- Page 1 P630 Plus-A Installation Guide Verifone Part Number: DOC562-004-EN-A, Revision A00 www.verifone.com...
- Page 2 The information contained in this document is subject to change without notice. Although Verifone has attempted to ensure the accuracy of the contents of this document, Verifone shall not be liable for technical or editorial errors or omissions contained herein. Verifone and the Verifone logo are registered trademarks of Verifone.
-
Page 3: Table Of Contents
Cable Connections ..........18 Attaching a Cable Connector to the P630 Plus-A ....19... - Page 4 Mounting Plate ............25 Attaching a Mounting Plate to P630 Plus-A ......25 Mounting P630 Plus-A with Mounting Plate to a Wall or Flat Surface.
- Page 5 Checking CTLS Reader ......... . . 36 © VeriFone, Inc. All rights reserved.
-
Page 6: Audience
Installation Guide P630 Plus-A Preface This guide is the primary source of information for setting up and installing the P630 Plus-A device. Audience This guide is intended for the users involved in P630 Plus-A installation. Organization This guide is organized as follows: •... -
Page 7: Conventions
The lightning symbol is used as a For safety, do not string cables or warning when bodily injury might cords across a walkway. occur. © VeriFone, Inc. All rights reserved. -
Page 8: Device Overview
P630 Plus-A 1. Device Overview The P630 Plus-A device is a consumer-facing handheld device. It may also be integrated into retail devices such as kiosks and as an indoor unattended device. The product’s design is equally appealing as a handheld PINpad and robust enough to look and function appropriately in a fixed mount setting. -
Page 9: Back Functions
Accept a wide range of payments, including mobile wallets and alternative payment methods, making transactions seamless anywhere. • Buzzer for audio confirmation of card transactions. Back Functions The P630 Plus-A includes the following features: • Cable connector compartment. • Threaded grommets for attaching the mounting plate. -
Page 10: Contactless Capability
Installation Guide P630 Plus-A • Simplifies and secures key injections through Verifone's Secure Kit key-loading software. Contactless • Future-proof your investment with an advanced contactless architecture Capability featuring a single contactless interface (SingleCl), SoftSAMs, and a side-by-side application architecture. •... -
Page 11: Device Setup
Installation Guide P630 Plus-A 2. Device Setup This section outlines the setup procedures for the P630 Plus-A, covering the following segments: • Safety Instructions • Contactless Considerations • PIN Protection Measures • Inside the Shipping Carton • Installing SAM Cards •... -
Page 12: Environmental Factors
Considerations non-metallic mounting plate. Using an enclosed metal frame or mount may negatively affect contactless performance. L'utilisation d'un cadre ou d'un support métallique fermé peut affecter négativement les performances sans contact. © VeriFone, Inc. All rights reserved. -
Page 13: Pin Protection Measures
PED and next in the queue Verifone also recommends instructions to the cardholder regarding safe PIN-entry. This can be done with a combination of: • Signage on the PED. • Prompts on the display, possibly with a click-through screen. -
Page 14: User Privacy
Lift and extract the inner carton box from the outer carton box once the tape is removed. Unfold the inner carton box. Conduct a detailed inspection of the shipping carton contents. The carton box includes the following components as part of the P630 Plus-A product: • Device •... -
Page 15: Inspecting The Features Of The Unit
CTLS functionality for contactless payments. Refer to "CTLS" for instructions on conducting contactless transactions. Installing SAM To install a SAM (Security Access Module) card in the P630 Plus-A, follow these steps: Cards Power off the device. Place the terminal face down on a soft and clean surface to protect the lens from scratches. -
Page 16: Power Supply
Power Supply Not all configurations and device contexts require the use of a power supply – Verifone ships the power supply with the terminal as required. Contact your Verifone representative if you have changed the context in which the terminal is used or have questions about which power supply should be used. - Page 17 When the terminal has power and an application is loaded, the application starts after the initial Verifone copyright screen and displays a unique copyright screen. If no application is loaded, DOWNLOAD NEEDED appears on the display after the initial Verifone copyright screen.
-
Page 18: Manual Startup/Shutdown
Installation Guide P630 Plus-A You can order the power pack from Verifone Online Store. Refer to Accessories and Cables for Part Number. Manual Press the power button on the left side for at least 8 seconds, until the device display turns off, to power off the P630 Plus-A device. -
Page 19: Attaching A Cable Connector To The P630 Plus-A
Installation Guide P630 Plus-A The cables first have to be attached to the P630 Plus-A. To attach a cable to Attaching a the terminal, follow the below steps: Cable Connector to the P630 Step 1: Release the screw. Step 2: Slide out the cable cover. - Page 20 Installation Guide P630 Plus-A P630 Plus-A, then insert the other end of the cable to the multi-communication port of V200c. Figure: 5 Plus-A via Serial Connection • Configuration 2 - P630 Plus-A Full Feature The PINpad accessories on the opposite side is to connect the PC and the Electronic Cash Register (ECR).
