- Page 1 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.02 版本号 DM05C Display Functionality Introduction Product Name：Colored IPS Screen Display Product Model：DM 05C Editor Editor Editor 刘磊 2021.09.07 Checked Approved...
- Page 2 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Modification History Version No Reviser Date Revision content V1.01 刘磊 2021.09.07 Initial version 第2 页/共 31页...
- Page 3 Please consult your drive system supplier for additional function requirements and data display. If you have any questions about DM05C functional definition, please consult our sales or technical support team. Our company (VeloFox ®) reserves all the rights to interpret and explain DM05 functional definitions.
-
Page 4: Table Of Contents
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 catalogue A. Product Introduction ......................... 5 1Product name and model ......................5 2 Product introduction ......................... 5 3 Range of application ......................... 5 4 Appearance and size ......................... 5 5 Display coding rules ........................6 B. -
Page 5: Product Introduction
Suitable for all E-bikes that comply with EN15194 standard 4 Appearance and size The shell material of DM05C is PC+ABS，the screen is made of imported tempered glass with beveled edge. This product is suitable to be installed on a horizontal handlebar tube size ofφ22.2mm，... -
Page 6: Display Coding Rules
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 14.5 mm 61 mm Holder size ： φ 22.2mm ， φ 25.4mm，φ31.8mm 5 Display coding rules As shown in above picture: Production serial number Manufacture year and week number Manufacture factory code，M0, M1，M2, M3 Hardware version number，C-CAN, U-UART, last 2... -
Page 7: Product Manual
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Parameter character value（reserved） Parameter character value (wheel size value, 700C=70, 27.5=27) Parameter character value（speed limit information, range from 04 to 46） Parameter character value （voltage，24/36/43/48/52，can be expanded） Customer software version number（may omit）... -
Page 8: Installation
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 ② Customization of boot interface and UI ③ Unit: Km/Miles, Language: English/German ④ Display key riding data, speed, mileage, battery info, etc. ⑤ Statistical function for power assist mode ⑥ Walk assist function ⑦... -
Page 9: Interface
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 4 Interface 4.1Boot interface Boot logo interface is displayed for 2 seconds after the display is turned on. When the communication connection is established, display enters the main interface which shows information obtained from the controller. -
Page 10: Function Interface Introduction
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 ① All RM series buttons are compatible with DM02 series displays, the power-on button is located on the top side of the display. ② Standard Outlet is a board end connector, which is convenient for after-sales maintenance and replacement. - Page 11 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 TRIP value has 4 digits, including one digit after the decimal point. After 9999.9 KM is exceeded, the decimal point is not indicated, and a 5-digit mileage value is displayed directly, with a maximum value of 99999km.
- Page 12 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Function interface ——Assist Mode Usage Statistics Ⅲ The function interface mainly displays the usage time statistics of different power assist Ⅲ modes during the riding process. The statistical data is calculated by the meter according to the actual riding state and displayed as percentage data.
- Page 13 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Maintenance reminder interface The display can be set with regular maintenance reminders, and when reaches the set mileage value, display will notify the user through the maintenance reminders. After the maintenance reminder mileage is reached, display will show a notification interface every time being turned on to prompt the user to carry out daily vehicle maintenance.
- Page 14 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Setting interface Within 10s after turning on display, long press M button to enter the setting interface, short press 、 to switch between setting interfaces. Short press 、 to enter parameter picking state.
-
Page 15: 5Button Definition
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 5Button definition 5.1 Button name Adjust button Power button M button Power button: Turn on/off the display Adjust button: Adjust the assisting power level during riding and switch functions Long press the adjust buttons to perform specific function operation Mode button: Switch interface functions and enter into parameter setting interface 第15 页/共... -
Page 16: Definition Of Button Operation
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 5.2 Definition of button operation Operation Description Type Press the button and soon released, while the button is released,the function Short press activated accordingly Press the button and hold, when the hold time exceeds the setting time(generally Long press 2 seconds), the function activated accordingly. -
Page 17: Information Switch
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Short press 、 button to switch assist level. Switching level is not cycled, that is, after reaching level, short press button to return to off level. It’s the same when adjusting up. -
Page 18: Maintenance Reminder
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 intensity and controls the turning on/off of the lights. The icon on the top right corner of the basic interface indicates automatic lights-on state. When automatic lights-on/off function fails, long press... -
Page 19: Walk Assist Function
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 6.6 Walk assist function When speed is 0, long press button to enter walk assist mode, motor outputs power according to the set speed and control the actual walk speed, display shows the walk assist icon and the real- time speed. -
Page 20: Setting Function
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 余量百分比信息 电池条指示 说明 80% ≤ SOC Full battery level 5 Level 4 60% ≤ SOC < 80% 40% ≤ SOC < 60% Level 3 Level 2 20% ≤ SOC < 40% Level 1 10% ≤SOC <... - Page 21 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 button to switch between setting interfaces. In any setting interfaces, short press M button to enter parameter editing state, the blue mark indicates chosen parameter, and selected option or value will be indicated by a white font with a grey background.
- Page 22 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 MAINTENANC Fixed value Default= Maintenanc 5000km e reminder Default Value= Value= LEVEL1,backlig BACK LIGHT LEVEL 3 Backlight ht level 60% level setting Value= LEVEL 2 backlight level Value= LEVEL 3...
-
Page 23: Advanced Setting Functions
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Controller Controller read only According information info communicat ion protocol 8. Advanced setting functions *Warning The advanced setting function is based on specific protocol content, allowing to modify and set the controller and system parameter through display side. - Page 24 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 After the password is typed correctly, advanced setting is entered, divided into two-page contents. Short press to pick and select. 、 Advanced setting functions descriptions：： Setting Interface Description Setting data...
- Page 25 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Value= 5 to 46 Default Value= 25 Speed SpdLtd=Speed Step=1 limitation limitation setting PAS= Pedal Value= Dig-3: assistant Mode Dig-3； Digital 3 gear Pedal Dig-5； levels assistant ICON Dig-5： Mode...
- Page 26 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 slow Slow-ACC= slow Value= 0-3 Default：0 accelerati acceleration on setting assistance Value= 2-63 Default：2 started Pulse=assistance Step=1 pulse started pulse setting current CurLtd= current Value= 0-31.5A Default：12 limitation limitation Step=0.5A...
-
Page 27: Data Clearance
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 9. Data clearance Data clearance is aimed at the removal of data information such as subtotal mileage TRIP, average speed, and maximum speed. 10s after display is turned on when display is at function... -
Page 28: Wire Definition
11. Wire definition 11.1 Standard wires definition: The standard outlet of the display is defined by Velofox according to the conventional application, 第28 页/共 31页... -
Page 29: Standard Conversion Wire Specifications
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 and the standard outlet needs to match the corresponding conversion harness. Our company has corresponding standard settings for the conversion line length and interface standards. If the standard settings cannot meet your requirement, a customized conversion harness is required. -
Page 30: C Package Specifications
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 Adaptor-C2J: C Package specifications Standard delivery, in double corrugated box packaging. The inner layer is a double corrugated septum plus EPE foam product bag. Outer box size：580*390*168mm (L*W*H) 第30 页/共 31页... -
Page 31: D Note
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 1.01 版本号 D Note In the use of the display, pay attention to the security, do not plug the display in and out when the power is on； Try to avoid exposure in harsh environments like heavy rain, heavy snow, and strong sunlight ...
