  • Page 1 People. Pneumatic Breakers Passion. for Demolition and Construction Performance.
  • Page 2 A pneumatic breaker should be robust and reliable yet easy to use. That’s exactly what you get with the new generation of CP breakers. These demolition tools deliver the power and durability you demand for tough jobs including breaking reinforced concrete, heavy road work, trenching, and cutting tarmac or frozen ground.
  • Page 4 Engineered for High Performance Chicago Pneumatic construction tools are known for their pioneering design, high-impact technology and durability. We listen to our customers, watch how the products are used, and never stop working to develop new features that make our tools more comfortable and efficient on the job.
  • Page 5 mOrE POwEr CP 1260 and lighTEr CP 1290 Breakers wEighT aPPliCaTiOnS: Tough construction and plant maintenance work such as breaking reinforced concrete, heavy road work, cutting tarmac, frozen ground or non-consolidated rock and for general demolition work. These new 60-pound and 90-pound breakers continue the tradition of the well-known CP 1230 and CP 1240 with outstanding robustness and reliability in tough working conditions.
  • Page 6 muFFlEr CP 1260 and inCluDED huShED CP 1290 Spike Drivers POwEr aPPliCaTiOnS: Used for driving spikes in railroad, construction and plant maintenance applications and in tent erection. These specialized spike drivers are built to the same exacting specifications as our heavy duty pneumatic breakers, but with an open front head without tool retainer.
  • Page 7 CP 0117 Breakers aPPliCaTiOnS: Used in heavy breaker applications. Drawing on traditional breaker design, these heavy breakers are hard-hitting, but with a somewhat lower weight, impact rate and power than the CP 1290. With their lower air consumption and powerful blow, they are used for heavy applications.
  • Page 8 They are also often found on bridge deck jobs. Although classed as a 35-pound tool, the CP 1210 offers the hitting power and high performance of a larger tool. There are also a number of different shank sizes and shank configurations available.
  • Page 9 CP 0112 Breakers aPPliCaTiOnS: Used in light construction work and plant maintenance including light demolition of floors, pavement and masonry walls and breaking of frozen ground. They are also popular for bridge deck jobs. The CP 0112 breakers are the lightest in the CP range and are ideal for situations where easy handling and weight restrictions are important issues.
  • Page 10 Just as Chicago Pneumatic tools and equipment are built for hard work in real-world conditions, original CP accessories enhance the tools to fit your needs. These parts and accessories offer the quality and reliability you need to get the most from your equipment for years to come.
  • Page 11 Driver Pad, Round – 3371 8060 12 Posthole Pad – 9245 2822 30 iSO STanDarD hEX 28 x 160 mm — CP 1210, CP 1260, CP 1290, CP 0117 Moil Point – 3083 3271 00 Moil Point – 3083 3272 00 Moil Point –...
  • Page 12 Safety and operating instructions Handheld pneumatic breakers CP 1210, CP 1260, CP 1290...
  • Page 13 CP 1210, CP 1260, CP 1290 Safety and operating instructions Introduction Thank you for choosing Chicago Pneumatic brand products. For over a century, the Chicago Pneumatic brand has represented performance and innovation in the pneumatic tool industry. Today the brand is found around the world on a range of pneumatic and hydraulic tools that includes breakers, rock drills, chipping hammers, clay-diggers, picks and busters, scabblers, pumps and a whole lot more.

  • Page 14: Safety Instructions

    Safety and operating instructions CP 1210, CP 1260, CP 1290 Drugs, alcohol or medication Safety instructions WARNING Drugs, alcohol or medication To reduce the risk of serious injury or death to Drugs, alcohol or medication may impair your yourself or others, read and understand the Safety judgment and powers of concentration.

  • Page 15: Operation Precautions

    CP 1210, CP 1260, CP 1290 Safety and operating instructions WARNING Ejected insertion tool WARNING Unexpected movements If the tool retainer on the machine is not in a locked The inserted tool is exposed to heavy strains when position, the inserted tool can be ejected with force, the machine is used.
  • Page 16 Safety and operating instructions CP 1210, CP 1260, CP 1290 Select, maintain and replace consumables/ ► WARNING Dust and fume hazard working tools/ other accessories as recommended Dusts and/or fumes generated or dispersed when in the operating and safety instructions. Incorrect...
  • Page 17 CP 1210, CP 1260, CP 1290 Safety and operating instructions WARNING Splinters hazard WARNING Vibration hazards Using the insertion tool as a hand struck tool can Normal and proper use of the machine exposes the result in splinters hitting the operator and can cause operator to vibration.
  • Page 18 Safety and operating instructions CP 1210, CP 1260, CP 1290 Participate in health surveillance or monitoring, ► WARNING Noise hazard medical exams and training programs offered by High noise levels can cause permanent and disabling your employer and when required by law.