-
Page 21: Rs-232 Connection Using An External Power Brick
A special dongle cable is used, where one end of the cable plugs into the RS-232 P630 Plus-A while the other end terminates into the DB-9 connector Connection housing. On the housing, a DC jack is provided to connect to an external Using an power brick. - Page 22 MOD-8 socket for RS232, Mini USB, type A USB & DC-in jack The figure below shows the connections available on the external power brick. Figure: 8 Available Connections on the External Power Brick © VeriFone, Inc. All rights reserved.
-
Page 23: P630 Plus-A
If using a smart card, insert the card and follow the on-screen instructions before removing it. This process allows for the utilization of both magnetic stripe and smart cards with the device. © VeriFone, Inc. All rights reserved. -
Page 24: Optional Accessories
One type of privacy shield can be used. Standard Type - This privacy shield is PCI-compliant. This must be used when P630 Plus-A is not mounted on a swivel stand. Standard type privacy shield may be optionally used in attended handheld (or handover) mode, or... -
Page 25: Installing The Privacy Shield
Installation Guide P630 Plus-A when the P630 Plus-A is mounted on a swivel stand (as for a multilane environment), or when the P630 Plus-A is integrated into a kiosk and the kiosk has its own privacy shielding. Figure: 9 Standard... -
Page 26: Mounting P630 Plus-A With Mounting Plate To A Wall Or Flat Surface
Ensure the mounting plate is attached to the terminal. Mounting Plate Attach three M3 screws (not included in the P630 Plus-A package) to the to a Wall or Flat desired surface. Make sure that they are aligned with the slots on top and at the bottom of the mounting plate. - Page 27 Un cadre ou un support métallique fermé peut affecter négativement les performances du CTLS. Following are the guidelines for scanning a QR code using the bottom camera on a P630 Plus-A terminal: • Position the terminal Properly: Hold the QR code directly under the P630 Plus- A's bottom camera.
-
Page 28: Specifications
Installation Guide P630 Plus-A 3. Specifications This chapter provides details on the power requirements, dimensions, and additional specifications of the P630 Plus-A device. Unit Power • Full capabilities: 110V - 240V AC, 1A Requirement Temperature • 0°C to 50°C (32°F to 122°F) Operating temperature: •... -
Page 29: Primary Smart Card
Installation Guide P630 Plus-A Primary Smart • ISO 7816-3, 1.8V, 3V, 5V Card • Synchronous and Asynchronous cards • EMV Approved Security • 3DES and AES • PCI PTS 6.x approved © VeriFone, Inc. All rights reserved. -
Page 30: Maintenance And Cleaning
Verifone authorized service provider for maintenance or replacement. Cleaning & Verifone devices should only be gently cleaned to remove dirt, residue, or debris using a lightly water-damped, clean microfiber cloth. One or two Sanitizing drops of pH-neutral, non-scrubbing soap may be used. -
Page 31: Cleaning Instructions
Installation Guide P630 Plus-A Cleaning Turn off your device. Instructions Disconnect it from the power source. Clean it following the instructions and guidelines as mentioned above. Once completely dry, reconnect to power up. © VeriFone, Inc. All rights reserved. -
Page 32: Service And Support
Il est conseillé aux clients en dehors des États-Unis de contacter leur Verifone local représentant pour obtenir de l'aide concernant l'entretien, le retour ou le remplacement des appareils Et accessoires. - Page 33 • Reference the model and part number in the Note box. Each P630 Plus-A returned to Verifone requires a distinct MRA number to be issued. Even if you are returning multiple terminals of the same model, ensure that a separate MRA number is issued for each unit.
-
Page 34: Accessories And Cables
P630 Plus-A 6. Accessories and Cables Verifone provides a range of accessories and documentation for the P630 Plus-A. When placing orders, it is essential to reference the specific part numbers. Here are the available channels for ordering: Verifone online store: •... -
Page 35: Device Does Not Start
Utilizing services from unauthorized parties may potentially void any existing warranty. All units require the use of a power supply. Only use a Verifone-supplied power pack. Using an incorrectly rated power supply may damage the unit or cause it to malfunction. Ensure that the power supply used to power the unit matches... - Page 36 Installation Guide P630 Plus-A • If the problem persists, reach out to your local Verifone representative for assistance. Keypad Does Use the following steps to check the keypad: Not Respond • Check the display panel. If there are no characters, or the wrong characters are...
- Page 37 As commerce experts, we are here for you and your business. With our payment devices, our systems & solutions and our support. Everywhere. Anytime. So that your customers feel enabled, recognized and well taken care of, even beyond their expectations. Verifone. Creating omni-commerce solutions that simply shape powerful customer experiences.
