- Page 1 No.VZ1000-OMM0002-C Solenoid Valve PRODUCT NAME VZ1000/3000/5000 Series MODEL / Series / Product Number...
-
Page 2: Table Of Contents
Contents Safety Instructions ---------------------------------------------------------------------------- 2,3 Design / Selection ---------------------------------------------------------------------------- Mounting ---------------------------------------------------------------------------------------- Piping -------------------------------------------------------------------------------------------- Wiring -------------------------------------------------------------------------------------------- Lubrication -------------------------------------------------------------------------------------- 7 Air Supply --------------------------------------------------------------------------------------- 7 Operating Environment ---------------------------------------------------------------------- 8 Maintenance ------------------------------------------------------------------------------------ 8 Specific Product Precautions --------------------------------------------------------------- 9 ~13 Trouble shooting ------------------------------------------------------------------------------- 14,15... -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
Safety Instructions Caution SMC develops, designs, and manufactures products to be used for automatic control equipment, and provides them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not allowed. Products SMC manufactures and sells cannot be used for the purpose of transactions or certification specified in the Measurement Act of each country. -
Page 5: Design / Selection
VZ Series Precautions for 5 Port Solenoid Valve 1 Be sure to read before handling. Refer to main text for detailed precautions on every series. Design / Selection 9. Regarding a vacuum switch valve and a vacuum release valve. Warning If a non-vacuum is installed in the middle of piping 1. -
Page 6: Mounting
VZ Series Precautions for 5 Port Solenoid Valve 2 Be sure to read before handling. Refer to main text for detailed precautions on every series. Operation in a low temperature condition Design / Selection It is possible to operate a valve in extreme 2. -
Page 7: Piping
VZ Series Precautions for 5 Port Solenoid Valve 3 Be sure to read before handling. Refer to main text for detailed precautions on every series. Caution Piping 6. Uni thread fittings Caution 1) First, tighten the threaded portion by hand, then use a suitable wrench to tighten the hexagonal portion of Refer to the Fittings and Tubing Precautions the body further at wrench tightening angle shown... -
Page 8: Wiring
VZ Series Precautions for 5 Port Solenoid Valve 4 Be sure to read before handling. Refer to main text for detailed precautions on every series. Air Supply Wiring Warning Warning Type of fluids 1. The solenoid valve is an electrical Please consult with SMC when using the product in product. -
Page 9: Operating Environment
VZ Series Precautions for 5 Port Solenoid Valve 5 Be sure to read before handling. Refer to main text for detailed precautions on every series. Operating Environment Maintenance Warning Warning 1. Do not use in an atmosphere having 1. Perform maintenance inspection according corrosive gases, chemicals, sea water, water, to the procedures indicated in the operation water steam, or where there is direct contact... -
Page 10: Specific Product Precautions
VZ Series Specific Product Precautions1 Be sure to read before handling.. Manual Override Operation Light/Surge Voltage Suppressor Without an electric signal for the solenoid valve the manual override Grommet Type is used for switching the main valve. Connected actuator is started by manual operation. - Page 11 VZ Series Specific Product Precautions2 Be sure to read before handling. Light/Surge Voltage Suppressor When using a 4/5 port valve as a 3 port valve VZ1000/3000/5000 are possible for use with normally closed (N.C) or normally open (N.O) 3 port valve by closing one of the cylinder ports (A,B) with a plug.
- Page 12 VZ Series Specific Product Precautions3 Be sure to read before handling. Attaching and detaching lead wires with sockets How to Wire DIN Terminal Connection 1. Attaching Insert the sockets into the square holes of the connecter (with + 1. Loosen the set screw and pull out the connector from the terminal and ―...
- Page 13 VZ Series Specific Product Precautions4 Be sure to read before handling. Manifold Electrical Wiring Bracket Single B Mount Manifold and Non Plug-in DIN Rail Manifold In the case of Series VZ5000 with bracket, do not use it without Connect individually according to electrical entry of the solenoid bracket.
- Page 14 VZ Series Specific Product Precautions5 Be sure to read before handling. Interface Regulator Installing an interface regulator between a valve and the manifold base makes it possible to reduce the supply pressure to that valve without changing the supply pressure of the other stations on the manifold.
-
Page 15: Troubleshooting
TROUBLESHOOTING Should any trouble be found during operation, trace the source of the trouble in the following order and take corrective action. Trouble phenomenon Cause expected Measures (Next page) ① Faulty operation Pilot valve is not operated Faulty wiring ② Blown fuse or disconnection lead wire ③... - Page 16 Remedy ① Re-wire correctly. ② Replace part. ③ Replace part or re-wire positively. ④ Replace valve. (pilot valve). ⑤ Regulate pressure so that pilot pressure will fall within operating pressure range furing operation. ･If wrong oil is used, completely air blow to remove oil, and replace valve. After valve is replaced, use turbine oil class 1 (ISO VG32).
- Page 17 Revision history A Safety Instructions 2010.2 B Plug-in type deletion 2012.8 C Corrected notes on precautions. 2025.3 Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
