User's manual
Customer Service
US:1-800-645-2986
Portable Air Conditioner, 7.5 Ton, 92,000 BTU
Read all instructions carefully before attempting to assemble, install, operate or maintain this air conditioner.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in
personal injury and / or property damage, and will void warranty. Save instructions for future reference.
Description
Global Industrial portable air conditioners are designed for spot cooling in large areas
where cooling the entire space is impractical. A dedicated thermostat specifically for
spot cooling controls the unit in this application. These air conditioners can also be used
in smaller spaces for general room cooling.
The control panel is user-friendly, featuring a self-diagnostic function and display that
shows operating modes, room and set temperatures, as well as any faults. If an
abnormal operation occurs, the fault is visually displayed. The units come with caster
wheels for easy mobility. They are suitable for various applications such as factories,
industrial kitchens, computer rooms, emergency cooling, outdoor events, and more.
Unpacking
After unpacking the unit, carefully inspect the machine for any damage that may have
occurred during transit. Check for any loose, missing, or damaged parts.
Specifications:
Model No.
Power Supply Ph-V-Hz
604217
3 phases, 460V, 60Hz
Dimensions W x D x H
Model No.
Weight (Net / Gross)
28.9 "x 51.6" x 59.8"
604217
760.6 lbs. / 793 lbs.
Manual del usuario
Servicio de atención al Cliente
US: 1-800-645-2986
Model: 604217
Cooling
Power Consump-
Capacity Btu/h
92,000
No. of Cool Air
Condensate tank
Outlets Pcs
3
- 1 -
Manuel de l'utilisateur
Service à la clientèle
Canada: 888-645-2986
EER Btu/
ti on Watt s
Wh
10,500
8.76
Ambient temperature range
Gallons(Liters)
Auto Pump
64~113 (18~45)
Included
604217
Figure 1
Rated Cur-
rent Amps
16.5
°F (°C)
Advertisement
Table of Contents
Related Manuals for Global Industrial 604217
Summary of Contents for Global Industrial 604217
- Page 1 / or property damage, and will void warranty. Save instructions for future reference. Description Global Industrial portable air conditioners are designed for spot cooling in large areas where cooling the entire space is impractical. A dedicated thermostat specifically for spot cooling controls the unit in this application.
- Page 2 Portable Air Conditioner Specifications (continued): Setting temperature Setting temperature (Spot Model No. (Room cool mode) °F( °C) cool mode) °F( °C) 604217 64~86 (18~30) 32~86 (0~30) Application Area Refrigerant Design Pressure - Hi/Low Model No. (Room cool mode) ft² Type / oz(g)
-
Page 3: Component Parts
Portable Air Conditioner DO NOT operate a unit with a damaged power cord. 19. The filters must be used with the product at all times. When the filters are removed for clean-ing, always ensure that the unit has been turned off and unplugged from the electrical outlet. 20. -
Page 4: Installation
Portable Air Conditioner Installation Only operate in the upright position on a flat level surface, with a minimum of 24 inches from all walls or any objects. (See Figure 8) Figure 8 WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION Do not use the unit in explosive environments or in areas where flammable gas leakage may occur. -
Page 5: Control Panel
Portable Air Conditioner Operation CONTROL PANEL Figure 9 - Control Panel POWER BUTTON • Activates unit when POWER BUTTON is pressed. • Fan starts on low speed. • If POWER BUTTON is pressed during operation, unit stops. BLOWER BUTTON • Changes fan speed from LOW to HIGH when pressed. -
Page 6: Maintenance
– To ensure your product is covered by warranty, the complete faulty product along with your original purchase receipt must be provided at the place of purchase. Wiring Diagram Figure 12 - Circuit Wiring Diagram (604217) High Pressure Switch Drain... -
Page 7: Self Diagnostic Codes
Portable Air Conditioner SELF-DIAGNOSTIC CODES (See Table 1) The alarm light is activated if abnormal operation occurs, and a code is displayed on the control panel. The compressor and condenser fan motor will stop operating. The evaporator fan will con-tinue to run for 3 minutes. If the fault is rectified within 3 minutes, the unit will resume opera-tion. -
Page 8: Troubleshooting
Portable Air Conditioner Troubleshooting Possible Cause(s) Corrective Action Symptom 1. Check and remove any High water level blockage from drain hose Water leakage in condensate 2. Remove any objects stuck tank beneath the black panel under the water tank 1. Check the buildings 1.
