17: Pc Connection
All manuals and user guides at all-guides.com Connection PC CONNECTION NOTES: 1) The resolution of the TV set is best at 1024 768(XGA). 2) If there is a [Vertial Frequency] setting menu in the [Display] Menu of the PC, adjust the frequency to 60Hz. 3) If the PC resolution is too high, it may be hard to detect signals. -
Page 18: Cable Tv Broadcasting Connection
All manuals and user guides at all-guides.com Cable TV Broadcasting Connection External Input Connection Source Watching cable television is only possible after you have subscribed to the local broadcasting company and installed a cable receiver. You may make the connection to any of the Component input and input AV1, AV2. -
Page 19: Connect With The Dolby Digital Amp
All manuals and user guides at all-guides.com Connect with the Dolby Digital AMP If you connect the optical output to a Dolby digital AMP, you can listen to better sound. BACK OF THE TV SET INPUT SERVICE INPUT HDMI AUDIO OPTICAL DIGITAL MONITOR OUT... -
Page 20: Name Of Each Part
All manuals and user guides at all-guides.com Name of Each Part Front / Side Panel Buttons on the TV set have the same functions as those of the remote controller. MENU Front Panel Side Panel (Left) Side Panel (Right) Control Key Buttons. Buttons : Each time you press this button, the TV will cycle through: TV =>... - Page 21 All manuals and user guides at all-guides.com Name of Each Part Rear Panel INPUT SERVICE INPUT HDMI AUDIO OPTICAL DIGITAL MONITOR OUT L - AUDIO - R AUDIO VIDEO L - AUDIO - R COMPONENT S-VIDEO 1...
-
Page 22: Parts Of The Remote Controller
All manuals and user guides at all-guides.com Parts of the Remote Controller This remote controller is universal; thus, it may be convertible for TV, Video, CTV, etc. (MUTE) : Press this button, and the sound goes off. Press again, and the sound returns. (POWER) : TV on/off button in Stand-By mode. - Page 23 All manuals and user guides at all-guides.com Parts of the remote controller 18. DYNAMIC BASS : Using this button, you can enhance the bass. 19. 3D PANORAMA : Using this button, you can listen to MUTE POWER the virtual surround sound. : When sub screen is RF(TV) mode in the POP, P.PR PICTURE...
-
Page 24: Method To Use Basic Menu
All manuals and user guides at all-guides.com Method To Use Basic Menu Basic Menu - The basic menu appears on the screen if you press the “MENU” button of the remote control. - There are 5 items Picture, Screen, Sound, Function, and Install in the basic menu. - Each item has sub-items under it. -
Page 25: To Watch Tv
All manuals and user guides at all-guides.com To Watch TV On/Off, Number, Mute, Recall, ◀/▶, ▼/▲ - Buttons with same name in the main body performs the same function. Press the " " button of the front side of the set or MUTE POWER Remote controller . - Page 26 All manuals and user guides at all-guides.com To Watch TV 1. Press the “ ” button of the main body. • The Stand By LED lamp turns on in red colour. • Press “▼/▲” button of the main body or “POWER” button of the remote control.
-
Page 27: Setting Up Tv Stations
All manuals and user guides at all-guides.com Setting Up TV Stations Auto Tuning - All stations that can be received are stored by this method. It is recommended that you use Auto tuning during installation of this set. 1. Press the “MENU” button to select the Install menu. Mode Normal Brightness... - Page 28 All manuals and user guides at all-guides.com Setting Up TV Stations Manual tuning 1. Press the Number buttons(0~9) or the “▼PR▲” button to select a program number you want. MENU 2. Locate the selection bar on the Manual tuning at the Picture Install menu.
- Page 29 All manuals and user guides at all-guides.com Setting Up TV Stations Setup The Setup menu shows you information as follows: - Picture information: PAL, SECAM, and SECAM-L - Sound information: L, DK3, DK2, DK1, I, BG - Station name, Program number and Real channel number. 1.
- Page 30 All manuals and user guides at all-guides.com Setting Up TV Stations Edit The Edit menu shows you information as follows: - Program position assignment: Program number and Station name, Real channel number. - Skip information: Red (Skip Yes), White (Skip No) 1.
-
Page 31: Selection Of Av And Multimedia Input Signal
All manuals and user guides at all-guides.com Selection of AV and Multimedia Input Signal When watching video, Camcorder, DVD, Cable TV with AV - See page 12 for connection method of Camcorder and Video. - When pressing ” ” button on the TV set, screen changes as follows: TV =>... - Page 32 All manuals and user guides at all-guides.com Selection of AV and Multimedia Input Signal When connecting PC, STB, DVD with Multimedia 1. Pressing the "MULTIMEDIA" button on the remote controller. MUTE POWER • The screen changes as follows: PICTURE SOUND MULTIMEDIA PC =>...
