User's manual
Customer Service
US:1-800-645-2986
Outdoor Rated Portable Air Conditioner,
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain
the product described. Protect yourself and others by observing all safety information. Failure to comply with
instructions could result in personal injury and / or property damage! Retain instructions for future reference.
Description
Global Industrial Portable Air Conditioners are specialized for "SPOT COOLING" where
central cooling is impractical. These air conditioners can also be used in enclosed areas
just like conventional air conditioners. Simple digital controller and self-diagnostic
functions allow users to easily operate the unit. Built-in caster wheels enable users to
move the unit without any hassle. The unit can be installed within 5 minutes and does not
require any extra materials or certified technician for installation.
Unpacking
After unpacking the unit, carefully inspect unit for any damage that may have
occurred during transit. Check for any loose, missing, or damaged parts.
Specifications
Model No.
Power Supply Ph-V-Hz
293119R
3 Phases - 460V - 60Hz
Weight (Net / Gross)
Model No.
1168/1245lbs.
293119R
(530/565kg)
Manual del usuario
Servicio de atención al Cliente
US: 1-800-645-2986
12 Tons, 144,400 BTU
Model : 293119R
Cooling Capacity Btu/h
Ambient temperature
Lbs(kg)
range °F( °C)
64~113(18~45)
Power Consumption
144,400
16.46 kW
- 1 -
Manuel de l'utilisateur
Service à la clientèle
Canada: 888-645-2986
293119R
Figure 1
Rated Current Amps
Watts
26.4 A
Dimensions
W x D x H - in. (mm)
34.3 x 75 x 71
(870 x 1904 x 1801 )
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Global Industrial 293119R
Summary of Contents for Global Industrial 293119R
- Page 1 / or property damage! Retain instructions for future reference. Description Global Industrial Portable Air Conditioners are specialized for “SPOT COOLING” where central cooling is impractical. These air conditioners can also be used in enclosed areas just like conventional air conditioners.
-
Page 2: General Safety Information
Portable Air Conditioner Model No. Indoor Air Flow CFM Refrigerant Type / oz(g) 293119 4000 R454B / 246.9 (7000) Compressor overload protector, Anti-freezing thermistor, Automatic restart Safety Devices (power interruption), Compressor time delay program, High pressure switch Temperature control, Self-diagnostic function, Features Optional drain pump kit, Washable filters, °F or °C display, Off-timer The unit is integrated with “PUMP-DOWN”... - Page 3 Portable Air Conditioner DO NOT use the unit in wet environments, such as a laundry room, to avoid the risk of electrical shock. 10. DO NOT place any foreign objects on the unit. 11. DO NOT operate the unit with wet or damp hands. 12.
-
Page 4: Work Procedure
Portable Air Conditioner WARNING – Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. – The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater.) –... - Page 5 Portable Air Conditioner Qualification of workers – Use caution while handling and prevent damage to unit. Do not put any holes into product for any reason. This can cause damage to product and prevent unit from cooling. – Service should only be performed by technicians properly trained and certified in the use of flammable refrigerants. Any service performed by unauthorized servicers/individuals will void all warranties.
-
Page 6: Repair To Intrinsically Safe Components
Portable Air Conditioner Checks to the refrigerating equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer’s maintenance and service guidelines shall be followed. If in doubt, consult the manufacturer’s technical department for assistance. -
Page 7: Detection Of Flammable Refrigerants
Portable Air Conditioner Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used. The following leak detection methods are deemed acceptable for all refrigerant systems. - Page 8 Portable Air Conditioner Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant.
-
Page 9: Portable Air Conditioner
Portable Air Conditioner Assembly COMPONENT PARTS Controls Emergency Stop Figure 3 Controls Hot Air Exhaust Electrical Panel Cold Air Inlet Cold Air Inlet Filter Figure 2 I BOLT Front and Right Side View Handle Caster Figure 4 Condensate Outlet Casters can be locked by locking the break down Figure 6 CAM LOCK Figure 5... -
Page 10: Duct Connections
Portable Air Conditioner DUCT CONNECTIONS Cool Air Out Duct(EVA) The Cool air duct connections are labeled “AIR OUT”. The connection size is 350Ø in diameter. Connect the flexible air ducting as follows: 1. Attach the flexible air ducting to the unit’s duct collars making sure that air will not leak past the connection collar by using appropriate round flexible ducting clamps. -
Page 11: Installation
Portable Air Conditioner Installation WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION Do not use the unit in explosive environments or in areas where flammable gas leakage may occur. Do not use the unit in areas where it will be exposed to rain or water. Do not use the unit in a corrosive atmosphere. -
Page 12: Operation
Portable Air Conditioner Operation CONTROL PANEL Figure 9 · Press the power button for 0.5 seconds to activate the unit. · Press the power button for 0.5 seconds while running to stop the unit. · Self-diagnosis will be performed to test for abnormalities, after marking “VER” for 3 seconds when power is “ON”, the blower is set to “High”, and the compressor is operated after 1 minute. - Page 13 Portable Air Conditioner 1) Cooling mode (SPOTCOOL Mode) · The basic operation is based on “out” control. (discharge temperature TH1) · On/off the operation of the compressor. (COOL ↔ BLOWER) The set temperature cannot be changed and it operates which is set to 32°F (0°C). ·...
-
Page 14: Maintenance
Portable Air Conditioner Maintenance FILTER CLEANING (See Figures 10 and 11) 1. Loosen up 6 bolts on the front filter guard. 2. Slide filter up and use a vacuum cleaner to remove the dust from the filter. 3. If the filter is heavily covered with dust and dirt, warm water and mild soap or neutral detergent may be used to wash the filter. -
Page 15: Wiring Diagram
Portable Air Conditioner 01 WPC-36003 회로도 Wiring Diagram WPC-36003 SLT 통합 PCB Drain Pump (Option) Display & Control Phase Protector (Emergency Stop) R (L1) A (NO) B (NC) S (L2) C (CM) T (L3) MCCB 220V 380-460V Solenoid Valve Power (Pump Down) 3P AC 460V-60Hz 3P AC 380V-50Hz... - Page 16 Portable Air Conditioner SELF-DIAGNOSTIC ALARM CODES Alarm Display Problem Cause Corrective Action • Do not use the air conditioner if ambient • Ambient temperature is too high temperature is higher than 113°F (45°C) Compressor • Unstable voltage supply overloaded • Contact a qualified service agent •...
-
Page 17: Troubleshooting Chart
Portable Air Conditioner Troubleshooting chart Symptom Possible Cause(s) Corrective Action Position issue / 1. Check the water tank is placed on the correct Damage position Replace the damaged water tank with the new one. 2. Remove any object stuck underneath the Drain Pan underneath the water tank Water leakage Drain pump issue... - Page 18 Portable Air Conditioner Troubleshooting chart Symptom Possible Cause(s) Corrective Action Compressor will not work 1. Wait 3 minutes after unit is turned off if the unit is turned off and before turning the unit back on. on quickly. 2. Check the Cool Icon If the light is off, A/C will be activated after light is on.
- Page 19 - 19 -...
- Page 20 - 20 -...
