SMC Networks VM200-A Series Operation Manual

Mechanical valve
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Document No: VM-OMR0012-B
Product Name
Mechanical valve
Model/Series
VM200-A Series
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM200-A Series and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks VM200-A Series

Summary of Contents for SMC Networks VM200-A Series

  • Page 1 Document No: VM-OMR0012-B Product Name Mechanical valve Model/Series VM200-A Series...

  • Page 2: Table Of Contents

    Contents 1. Safety Instructions 2. Application 3. Specifications 4. Models and Strokes 5. Installation and Mounting Orientation 6. Operating Force 7. Mechanical Operating Conditions 8. Replacement of the Actuator 9. Product Number of the Actuator...

  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing business. Use in non-manufacturing business is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
  • Page 5 Design precautions Warning ！ 1. Actuator drive When an actuator, such as a cylinder, is to be driven take appropriate measures to prevent potential danger caused by actuator operation. 2. Maintenance space When installing the products, allow access for maintenance. 3.
  • Page 6 2. Do not disassemble or modify the product. This may cause human injury and/or an accident. Contact SMC for repairs and maintenance of the product. 3. Do not wipe the product using chemicals. Piping Caution ！ 1. Before piping Before piping, perform air blow (flushing) or cleaning to remove any cutting chips, cutting oil, dust, etc.
  • Page 7 Air Supply Warning ！ 1. Use clean air. Do not use compressed air that contains chemicals, organic solvents based synthetic oils, salts or corrosive gases, etc., as this can cause damage or malfunction. Caution ！ 1. Install air filters. Install air filters close to valves on the upstream side. A filtration degree of 5 micrometer or less should be selected.
  • Page 8 Maintenance Warning ！ 1. Removal of equipment, and supply/exhaust of compressed air When equipment is serviced, first confirm that measures are in place to prevent dropping of driven objects and/-or equipment running out of control, etc. Then cut the supply pressure and power, and exhaust all compressed air from the system using its residual pressure release function.
  • Page 9 Specific Product Precautions for Mechanical Valve Design precautions Warning ！ 1. Cannot be used for sealing pressure. Since VM200 is a poppet type valve, fluid flows backwards when the pressure on port 2 rises. Since the valve is subject to a little amount of air leakage, it cannot be used for applications such as holding pressure.
  • Page 10 2. Select the angle and the maximum speed of the operating cam and the dog of the mechanism so that they do not exceed the maximum values. This could damage the mechanical valve itself and lead to equipment malfunction. Refer to Chapter 7, "Mechanical Operating Conditions"...

  • Page 11: Application

    2. Application This product is a valve for signal transmission used for a pneumatic control circuit of machining equipment or general industrial machinery, etc. 3. Specifications Fluid Operating pressure 0 to 1 MPa Operating temperature -5 to 60 C (No freezing) 1(P)→2(A) 2(A)→3(R) Flow rate characteristics...
  • Page 12 Model F.O.F. P.T. O.T. T.T. Type (Note 1) (Note 1) (Note 1) 0.5 MPa 2 port 3 port (Note 1) Basic VM220-02-00A VM230-02-00A 52 N 3 mm 2 mm 5 mm VM220-02-01A VM230-02-01A Roller lever 24 N 6.5 mm 4.5 mm 11 mm VM220-02-01SA VM230-02-01SA...

  • Page 13: Installation And Mounting Orientation

    5. Installation and Mounting Orientation 5-1. Product number with each actuator Model Type Mounting dimensions 2 port 3 port Mounting Roller lever VM220-02-01A VM230-02-01A plate VM220-02-01SA VM230-02-01SA One way roller lever VM220-02-02A VM230-02-02A M5 screw VM220-02-02SA VM230-02-02SA Fix at two points using M5 screws. Straight plunger VM220-02-05A VM230-02-05A...
  • Page 14 5-2. Bottom mounting type Only the selector type (for 3 position) has four mounting screw positions. 削除 Mounting plate Use two M4 screws (four for 3 position selector) for mounting. 2×M4 4×M4 5-3. With bracket 2×φ5.4 two M5 screws for mounting. Mounting plate...

  • Page 15: Operating Force

    6. Operating Force Full operating force increases according to the increase of the supply pressure. Full operating force for each product type can be found by the formula below. F ≒ × F2 F1: Full operating force at 0.5MPa of the product type (F.O.F on page 11) F2: Full operating force at supply pressure found from Fig.1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 supply pressure（MPa）...

  • Page 16: Mechanical Operating Conditions

    7. Mechanical Operating Conditions 7-1. Stroke range Use a mechanical operating product within the stroke range calculated by the formula below. Stroke range = (P.T. + 0.5 x O.T.) to (P.T. + O.T. -0.1) Actuator Stroke range (mm) Basic 4.0 to 4.9 Roller lever 8.7 to 10.9 One way lever...
  • Page 17 7-4. Operation mechanism and configuration 1. Avoid acute angles on limit switch actuator. (Not acceptable) (Acceptable) Section 7-2 Not larger than the maximum angle Section 7-2 Wider than the maximum angle Abrupt angle 2. Do not allow stroke beyond the maximum travel position. (Not acceptable) (Acceptable) (Acceptable)

  • Page 18: Replacement Of The Actuator

    8. Replacement of the Actuator 8-1. Lever type 1. Raise the lever of the actuator as shown in Fig. and mount the actuator to the mechanical valve with two screws (M3x8). 2. Gently hit the end part of the lever support with a hammer so that the lever will not rise after mounting, and adjust the clearance between the end of the push bar and the bottom part of the lever to be not more than 1mm.
  • Page 19 8-3. Button type, Selector type 1. Mount a bracket to the mechanical valve using two screws (M3x8 with spring washer). 2. Mount a button or selector to the bracket (that is already mounted to the mechanical valve) with two screws (M3 x8 with spring washer). Cross recessed round...
  • Page 20 8-4. Replacement of the button Follow the procedure below to change the button. 1. Flush push button Installation - Choose the button from 4 colors (red, green, black and yellow). Push the protruding part of the button into the body. Removal - Remove fastening ring.

  • Page 21: Product Number Of The Actuator

    9. Product Number of the Actuator [Actuator number] Actuator Actuator Remarks Component No. Basic ― ― VM-01A POM roller Roller lever VM-01AS Hard steel roller VM-02A POM roller One way roller lever VM-02AS Hard steel roller Straight plunger VM-05A ― VM-06A POM roller Roller plunger...
  • Page 22 Revision history A. Stroke range correction D : Safety Instructions changed. 2023.12 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 URL https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
