- Page 1 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 DM08 Top Tube Embedded Display Functionality Introduction Product Name：Top Tube Embedded Display Product Model：DM08 Signature Date Editor Liu Lei 2024.10.09 Checked Approved...
-
Page 2: Revision History
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Revision History Version No Reviser Date Revision content V1.0 Liulei 2024.10.09 1. Initial version 第 2 页/共 19页... -
Page 3: Table Of Contents
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Content A.Product Introduction .......................... 5 1.Product name and model ......................5 2. Product introduction ........................5 3. Range of application ........................ 6 4. Appearance and size ........................ 6 5.display coding rules ........................7 B. Product manual ..........................8 1. - Page 4 Please consult your drive system supplier for additional function requirements and data display. If you have any questions about DM08 functional definition, please consult our sales or technical support team. Our company (VeloFox®) reserves all the rights to interpret and explain DM08 functional definitions.
-
Page 5: A.product Introduction
DM08 includes two versions of UART communication and CAN BUS communication DM08_U corresponds to UART communication version； DM08_C corresponds to CAN BUS communication version. All DM08 products are equipped with built-in hardware that supports master-slave mode Bluetooth functionality. 2. Product introduction ... -
Page 6: Range Of Application
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 3. Range of application Suitable for all E-bikes that comply with EN15194 standard 4. Appearance and size The shell material of DM08C is PC+ABS, Combined with the embedded top tube design, it is mainly suitable for road, gravel, and MTB bikes. -
Page 7: Display Coding Rules
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 5.display coding rules As shown in above picture： Manufacture year and week number Production serial number Manufacture factory code，M1，M2, M3 Hardware version number，C-CAN, U-UART, last 2 numbers are version Product model Parameter character value（reserved）... -
Page 8: Product Manual
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 B. Product manual 1. Specifications ① Power supply：DC 24V/36V/48V/72V ② Rated current：12mA@36V ③ Shutdown leakage current：<1uA ④ Screen specification：6-LED Color Indicator Lights ⑤ Communication method：UART/ CAN-BUS ⑥ Operating temperature：-20°C ~ 60°C ⑦... -
Page 9: Interface
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 4 .Interface 4.1 Boot interface Upon powering on, all LEDs will light up simultaneously. Then, the bottom five LEDs will sequentially light up in a running light pattern for two cycles. After establishing a communication connection, the device will retrieve battery and gear information from the controller, displaying the actual data.The color of the lights represents different gear levels, and the number of lit LEDs... -
Page 10: Basic Interface And Operation
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 4.2 Basic interface and operation Bluetooth indicator Sixth LED Power button Fifth Battery Display, ↓ Gear Display & Error Display First LED Adjustment button Power On/Off Operation； ① LED indicators display battery, gear, and error information based on the controller's feedback；... -
Page 11: Definition Of Button Operation
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 4.3 Definition of button operation Operation Type Description Press the button and soon released, while the button is released,the Short press function activated accordingly。 Press the button and hold, when the hold time exceeds the setting Long press time(generally 2 seconds), the function activated accordingly. -
Page 12: Assist Level Switch
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 5.2 Assist level switch Press the button to switch assist levels, changing the assist mode.There are 5 assist levels (1-5). Different assist levels correspond to different LED light colors: 0th gear: White；1st gear: Yellow；2nd gear: Green；... -
Page 13: Bluetooth Indicator Light
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 5.4 Bluetooth Indicator Light When Bluetooth is not connected, the sixth indicator LED will remain off. Once a Bluetooth device successfully connects to the display, the sixth LED will light up in blue. -
Page 14: Battery Power Indicator And Assist Power Output
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 5.6 Battery power indicator and assist power output The battery level is indicated by the number of LED lights displayed. The following table shows the correspondence between the battery capacity percentage and the... -
Page 15: Error Information
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 6. Error information The display can provide a warning of vehicle malfunctions， When a fault is detected, the first and second LEDs will flash red in combination to indicate the error. For example, to report error code 24, the first LED flashes twice, then stops, followed by the second LED flashing four times. - Page 16 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 error code information table： Error description Suggest operation Error code Throttle not returning LED 2 flashes 4 times Throttle failure LED 2 flashes 5 times Overvoltage protection LED 2 flashes 7 times...
-
Page 17: Key Selection Recommendations
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 7. Key Selection Recommendations Product images Remote Product name RM01 RM05 RM07（Bluetooth Key） Four keys: power on/off Add +/subtract - (power button)/M key/+ Add +/subtract - key Button key/- key 8. Wire definition Our company has defined the standard output wiring for the display according to conventional applications. - Page 18 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Table 1 Standard wire definition Color Function Orange(KP) Power lock control wire White(TX/CAN-H) Display data transmission wire Brown(VCC) Display power wire Green(RX/CAN-L) Display data reception wire Black(GND) Display ground wire ..
-
Page 19: C.package Specifications
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 C.Package specifications Standard delivery, in double corrugated box packaging. The inner layer is a double corrugated septum plus EPE foam product bag. Outer box size：615*400*210mm (L*W*H) D.Note In the use of the display, pay attention to the security, do not plug the display in and out when the power is on;...
