Hotpoint Ariston HFC 3C26 CW X Quick Manual

Quick Guide
THANK YOU FOR BUYING A HOTPOINT ARISTON PRODUCT.
In order to receive a more complete assistance, please register
your appliance on: www.hotpoint.eu/register
Before using the appliance carefully read Safety Instructions
guide.
CONTROL PANEL
1. On-Off / Reset button with indicator light
2. Program selection button with indicator light
3. Zone Wash 3D button with indicator light /
Keylock
4. Eco program indicator light
5. Keylock indicator light
6. Display
7. Program number and remaining time indicator
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine's functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
filled when the SALT REFILL indicator light
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel (see figure) and fill the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
3. Only the first time you do this: fill the salt reservoir
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water
softener beyond repair).
Whenever you need to add salt, it is mandatory to complete the proce-
dure before the beginning of the washing cycle to avoid corrosion.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be filled when the RINSE AID
REFILL indicator light
D
NEVER pour the rinse aid directly into the
C
appliance tub.
A
PROGRAMS TABLE
Program
Eco 50°- Eco program is suitable to clean normally soiled
tableware. that for this use. it is the most efficient program in
1.
terms of its combined energy and water consumption. and that
it is used to assess compliance with the EU Ecodesign legislation.
Auto Intensive 65°
2.
dishes and pans (not to be used for delicate items).
Auto Mixed 55°
3.
and dishes.
Auto Fast Wash 50° - Automatic program for limited quantity
4.
of normally soiled crockery. Ensures optimal cleaning
performance in shorter time.
Rapid 30' 50°
5.
soiled dishes with no dried food residues. Does not have
drying phase.
Good Night 50°
6.
appliance. Ensures optimal cleaning and drying performance
with the lowest noise emission.
Sanitizing 65° - Normally or heavily soiled crockery, with
7.
additional antibacterial wash. Can be used to perform
maintenance of the dishwasher.
Soak - Use to refresh crockery planned to be washed later.
8.
No detergent to be used with this program.
Self-Clean 65° - Program to be used to perform maintenance
of the dishwasher, to be carried out only when the dishwash-
9.
er is EMPTY using specific detergents designed for dishwash-
er maintenance.
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid refill indicator light
11. Salt refill indicator light
12. Short Time button with indicator
light / Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
in the control panel is lit.
in the control panel is lit.
Programs description
-
Automatic program for heavily soiled
-
Automatic program for normally soiled pans
-
Program to be used for half load of lightly-
-
Suitable for night-time operation of the
PLEASE SCAN THE QR CODE ON YOUR
APPLIANCE IN ORDER TO HAVE MORE
DETAILED INFORMATION
1 2 3
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub.
If all-in-one detergents are used, we recommend using the TABLET button,
because it adjusts the program so that the best washing and drying results
are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on heater, contributing also to better cleaning effi-
ciency. This system regenerates itself with salt, therefore it is required
to refill salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in final rinse and finishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
Available
options
*)
- -
-
-
-
-
-
-
-
4 5 6 7 8 9 10 11 12 13
Duration
Water
of wash
consumption consumption
program
(litres/cycle) (kWh/cycle)
(h:min)
**)
3:10 9.5
2:00 - 3:10 14.0 - 17.0 1.50 - 1.85
1:30 - 2:30 14.5 - 16.0 1.15 - 1.30
0:55 - 1:20 13.0 - 14.5 1.15 - 1.25
0:30 9.0
3:30 15.0
1:40 10.0
0:12 4.5
0:50 8.0
EN
14
Energy
0.95
0.50
1.15
1.30
0.01
0.85
1