  • Page 19: Maintenance Precautions

    CP 1210, CP 1260, CP 1290 Safety and operating instructions Maintenance, precautions WARNING Machine modification Any machine modification may result in bodily injuries to yourself or others. Never modify the machine. Modified machines ► are not covered by warranty or product liability.

  • Page 20: Main Parts

    Design and function These instructions are valid for the CP 1210, CP 1260 and CP 1290. The CP 1210, CP 1260 and CP 1290 are designed for medium to heavy demolition of materials such as concrete and asphalt. The pneumatic breakers are designed for vertical use.

  • Page 21: Data Plate

    CP 1210, CP 1260, CP 1290 Safety and operating instructions To avoid injury, before using or servicing tool, read Labels and understand separately provided safety instructions. The machine is fitted with labels containing important information about personal safety and machine maintenance. The labels must be in such condition that they are easy to read.

  • Page 22: Installation

    Safety and operating instructions CP 1210, CP 1260, CP 1290 Installation Connecting a water separator Hoses and connections The length of the air hose between the compressor and the water separator must be such that the water vapour is cooled and condenses in the hose before reaching the water separator.

  • Page 23: Insertion Tool

    CP 1210, CP 1260, CP 1290 Safety and operating instructions Narrow chisel The narrow chisel is used for demolition and cutting work in concrete and other types of hard materials. Moil point The moil point is only used for making holes in concrete and CP 1260, CP 1260 S, CP 1290 and CP 1290 S other types of hard materials.

  • Page 24: Start And Stop

    Safety and operating instructions CP 1210, CP 1260, CP 1290 Use the gauge that corresponds to the insertion Start and stop tool s shank dimension. See section "Technical data" for correct tool shank dimensions. > Check if the gauge s hole (A) can be pushed down...

  • Page 25: When Taking A Break

    CP 1210, CP 1260, CP 1290 Safety and operating instructions Breaking Let the machine do the work; do not press too ♦ hard. The vibration-reducing handle must absolutely not be pressed all the way down to the base. For pneumatic breakers with vibration-reducing ♦...

  • Page 26: Maintenance

    Safety and operating instructions CP 1210, CP 1260, CP 1290 Too big a clearance between the insertion tool´s Maintenance ♦ shank and the chisel bushing will generate increased vibrations. To avoid getting exposed to Regular maintenance is a basic requirement for the excessive vibrations, check the chisel bushing for continued safe and efficient use of the machine.
  • Page 27 See illustration below (valid for CP throttle to avoid damage to piston, anvil block 1210 SVR, CP 1260 SVR and CP 1290 SVR). and front head. CP 1210 SVR, CP 1260 SVR and CP 1290 SVR...

  • Page 28: Periodic Maintenance

    Maximum allowed wear (A) ⁄ in. (1mm). See illustration shown below. CP 1210 SVR, CP 1260 SVR and CP 1290 SVR 8. Before assembling the back head onto the cylinder, check that the seal protrudes approximately (B) ⁄...

  • Page 29: Tightening Torques

    CP 1210, CP 1260, CP 1290 Safety and operating instructions Tightening torques Fitting claw couplings or other connectors NOTICE When fitting a claw coupling or other connectors to the swivel, Loctite® 263™(Loctite is a registered trademark of Henkel Corporation. 263 is a trademark of Henkel Corporation) or similar has to be used.
  • Page 30 Safety and operating instructions CP 1210, CP 1260, CP 1290 Check that the insertion tool being used has the ♦ correct shank dimension. Check that the pneumatic machine is getting the ♦ correct amount of lubricant. Too much lubrication can cause starting problems, low power or uneven performance.

  • Page 31: Technical Data

    CP 1210, CP 1260, CP 1290 Safety and operating instructions Technical data Machine data Shank dimension Weight Length Blows Consumption Type in. (mm) lb (kg) in. (mm) cfm (l/s) CP 1210 Hex. 1x4¼ (25x108) 44 (20) 21¼ (540) 1400 55 (26.5) CP 1210 S Hex.

  • Page 32: Noise And Vibration Data

    Safety and operating instructions CP 1210, CP 1260, CP 1290 The vibration emission varies greatly with task and operator technique. The declared vibration value relates to the main handle(s) and much higher vibration levels may occur at other hand positions. We believe that normal intended use of the tool will usually produce vibration emissions in the range of C ⁄...

  • Page 33: Ec Declaration Of Conformity (Ec Directive 2006/42/Ec)

    CP 1210, CP 1260, CP 1290 Safety and operating instructions EC Declaration of Conformity EC Declaration of Conformity (EC Directive 2006/42/EC) We, Construction Tools PC AB, hereby declare that the machines listed below conform to the provisions of EC Directive 2006/42/EC (Machinery Directive) and 2000/14/EC (Noise Directive), and the harmonised standards mentioned below.

