- Page 1 User's manual Manual del usuario Manuel de l'utilisateur Customer Service Servicio de atención al Cliente Service à la clientèle US: 1-800-645-2986 Canada: 888-645-2986 US: 1-800-645-2986 Global Industrial™ Portable Spot Cooler Air Conditioner, 6,475 BTU, 115V Model: 293117 MODEL # 293117...
-
Page 2: Safety Precautions
User Manual Portable Spot Cooler AC Safety Precautions NOTE: Be sure to follow the safety precautions to prevent accidents or dangers in advance by using the product safely and correctly. When using an extension cord, check the current of the Use the rated voltage marked on the side of the air product being used and use a cord that meets the conditioner;... -
Page 3: Notes On Installation
User Manual Portable Spot Cooler AC Safety Precautions (Cont'd) NOTE: Be sure to follow the safety precautions to prevent accidents or dangers in advance by using the product safely and correctly. Do not disassemble, repair, or remodel. There is a risk of Do not move the product while it is in operation. -
Page 4: Connecting To Power
User Manual Portable Spot Cooler AC Notes on Installation (Cont'd) Transporting Product • Operate product on a flat surface. • There may be residual moisture inside the product. When moving the product, be sure to empty the water tank and be careful not to fall or collide. Connecting to Power •... - Page 5 User Manual Portable Spot Cooler AC Product Diagram & Parts (Cont'd) How to Install Duct Hose After inserting the elbow pipe (A) into the connection part (B) of the body, tighten the lever handle under the duct (A) by turning it counterclockwise. After inserting the duct hose (C) into the duct (A), turn it to the left to fasten it.
-
Page 6: Wiring Diagram
User Manual Portable Spot Cooler AC Wiring Diagram switch terminal numbering LAMP EVA' MOTOR Power COND' 1P AC 100 / 115V, MOTOR 50/60Hz COMP' Operating Location Precautions • When using the product, the air intake and bellows hose must be kept at least 1 foot away from the wall or any other obstacles. -
Page 7: Troubleshooting
User Manual Portable Spot Cooler AC Maintenance and Storage (Cont'd) Machine Body Cleaning • Clean the main body only. Do not attempt to take machine apart. • Moisten a soft cloth with water or neutral detergent, etc., and spot clean any contaminated areas. •... -
Page 8: Product Specifications
User Manual Portable Spot Cooler AC Product Specifications Specification 293117 Voltage 115V / 60Hz Cooling Capacity 6,745 BTU (2000W) Power Consumption 720W Rated Current 6.38A Refrigerant R410A (330g) Weight 53 lbs Dimension 19x11x22...
