- Page 1 DM09 Display Functionality Introduction Product Name：Colored IPS Screen Display Product Model：DM 09 Signature Date Editor Liu Lei 2024.6.22 Checked Fang Chao 2024.6.25 Approved...
- Page 2 Revision History Version No Reviser Date Revision content V1.1 Liu Lei 2024.3.19 Initial version V1.2 Liu Lei 2024.6.22 1、Add CLASS 2、Add battery mode V1.3 Shouping Pan 2024.6.25 1、Modify some images and descriptions.
-
Page 3: Table Of Contents
Content A.Product Introduction ............................2 1.Product name and model ........................2 2. Product introduction ..........................2 3. Range of application ..........................2 4. Appearance and size ..........................3 5.display coding rules ..........................4 B. Product manual ...............................5 1. Specifications ............................5 2.Function overview ..........................5 3. - Page 4 While this document is a reference for complete function definitions, operation instructions, and error codes, any configuration difference between your display and the standard DM09 is possible, due to various technical requirements in different ebike applications. Please consult your drive system supplier for additional function requirements and data display.
-
Page 5: A.product Introduction
DM09 includes two versions of UART communication and CAN BUS communication DM09_U corresponds to UART communication version； DM09_C corresponds to CAN BUS communication version. All DM09 products are equipped with Bluetooth functionality in terms of hardware. 2. Product introduction High-brightness 1.45" IPS color LCD screen. -
Page 6: Appearance And Size
4. Appearance and size The shell material of DM09 is PC+ABS，the screen is made of high-hardness imported tempered glass, combined with 2.5D chamfering technology. This product is suitable for left-side installation on a φ22.2mm handlebar. 30.1mm 1.45" IPS 77.9mm color LCD screen 22.2mm... -
Page 7: Display Coding Rules
Parameter character value (wheel size value, 700C=70, 27.5=27) Parameter character value（speed limit information, range from 04 to 46） Parameter character value （voltage，24/36/43/48/52，can be expanded）） Customer software version number （may omit） Customer code Main software version number (*optional) Example： DM09-C01M020340001 A27.01-36V2570... -
Page 8: Product Manual
B. Product manual 1. Specifications ① Power supply：DC 24V/36V/48V/72V ② Rated current：40mA ③ Shutdown leakage current：<1uA ④ Screen specification：1.45" IPS color LCD screen. ⑤ Communication method：UART/ CAN-BUS ⑥ Operating temperature：-20°C ~ 60°C ⑦ Storage temperature：-20°C ~ 70°C ⑧ Waterproof level：IP65 ⑨... -
Page 9: Installation
⑫ Thumb throttle function 3. Installation ① Open the display lock clip, set the display in the left handlebar (standard handlebar size:Φ22.2).Adjust to a position easy to operate tighten and fix the screw by M3 hexagon. Tightening torque: 0.8N.m. *Note: Damage caused by excessive torque is not covered by the warranty. -
Page 10: Basic Interface And Operation
4.2 Basic interface and operation Power button M button Basic display interface Adjustment button Thumb throttle ① 4 buttons ：the power button、M button、 Adjustment button。 、 ② The standard cable exit method is straight out. ③ The screen uses a 1.45-inch high-brightness, high-definition IPS LCD, meeting the customization and modification needs of the startup interface and partial UI interfaces. -
Page 11: Function Interface Introduction
4.3 Function interface introduction Boot interface and basic function interface Battery information Headlight indicator Real-time speed display Supports dynamic effects customization at startup Trip mileage display Assist level Motor output power display auxiliary display Assist level display Startup logo interface Basic function interface Boot logo interface is displayed for 3 seconds after display is turned on. - Page 12 Function interfaceⅡ Interface II primarily displays the usage time statistics of different assist modes during the ride. The statistics are calculated by the instrument based on the actual riding conditions and displayed as percentages. The assist mode usage time statistics can be reset through a data clearing operation. Function interface Ⅲ...
- Page 13 Walk assist interface Long press to enter walk assist mode, interface shown as below： Error code interface When the display receives the error info returned by controller, it will show a detailed error code on interface, indicating relevant electrical system fault information. The error code will be displayed numerically in the speed display area.
