Hotpoint Ariston H2I HD526 A Quick Manual

Quick Guide
THANK YOU FOR BUYING A HOTPOINT ARISTON PRODUCT.
In order to receive a more complete assistance, please register
your appliance on: www.hotpoint.eu/register
Before using the appliance carefully read Safety Instructions
guide.
CONTROL PANEL
1. ON-OFF/Reset button with indicator light
2. Program selection button
3. Salt refill indicator light
4. Rinse Aid refill indicator light
5. Program number and delay time indicator
6. Tablet indicator light
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine's functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
filled when the SALT REFILL indicator light
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Only the first time you do this: fill the salt reservoir
with water.
3. Position the funnel (see figure) and fill the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Whenever you need to add salt, it is mandatory to complete the pro-
cedure before the beginning of the washing cycle to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently prevent-
ing scale buildup on heater, contributing also to better cleaning efficiency.
PROGRAMS TABLE
Program
Eco 50°- Eco program is suitable to clean normally soiled tableware. that
for this use. it is the most efficient program in terms of its combined energy
1.
and water consumption. and that it is used to assess compliance with the EU
Ecodesign legislation.
-
Intensive 65° Program recommended for heavily soiled crockery. especially
2.
suitable for pans and saucepans (not to be used for delicate items).
3. -
Mixed 55° Mixed soil. For normally soiled dishes with dried food residues.
Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that ensures
4.
optimal cleaning and drying performance in shorter time.
-
Rapid 28' 50°
Program to be used for half load of lightly-soiled dishes with no
5.
dried food residues. Does not have drying phase.
Good Night 50°
6.
optimal cleaning and drying performance with the lowest noise emission.
Sanitizing 65°
7.
antibacterial wash. Can be used to perform maintenance of the dishwasher.
Soak - Use to refresh crockery planned to be washed later. No detergent to be
8.
used with this program.
Self-Clean 65° - Program to be used to perform maintenance of the dishwasher,
9.
to be carried out only when the dishwasher is EMPTY using specific detergents
designed for dishwasher maintenance.
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020. Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
7. Display
8. Half Load indica-
tor lights
9. Half Load button
10. Delay button
11. START/Pause
in the control panel is lit.
Programs description
-
Suitable for night-time operation of the appliance. Ensures
-
Normally or heavily soiled crockery, with additional
PLEASE SCAN THE QR CODE ON YOUR
APPLIANCE IN ORDER TO HAVE MORE
DETAILED INFORMATION
1 2 3 4 5
This system regenerates itself with salt, therefore it is required to refill
salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in final rinse and finishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be filled when the RINSE AID
D
REFILL indicator light
C
NEVER pour the rinse aid directly into the appli-
ance tub.
A
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the program so
that the best washing and drying results are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
Available
options
-
-
-
6 7 8 9 10
button with indicator light / Tablet (Tab)
in the control panel is lit.
Duration Water
of wash con-
program sumption
*)
(h:min) **) (litres/cycle)
3:35 9.5
2:40 18.0
2:15 16.0
1:30 11.5
0:28 9.0
3:35 16.6
2:00 12.0
0:12 4.7
0:50 10.0
EN
11
Energy
consumption
(kWh/cycle)
0.95
1.60
1.40
1.30
0.50
1.30
1.50
0.01
0.80
1