  • Page 34: Spare Parts List

    Spare parts list Handheld pneumatic breakers CP 1290, CP 1290 S, CP 1290 SVR...

  • Page 35: General Information

    CP 1290, CP 1290 S, CP 1290 SVR Spare parts list General information This spare parts list applies to the following: Part number Description 8900 0030 37 Handheld pneumatic breakers CP 1290 hexagon ⁄ ⁄ in. (32 x 160 mm*) 8900 0030 38 Handheld pneumatic breakers CP 1290 hexagon ⁄...
  • Page 36 Spare parts list CP 1290, CP 1290 S, CP 1290 SVR Spare parts list CP 1290...
  • Page 37 CP 1290, CP 1290 S, CP 1290 SVR Spare parts list Description Remark Quantity Part number 1(2-7) Backhead, complete 3303 0053 70 Backhead Trigger F814 725 Pin - spring R133 433 Plug - oil R075 031 Oil wick C036 901 Rubber grip 3303 0052 76 0261 1099 53...
  • Page 38 Spare parts list CP 1290, CP 1290 S, CP 1290 SVR Description Remark Quantity Part number 51(52-53) Fronthead, complete R092 917 Fronthead Hexagon, 28 mm Hexagon, 1 ⁄ Bushing - fronthead Hexagon, 28 mm R090 122 Hexagon, 1 ⁄ Label Safety 3310 1602 00...
  • Page 39 Spare parts list CP 1290, CP 1290 S, CP 1290 SVR CP 1290 S...
  • Page 40 CP 1290, CP 1290 S, CP 1290 SVR Spare parts list Description Remark Quantity Part number 1(2-7) Backhead, complete 3303 0053 70 Backhead Trigger F814 725 Pin - spring R133 433 Plug - oil R075 031 Oil wick C036 901 Rubber grip 3303 0052 76 Screw...
  • Page 41 Spare parts list CP 1290, CP 1290 S, CP 1290 SVR Description Remark Quantity Part number Separation wall 3303 0052 97 Label Sound power level 111 dB H418 4044 Label Safety 3310 1602 00 Data plate 57(58-59) Fronthead, complete R092 918 Fronthead Hexagon, 32 mm Hexagon, 1...
  • Page 42 Spare parts list CP 1290, CP 1290 S, CP 1290 SVR CP 1290 SVR...
  • Page 43 CP 1290, CP 1290 S, CP 1290 SVR Spare parts list Description Remark Quantity Part number 1(2-12) Backhead, complete 3303 0053 78 Cover 3303 0053 64 Spring - handle 3303 0053 62 Backhead Spring pin 0108 1322 00 Spring pin ø16 x 65 mm 0108 1535 00 ø0.63 x 2.56 in.
  • Page 44 Spare parts list CP 1290, CP 1290 S, CP 1290 SVR Description Remark Quantity Part number 53(54-60) Muffler, complete 3303 0053 77 Muffler 3303 0053 20 Flange screw 0147 3000 32 Flange nut 9232 0207 50 O-ring ø94.1 x 5.7 mm 0663 2146 00 ø3.70 x 0.22 in.
  • Page 45 CP 1290, CP 1290 S, CP 1290 SVR Spare parts list Working tools US standard hexagon 1 x 6 in. (28 x 152 mm) Point to flat (in.) Description W (in.) L (in.) Wt (lb) Part number Moil point 3083 3267 00 3083 4015 10 3083 4015 20 ⁄...
  • Page 46 Spare parts list CP 1290, CP 1290 S, CP 1290 SVR US standard hexagon 1¼ x 6 in. (32 x 152 mm) Point to flat (in.) Description W (in.) L (in.) Wt (lb) Part number Moil point 3083 3285 00 3083 4000 10 ⁄...
  • Page 47 CP 1290, CP 1290 S, CP 1290 SVR Spare parts list (mm) Description W (mm) L (mm) Wt (kg) Part number Shaft for tamping pad 3083 3283 01 Tamping pad, round Ø180 3083 3301 00 Tamping pad, square 3083 3302 00 10.0 3083 3197 00 Driving pad...
  • Page 48 Spare parts list CP 1290, CP 1290 S, CP 1290 SVR Accessories Hose rolls Metric Maximum working Length of Inner diameter Thickness pressure roll Weight Description (mm) (mm) (bar) (kg) Part number Red-X hose roll 8900 0050 10 Red-X hose roll 8900 0050 11 Red-X hose roll 8900 0050 12...
  • Page 49 CP 1290, CP 1290 S, CP 1290 SVR Spare parts list Water separator Metric Hose connection Air flow Weight Description (mm) (l/s) (kg) Part number Water separator ( ⁄ in. BSP) 8900 0050 00 Imperial Air flow Hose connection Weight (foot /min) Description...
