- Page 1 Installation & Operational Manual Model D6098b-27k Series Hydraulic Cart Lifter Protected by US Patents 6,921,239 & 7,273,340 D6098b-56-27k Shown...
-
Page 2: Table Of Contents
MIXED COMMERCIAL AND RESIDENTIAL INSTALLATION.…………………………………………………. 10 - 13 NON-PERKINS HYDRAULICS.……………..……………………………………………………………………………………. 14 PERKINS HYDRAULICS.……………………………………………….……………………………………………………. 15 - 18 ADJUSTING THE PERKINS HYDRAULICS.…………………..………………………………………………………. 19 - 25 OPERATING THE LIFTER.…………………………………….……………………………………………………………. 26 - 27 ADJUSTING THE LIFTER………………………..………….………………………………………………………………. 28 - 29 TROUBLESHOOTING GUIDE………………….……..………………………….……………………………..………. 30 – 33 MAKING A WARRANTY CLAIM………………………..………….…………….……………………………………………. -
Page 3: D6098B-27K Lifter Specifications
Warranty 2-years *** Perkins regularly makes product improvements. Specifications are subject to change without notice. * Actual pressure required to lift a load can vary. ** Do not lift more than the recommended amount printed on the cart by the cart manufacturer or damage or injury may result. - Page 4 A NOTE ABOUT WEIGHT CAPACITY Please note that the advertised weight capacity of our Perkins lifters is typically 400 lbs, which includes our standard lifters equipped with our standard 27k rotary actuator. That figure of 400 lbs exceeds the marked capacity of the bin.
-
Page 5: Overall Dimensions
Overall Dimensions Perkins regularly makes product improvements. Dimensions are subject to change without notice. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 3 ® www.perkinsmfg.com... -
Page 6: Glossary Of Terms
Control Valves are sold separately or as part of a tap-in kit. The valves are shown for reference / identification purposes only. Your specific installation may require other equipment not shown. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway... -
Page 7: Installation Safety
Do not paint over caution and warning labels. If there are any questions about the proper installation or use of the cart lifter not covered in the manual, it is recommended to call Perkins at 800-882-5292. Perkins Manufacturing Company... -
Page 9: Installation Tips
(usually to the curb side) as shown in the picture at right. A double installation will place a lifter 17 ½” to the left and 17 ½” to the right of the truck’s centerline. A typical offset installation. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway... - Page 10 Positioning the Mounting Plate * The mounting height is based on the height of the top gripper arm to the ground. Minimum height is 25” up to 26". The mounting plate itself should be vertical and level. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021...
- Page 11 Dimensions shown above are an example only and will vary from truck to truck Perkins recommends adding steel structural tube across the entire length of the load sill. This tube becomes the new load sill.
- Page 12 Double check the hook height to the ground. If everything appears satisfactory, the lifter’s mounting plate and supports may be welded fully. The mechanical portion of the installation is complete. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021...
-
Page 13: Mixed Commercial And Residential Installation
Note: Be careful not to cut into the original load sill or else the structural integrity of the tailgate can be compromised. It may be necessary to add custom structure reinforcements where the lifter is to be mounted. Perkins Manufacturing Company 800-882-5292... - Page 14 That is normal. Note: The size and shape of the bumper extension can vary depending on your fabrication preferences. Perkins does offer pre-made bumper extension kits, sold separately: CA1084 – single lifter, offset to the right CA1085 –...
- Page 15 Double check that a commerical container cannot make contact with the lifter. If everything is satisfactory, weld fully. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 12 ®...
- Page 16 Note the Bumper Extension fully protects the cart lifter from contact with the commercial container. The elephant ears and container locks have been shifted back and material added. The reverse lights have been relocated in this installation so they would not be obscured by the lifter placement. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021...
-
Page 17: Non-Perkins Hydraulics
Perkins would like to take this opportunity to remind you to check the quality of your hydraulic oil periodically and make sure it meets your standards. Oil that is maintained in good condition will help your equipment last longer. - Page 18 (typically about 48” high) so that repeated ergonomics is easy to use and safe. The Perkins hand valve assembly comes with a mounting bracket which may be welded directly to the side of the truck. Typically, the hand valve’s handle will point to the back of...
- Page 19 With the system off and depressurized, find the pressure line that feeds the packer valve and disconnect it. Connect this pressure line to the “IN” port of the Perkins diverter valve. Connect the “OUT” port of the diverter valve back to the packer control valve where the pressure line originally was.
- Page 20 The Perkins Diverter Valve Ordinarily, the diverter valve’s port “P” will feed the lifter. But, if you have two lifters, then you will use the Perkins Double Diverter Valve. It’s the same valve, except port “P” is plugged, and a 50/50 splitter valve is mounted on top.
- Page 21 Tapping into the Tank Line There are two ways to run the oil back to tank. Perkins does not suggest allowing the return oil to get pushed back into the packer control valve, because this generates back pressure and heat.
-
Page 22: Adjusting The Perkins Hydraulics
Adjusting the Perkins Hydraulics Adjusting the Speed Single Diverter: D63237s Double Diverter: D63411s This valve’s adjustment controls the flow going to the lifter. The flow controls the speed of the lifter. A typical 27k rotary lifter requires 3.5 gpm to achieve a 6-8 second cycle time. - Page 23 “chatter”. Adjusting one valve to be set differently than another should eliminate the problem. Example: Pump relief valve 2000 psi, packer relief valve 1900 psi, lifter relief valve 1650 psi. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021...
- Page 24 If the lifter comes down too quickly, try turning this valve in clockwise ¼ turn at a time until the down direction is smooth and under control. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway...
