User's manual
Customer Service
US:1-800-645-2986
13,200BTU, 16,800BTU, 21,200BTU
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain
the product described. Protect yourself and others by observing all safety information. Failure to comply with
instructions could result in personal injury and / or property damage! Retain instructions for future reference.
Description
Global industrial Portable Air Conditioners feature spot cooling for large areas where cooling
of the entire area is not practical. A dedicated spot cooling thermostat controls the unit in
this application.
These air conditioners can also be used in smaller areas for room cooling.
A control panel provides ease of use and contains a self-diagnostic function and display,
showing operating modes, room and set temperatures, and faults.
If an abnormal operation occurs, a visual display of the fault is shown.
Caster wheels are included for easy portability. Suitable applications include: a factory or
work place, industrial kitchen, computer room, emergency cooling, outdoor event, etc.
Unpacking
After unpacking the unit, carefully inspect unit for any damage that may have occurred
during transit. Check for any loose, missing, or damaged parts.
Specifications
Model No.
Power Supply Ph-V-Hz
292660R
Single Phase, 115V, 60Hz
292661R
Single Phase, 115V, 60Hz
292662R
Single Phase, 220V, 60Hz
Model No.
292660R
292661R
292662R
Manual del usuario
Servicio de atención al Cliente
US: 1-800-645-2986
Portable Air Conditioners,
Model : 292660R / 292661R / 292662R
Cooling Capacity
Power Cord Gauge
Nema Plug
5-15P
5-20P
6-15P
Power Consumption
Btu/h
Watts
12,000
1,100
16,800
1,340
21,200
1,970
Power Cord Length ft
AWG
14
10
12
8
14
10
- 1 -
Manuel de l'utilisateur
Service à la clientèle
Canada: 888-645-2986
292660R/292661R/292662R
Figure 1
Rated Current Amps
EER Btu/Wh
9.9
10.9
11.75
12.5
8.98
10.8
Dimensions
W x D x H - in. (mm)
20.5 x 26.4 x 41
(520 x 670 x 1042)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Global Industrial 292660R
Summary of Contents for Global Industrial 292660R
- Page 1 / or property damage! Retain instructions for future reference. Description Global industrial Portable Air Conditioners feature spot cooling for large areas where cooling of the entire area is not practical. A dedicated spot cooling thermostat controls the unit in this application.
- Page 2 Thank you for selecting this Global Portable Air Conditioner. It provides you with spot cooling for large areas where cooling of an entire area is not practical or possible. Please read this manual before installing the 292660R, 292661R, 292662R as it provides important information that should be followed during installation and maintenance of the Portable Air Conditioner, allowing you to correctly set up your system for the maximum safety and performance.
-
Page 3: General Safety Information
Consult a local qualified lectrician and all local electrical codes to ensure proper setup. Any extension cord used with this device must be rated for a minimum of 292660R/ 292662R(10A), 292661R (15A).(220V) 18. -
Page 4: Work Procedure
Portable Air Conditioner 28. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 5 Portable Air Conditioner Qualification of workers – Use caution while handling and prevent damage to unit. Do not put any holes into product for any reason. This can cause damage to product and prevent unit from cooling. – Service should only be performed by technicians properly trained and certified in the use of flammable refrigerants. Any service performed by unauthorized servicers/individuals will void all warranties.
-
Page 6: Repair To Intrinsically Safe Components
Portable Air Conditioner Checks to the refrigerating equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt, consult the manufacturer’s technical department for assistance. -
Page 7: Detection Of Flammable Refrigerants
Portable Air Conditioner Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used. The following leak detection methods are deemed acceptable for all refrigerant systems. -
Page 8: Charging Procedures
Portable Air Conditioner a) Become familiar with the equipment and its operation. b) Isolate system electrically. c) Before attempting the procedure, ensure that: • mechanical handling equipment is available, if required, for handling refrigerant cylinders; • all personal protective equipment is available and being used correctly; •... -
Page 9: Component Parts
Portable Air Conditioner Assembly COMPONENT PARTS Top fan exhaust flange Cool air outlet hose Display / Control board Condenser / filter Guide bar for condensate Power cord holder water tank Electrical access panel Condensate water tank (Water level is sensed, and the unit operation is Caster stopped when tank is full. -
Page 10: Moving The Unit
Portable Air Conditioner Installa�on Only operate in the upright posi�on on a flat level surface, with a minimum of 24 inches from all walls or any objects. (See Figure 8) Figure 7 WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION Do not use the unit in explosive environments or in areas where flammable gas leakage may occur. -
Page 11: Operation
Portable Air Conditioner Operation CONTROL PANEL Figure 8 · Press the power button for 0.5 seconds to activate the product. · Press the power button for 0.5 seconds while driving to stop the product. · Self-diagnosis will be performed to test for abnormalities, after marking “VER” for 3seconds when power is “ON”. - Page 12 Portable Air Conditioner 1) Cooling mode (SPOTCOOL Mode) · The basic operation is based on “out” control. (discharge temperature TH1) · On/off the operation of the compressor. (COOL ↔ BLOWER) · The set temperature cannot be changed and it operates which is set to 0 degrees Celsius. 2) Cooling mode (ROOMCOOL Mode) ·...
-
Page 13: Maintenance
Portable Air Conditioner Maintenance FILTER CLEANING (See Figures 10 and 11) There are three filters in the unit. The evaporator filter is located at the front of the unit. The condenser filters are located at the side of the unit. 1. -
Page 14: Wiring Diagram
FAN' Block MOTOR L - 1 COMP' N - 1 Figure 11 - Circuit Wiring Diagram (292660R/292661R/292662R) 1. 재질 : 은무데드롱 25미크론 2. 인쇄방법: 씨링인쇄 3. 인쇄색상: 흑색 1도 4. 표면처리: 라미네이팅(OPP코팅) 5. 인쇄기준 : 도면 및 설계 제공 필름... - Page 15 Portable Air Conditioner SELF-DIAGNOSTIC ALARM CODES Alarm Display Problem Cause Corrective Action • Do not use the air conditioner if ambient • Ambient temperature is too high Compressor temperature is higher than 45°C (113°F) • Unstable voltage supply overloaded • Contact a qualified service agent •...
-
Page 16: Troubleshooting Chart
Portable Air Conditioner Troubleshooting chart Symptom Possible Cause(s) Corrective Action Position issue / Damage 1. Check the water tank is placed on the correct position Replace the damaged water tank with the new one. 2. Remove any object stuck underneath the Drain Pan underneath the water tank Water leakage FT sensor error...