-
Page 14: Button Definition
5.Button definition 5.1 Button name Power button/power Function switch key/mode Adjust button/up Adjust button/down Thumb throttle Power button: Turn on/off the display Adjust button: Adjust the assisting power level during riding and switch functions Long press the adjust buttons to perform specific function operation Thumb throttle: Provides assist output by moving the throttle Function switch button: Switches between function display interfaces and enters the parameter setting interface... -
Page 15: Basic Function Operation
6. Basic function operation 6.1Turn on/off the display To turn on, long press button until boot logo interface appears and shortly enters the basic interface. To turn off, long press button until display is turned off. If the rider does not perform any operation on the display within set shutdown time, while speed is 0, and current is less than 1A, then the display will be turned off automatically. -
Page 16: Light Control Function
The switching process of each interface, as shown below： 6.4 Light control function When the vehicle is equipped with a battery and powered on,long press button can turn on the headlight,a headlight icon on the top right corner of screen will appear indicating light-on status.The screen will display the normal function status, and the screen brightness will decrease.Long press button to manually turn the headlight off. -
Page 17: Battery Power Indicator And Assist Power Output
6.7 Battery power indicator and assist power output Battery power information is divided into battery bar indication and remaining percentage indication. When the battery power is normal, the screen will show the battery capacity changes accordingly. Before communication is established, the battery percentage is not displayed, and the power bar is full and blinks at 2Hz.After battery info is acquired, it will display the battery percentage (a white bar will represent 100%, and the segments will not display 100%). -
Page 18: Setting Function
Battery level Description 90% ≤ SOC Full battery level 5 70% ≤ SOC Level 4 50% ≤ SOC Level 3 Level 2 30% ≤ SOC 20% ≤SOC Level 1 Level 0 5% ≤ SOC 0% ≤ SOC < 5% Level 0 and icon blink at 1Hz 7.Setting function Display provides specific parameter setting functions. - Page 19 First level parameter setting interface, and the description of each parameter interface is as follow: Setting items Interface Description Setting data Remark Value=KM/H Default Value=KM/H KM/H—Metric Unit setting UNIT=Unit MPH—Imperial Value= LEVEL1 Back light Default Value= 3 level 60% Backlight BACKLIGHT= Value= LEVEL 2 Back light level setting...
- Page 20 Battery mode BATTERY TYPE MDDE1 Default Value= MODE2 MDDE1 Auto AUTO SLEEP Value=OFF,5-30 min Default Value=5min shutdown OFF means no auto time shutdown Power on Psword=Password Value= OFF and Default value：OFF Passward ON； setting When is ON, user is allowed to set 4-digit password DSPIFO=displa...
-
Page 21: Advanced Setting Functions
Reset to RESET factory data reset All parameters will be factory settings restored to factory settings values. 8. Advanced setting functions *Warning The advanced setting function is based on specific protocol content, allowing to modify and set the controller and system parameter through display side. This feature is only available to specific groups of people, such as bike manufacturers, dealers and other entities with professional technical capabilities. -
Page 22: Data Clearance
After the password is typed correctly, advanced setting is entered, divided into two-page contents. Short press to pick and select.The triangular cursor on the right indicates the selected item. 、 Advanced setting functions descriptions： Setting Interface Description Setting data Remark item Value=16、18、... -
Page 23: Error Information
After clearance, the subtotal mileage TRIP is 0, average speed, and max speed is 0. ODO information can’t be cleaned manually on the display, professional service tools are required. 10.Error information Display can warn bike faults. When faults are detected, error code will be shown on the interface and blink at 1Hz. -
Page 24: Wire Definition
"09" shown at speed failure of motor's phase wire Check motor "11" shown at speed failure of the motor's temperature sensor Check controller "12" shown at speed failure of the current sensor Check controller "13" shown at speed failure of the temperature of the battery Check battery Controller temperature is too high, and "14"... -
Page 25: C.package Specifications
Orange(VCC) White(TX) Black(GND) Green(RX) Purple(THR) Brown(KP) Table 1 Standard wire definition Color Function Orange(VCC) Power lock control wire White(TX) Data transmission wire of display Brown(KP) Power wire of display Green(RX) Data receiving wire of display Black(GND) GND of display Purple(THR) Throttle wire C.Package specifications Standard delivery, in double corrugated box packaging. -
Page 26: D.note
Outer box size：580*390*168mm (L*W*H) D.Note In the use of the display, pay attention to the security, do not plug the display in and out when the power is on; Try to avoid exposure in harsh environments like heavy rain, heavy snow, and strong sunlight; ...