-
Page 33: Screen Adjustment
All manuals and user guides at all-guides.com Screen Adjustment When setting up various screen modes - The user may select various screens designed for a good picture without adjusting the brightness, contrast or colour individually. 1. Pressing the “PICTURE” button. MUTE POWER •... - Page 34 All manuals and user guides at all-guides.com Screen Adjustment When adjusting the screen to taste - You can enjoy various screens by adjusting Brightness, Contrast, Colour, Sharpness, etc to the user’s taste. 1. Select "PICTURE" by pressing the "MENU" button. Mode Normal Brightness...
- Page 35 All manuals and user guides at all-guides.com Screen Adjustment Adjustment of Screen Size in TV and AV mode - Randomly change the size of the screen. PICTURE SOUND MULTIMEDIA - The AUTO screen operates when power is first turned on. ASPECT RECALL 1.
- Page 36 All manuals and user guides at all-guides.com Screen Adjustment Adjustment of the screen in the PC mode 1. Adjustment of the H-Position 16:9 Aspect H-Position • Move to H-Position in the Screen menu. Picture V-Position • Press the ”◀ ◀ VOL▶” buttons to adjust the horizontal MENU Phase Screen...
-
Page 37: Pop Mode
All manuals and user guides at all-guides.com POP Mode 1. POP mode when main picture is TV and AV. PREV PR • Press the "P.MODE" button, then POP mode will function. • Press the "P.STILL" button, then Sub screen will freeze. P.MODE P.STILL P.SWAP... -
Page 38: Sound Adjustment
All manuals and user guides at all-guides.com Sound Adjustment When selecting various sound modes 1. Sound mode selects what you want. MUTE POWER • Press the "SOUND" button, then the sound status changes as followed : PICTURE SOUND MULTIMEDIA Favourite => News => Music => Favourite ASPECT RECALL MENU... - Page 39 All manuals and user guides at all-guides.com Sound Adjustment When adjusting sound to taste - The user can enjoy various sounds by adjusting Sound Mode, Equalizer, 3D Panorama, Dynamic Bass and Balance. 1. To adjust the audio equalizer Mode Normal •...
- Page 40 All manuals and user guides at all-guides.com Sound Adjustment Multi-Sound and Stereo 1. Mono Sound Selection P.MODE P.STILL P.SWAP P.INPUT • During Stereo sound reception if the stereo is weak, you can switch DYNAMIC BASS 3D PANORAMA P.PR to MONO by pressing the button.
-
Page 41: Selection Of Language
All manuals and user guides at all-guides.com Selection of Language Selection of Language When you first turn on the TV set, the window of language selection is displayed automatically. 1. Press the “MENU” button and select "Function". Language Timer Picture Child Lock MENU Screen... -
Page 42: Adjustment Of Time
All manuals and user guides at all-guides.com Adjustment of Time Adjustment of Time - You must previously adjust current time in order to reserve Automatic On/Off. 1. Setting the Clock Clock 12 : 00 Picture Auto Colck • Move to Timer in the Function menu. Auto Colck Pr MENU Screen... - Page 43 All manuals and user guides at all-guides.com Adjustment of Time 4. Set up of Off Time Clock 12 : 00 Picture Auto Colck • Move to Timer in the Function menu. Auto Colck Pr MENU Screen Wake up • To go to the Off Timer, press the "▼PR▲" button. Wake up Time - - : - - Sound...
-
Page 44: Other Functions
All manuals and user guides at all-guides.com Other Functions 1. Setup of Child Lock Language • Move to Child Lock in the Function menu. Timer Picture Child Lock MENU • Select Child Lock to "On" using the “VOL▶” button Screen MGDI DEMO •... -
Page 45: Teletext
All manuals and user guides at all-guides.com Teletext Teletext SWITCHING TELETEXT ON/OFF Press the “TELETEXT” button ( The index page or the page viewed last will appear. Press the “TELETEXT” button again to return to the TV mode. NOTE: Teletext works only in TV/AV mode. COLOUR BUTTONS IN TOP/FLOF TELETEXT A red, green, yellow and blue field is shown at the bottom of the screen. -
Page 46: Troubleshooting
All manuals and user guides at all-guides.com Troubleshooting Symptoms and Solutions Please check the following list prior to calling Daewoo Electronics Service Centre for assistance Symptom Check items Neither picture - Check the contact of sockets is all right. nor sound - Check the TV main power is on. - Page 47 All manuals and user guides at all-guides.com Troubleshooting In PC mode Symptom Check items “OUT OF RANGE” - Check the resolution and frequency of your PC. Then, adjust them appears on the to optimum condition for LCD TV. screen - Refer to the table of PC mode input format (If registered resolution and frequency on the table no listed then no picture OUT OF RANGE will be displayed.)
-
Page 48: Standard Of Product
All manuals and user guides at all-guides.com Standard of Product Screen Size 26"(66Cm) 32"(81Cm) 37”(94Cm) 42”(106Cm) LCD Panel Aspect Ratio 16:9 16:9 16:9 16:9 Resolution 1366 x 768 (WXGA) 1366 x 768 (WXGA) 1366 x 768 (WXGA) 1366 x 768 (WXGA) Pixel Pitch 0.4215 mm 0.51075 mm... - Page 49 All manuals and user guides at all-guides.com 48586223E101-R4...
