Safety and operating instructions
Handheld hydraulic breakers
BRK 25, 40, 55, 70, 95
www.cp.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BRK 25 and is the answer not in the manual?

Questions and answers

Related Manuals for Chicago Pneumatic BRK 25

Summary of Contents for Chicago Pneumatic BRK 25

  • Page 1 Safety and operating instructions Handheld hydraulic breakers BRK 25, 40, 55, 70, 95 www.cp.com...
  • Page 2 BRK 25, 40, 55, 70, 95 3392 5166 01d | Original instructions...

  • Page 3: Table Of Contents

    BRK 25, 40, 55, 70, 95 Contents Contents Introduction............... 5 About the Safety and operating instructions.
  • Page 4 Safety and operating instructions BRK 25, 40, 55, 70, 95 3392 5166 01d | Original instructions...

  • Page 5: Introduction

    BRK 25, 40, 55, 70, 95 Safety and operating instructions Introduction Thank you for choosing Chicago Pneumatic brand products. For over a century, the Chicago Pneumatic brand has represented performance and innovation in the pneumatic tool industry. Today the brand is found around the world on a range of pneumatic and hydraulic tools that includes breakers, rock drills, chipping hammers, clay-diggers, picks and busters, scabblers, pumps and a whole lot more.

  • Page 6: Safety Instructions

    Safety and operating instructions BRK 25, 40, 55, 70, 95 Drugs, alcohol or medication Safety instructions WARNING Drugs, alcohol or medication To reduce the risk of serious injury or death to Drugs, alcohol or medication may impair your yourself or others, read and understand the Safety judgment and powers of concentration.

  • Page 7: Operation, Precautions

    BRK 25, 40, 55, 70, 95 Safety and operating instructions WARNING Hydraulic oil at high WARNING Operating pressure pressure If the maximum operating pressure for the hydraulic Thin jets of hydraulic oil under high pressure can machine is exceeded, the accumulator can be over penetrate the skin and cause permanent injury.
  • Page 8 Safety and operating instructions BRK 25, 40, 55, 70, 95 ► Select, maintain and replace consumables/ WARNING Dust and fume hazard working tools/ other accessories as recommended Dusts and/or fumes generated or dispersed when in the operating and safety instructions. Incorrect...
  • Page 9 BRK 25, 40, 55, 70, 95 Safety and operating instructions WARNING Splinters hazard WARNING Vibration hazards Using the insertion tool as a hand struck tool can Normal and proper use of the machine exposes the result in splinters hitting the operator and can cause operator to vibration.

  • Page 10: Maintenance, Precautions

    Safety and operating instructions BRK 25, 40, 55, 70, 95 ► Participate in health surveillance or monitoring, WARNING Noise hazard medical exams and training programs offered by High noise levels can cause permanent and disabling your employer and when required by law.

  • Page 11: Overview

    Pneumatic hydraulic power packs or, by means of for the work to be performed. a Chicago Pneumatic OFD oil flow divider, with most A breaker that is too small means that the work will hydraulic excavators, backhoe loaders and tractors.

  • Page 12: Noise Level Label

    Safety and operating instructions BRK 25, 40, 55, 70, 95 The warning symbol together with the book symbol means that the user must read the safety and operating instructions before the machine is used for the first time. Serial number (is also stamped in the valve housing).

  • Page 13: Installation

    To resist exterior wear and tear, we recommend using a 2-layer hydraulic hose. The At delivery, breakers BRK 25 D, BRK 40 and BRK 40 machine connection marked P (pump) is the oil inlet, VR are factory set to 20 l.p.m (EHTMA C). They can and the connection marked T (tank) is the oil outlet.

  • Page 14: Insertion Tool

    Safety and operating instructions BRK 25, 40, 55, 70, 95 5. Move the seal from the old nipple to the new Oil flow rate nipple. Apply Loctite 245 and fit the nipple. 20 l.p.m 25 l.p.m 30 l.p.m 35 l.p.m 40 l.p.m...