- Page 26 #4 bleed ports located atop it. Cracking the plug loose slightly will allow trapped air to escape. Perkins recommends this be performed only as necessary. Lifter motion that is very erratic is usually a sign of trapped air. The lifter should...
-
Page 30: Operating The Lifter
Step 4: Lower the cart by reversing the hand valve handle (pushing down), until the cart is safely returned to the ground and the lifter has disengaged the cart. Step 5: Remove the empty cart and repeat the process as needed. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021... - Page 31 If the truck is equipped to dump commercial containers, the lifter must be stored all the way down prior to engaging the commercial container or the cart lifter may be crushed by the container. This damage is not covered by warranty. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021...
- Page 32 If you experience any difficulties with the cart type you have, please call Perkins at 800-882-5292 to discuss the problem and Perkins will advise the best solution to meet your needs.
- Page 33 Install the faceplate assembly so that the face is 45 degrees above the horizon. Each tooth offers separation of 12.8 degrees, so if you use the wrong tooth, it should be readily obvious and easily correctible. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway...
-
Page 34: Troubleshooting Guide
If the pressure falls, you may have internal leakage and the actuator should be repaired/rebuilt with new seals. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway... - Page 35 On new installations, this is the result of having the pressure and tank lines reversed. Check and make sure that the pressure line goes to the “IN” port and the tank line goes to the “OUT” port. Perkins Manufacturing Company 800-882-5292...
- Page 36 Adjust the speed of the lifter to bring the cycle time to 6-8 seconds. Make sure the pressure is set no higher than 1950 psi. Make sure the lifter is not damaged. Bent or broken lifter parts can contribute to cart damage. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021...
- Page 37 In this case, the lifter is most likely being operated too fast, or the carts are overweight. Excessively hard shaking of the carts by the operators can also lead to cart damage. Train your operators to operate the lifters properly. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021...
-
Page 38: Making A Warranty Claim
At right is an example of the serial number plate. It will be stamped with a model number and serial number. Once you have the number, please call Perkins Manufacturing at 800-882-5292 for additional instructions. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021... - Page 39 Gripper Exploded Parts Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 35 ® www.perkinsmfg.com...
- Page 40 Mounting Exploded Parts Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 36 ® www.perkinsmfg.com...
- Page 41 RETAINING DISC FLANGE D62006 FHCS ½-13 X 1 ½ D62081 LOCKNUT NYLOCK ½-13 D69490 RUBBER GRIPPER BELT BOLT HHCS ½-13 X 2 ¼” GRADE 8 D62112 Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 37 ® www.perkinsmfg.com...
- Page 42 ORIFICE FITTING ADAPTER #4SAE - #6JIC TEE 6MT – 6MO – 6MT D63031 TEE 6MT – 6FT – 6MT D63419 D72219 12PT FLANGE BOLT 5/8-11 X 1 ½ Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 38 ®...
- Page 43 PARTS FOR THE D6098B-47 AS FOLLOWS IDLER ARM WELDMENT (47”) D69450 DRIVER ARM WELD. LH (47”) D69557 DRIVER ARM WELD. RH (47”) D69558 32” SHEATHED HOSES #6 D63517 Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 39 ® www.perkinsmfg.com...
- Page 44 50” SHEATHED HOSES #6 A90877-50 PARTS FOR THE D6098BLF AS FOLLOWS LONG DOUBLE ARM WELDMENT – RH D69569+5 LONG SINGLE ARM WELDMENT – LH D69570+5 Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 40 ® www.perkinsmfg.com...
- Page 45 BOLT FHCS 3/8-16 X 1 1/2 GR8, Zinc Plated D69567 CENTER RUBBER STRIP D69587 LOWER BUMPER WELDMENT D62106 SPLIT LOCKWASHER 3/8'' ZINC PLATED D62079 BOLT HHCS 3/8-16 X 1 GR8 ZINC PLATED Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021 Creators of the TuckAway Cart Lifter Page 41 ® www.perkinsmfg.com...
-
Page 46: Quick Rebuild Kit
Sometimes a lifter is damaged by collision, although the actuator and mounting parts are usually not damaged in this type of accident. Perkins offers a kit for the easy ordering of the necessary parts to quickly restore the lifter to good operation. -
Page 48: Protective Safety Labeling
Protective Safety Labeling Perkins provides each finished cart lifter with ANSI-specified caution labels. They are clearly placed directly on the machine for easy viewing by the operators. Should the cart lifter ever be re-painted, or if the labels are damaged beyond recognition, it is advised to replace the labels immediately to help keep your crew safe. - Page 50 If any issues occur, please contact service immediately. Perkins Manufacturing Company 800-882-5292 Revised:7/12/2021...
- Page 51 Safety Labeling and Training Requirements Perkins provides safety labeling on all outgoing product per ANSI regulations, seen below. It is the responsibility of owner of this product to maintain the safety labels, keep them clear & visible to all users, and replace the safety labels when they become worn or missing.
- Page 52 If you believe your Perkins lifter has suffered from a failure that could be covered by warranty, immediately lock out any equipment that has failed per OHSA guidelines.
- Page 53 If Perkins shipped the wrong item(s), the incorrect item(s) may be returned within 30 days of receipt of the item by contacting Perkins for a return authorization (RGA#). The item(s) must be shipped within 2 weeks of the return authorization. Perkins will pay the return freight and waive the restocking fee.
- Page 54 PERKINS warrants any service parts it may sell for a period of ninety (90) day from the date of delivery for replacement only. The item being replaced must be returned to PERKINS for evaluation upon its request.