  • Page 15: Operation

    BRK 25, 40, 55, 70, 95 Safety and operating instructions 1. To prevent an accidental start: switch off the WARNING Vibration hazard power supply and bleed the machine by Using inserted tools that do not fulfil the criterias pressing the start and stop device. Disconnect mentioned below, will result in a longer time to the machine from the power source.

  • Page 16: Operating

    Safety and operating instructions BRK 25, 40, 55, 70, 95 Stop ♦ Never break off too large pieces. Adjust the breaking distance (A) so that the inserted tool > Release the trigger. Press the breaker against the does not get stuck.

  • Page 17: When Taking A Break

    BRK 25, 40, 55, 70, 95 Safety and operating instructions ♦ Never use the machine as a hand held impact tool. ♦ If the machine has a vibration-absorbing handle, check that it moves freely (up and down) and Ensure that the work piece is securely fixed.

  • Page 18: Disposal

    Safety and operating instructions BRK 25, 40, 55, 70, 95 Disposal A used machine must be treated and scrapped in such a way that the greatest possible portion of the material can be recycled and any negative influence on the environment is kept as low as possible.

  • Page 19: Technical Data

    BRK 25, 40, 55, 70, 95 Safety and operating instructions Technical data Troubleshooting Problem Cause Solution Breaker does not work. Pressure is not built No or incorrect flow/pressure Check flow/pressure by means of test up when trigger is activated equipment P and T hoses interchanged Check connection.
  • Page 20 BRK type (Bar) (Bar) (Bar) BRK 25 D, BRK 40, BRK 40 VR BRK 55, BRK 55 VR, BRK 70, BRK 70 VR, BRK 95, BRK 95 VR BRK 55 HBP, 55 VR HBP, BRK 70 HBP, BRK 70 VR HBP...

  • Page 21: Noise And Vibration Declaration Statement

    BRK type (psi) (psi) (psi) BRK 25 D, BRK 40, BRK 40 VR 2500 2000 BRK 55, BRK 55 VR, BRK 70, 2500 2000 BRK 70 VR, BRK 95, BRK 95 VR BRK 55 HBP, 55 VR HBP, BRK...

  • Page 22: Noise And Vibration Data

    Type rel 20µPa factor dB(A) dB(A) rel 1pW BRK 25 D (Hex 25x82.5, 20 lpm) 16.5 BRK 40 (Hex 25x108, 20 lpm ) 15.1 BRK 40 (Hex 28x160, 20 lpm ) 14.9 BRK 40 (Hex 32x152, 20 lpm ) 14.9...
  • Page 23 BRK 25, 40, 55, 70, 95 Safety and operating instructions Noise Vibration Sound pressure Sound power Three axes values Declared values Declared values EN ISO 11203 2000/14/EC EN ISO 28927-10 r=1m dB(A) uncertainty guaranteed value spreads Type rel 20µPa factor dB(A)
  • Page 24 Safety and operating instructions BRK 25, 40, 55, 70, 95 Noise Vibration Sound pressure Sound power Three axes values Declared values Declared values EN ISO 11203 2000/14/EC EN ISO 28927-10 r=1m dB(A) uncertainty guaranteed value spreads Type rel 20µPa factor dB(A)

  • Page 25: Ec Declaration Of Conformity

    BRK 25, 40, 55, 70, 95 Safety and operating instructions EC Declaration of Conformity EC Declaration of Conformity (EC Directive 2006/42/EC) We, Construction Tools EOOD, hereby declare that the machines listed below conform to the provisions of EC Directive 2006/42/EC (Machinery Directive) and 2000/14/EC (Noise Directive), and the harmonised standards mentioned below.
  • Page 26 BRK 25, 40, 55, 70, 95 3392 5166 01d | Original instructions...
  • Page 27 BRK 25, 40, 55, 70, 95 3392 5166 01d | Original instructions...
  • Page 28 2014-05 | No. 3392 5166 01d © Copyright Construction Tools EOOD...
