- Page 1 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 DM08C Top Tube Embedded Display Functionality Introduction Product Name：Colored IPS Screen Display Product Model：DM08C Signature Date Editor Liu Lei 2024.9.03 Checked Approved 第 1 页 共 33 页...
-
Page 2: Revision History
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Revision History Version No Reviser Date Revision content V1.0 Liu Lei 2024.8.22 Initial version V1.1 Liu Lei 2024.10.18 1.Update product description (P5) 2.Add button selection recommendations (P26) 第 2 页 共 33 页... -
Page 3: Table Of Contents
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Content A.Product Introduction ............................4 1.Product name and model ........................4 2. Product introduction ..........................5 3. Range of application ..........................5 4. Appearance and size ..........................5 5.display coding rules ..........................7 B. Product manual ...............................8 1. -
Page 4: A.product Introduction
While this document is a reference for complete function definitions, operation instructions, and error codes, any configuration difference between your display and the standard DM08C is possible, due to various technical requirements in different ebike applications. Please consult your drive system supplier for additional function requirements and data display. -
Page 5: Product Introduction
Suitable for all E-bikes that comply with EN15194 standard 4. Appearance and size The shell material of DM08C is PC+ABS ， the screen is made of high-hardness imported tempered glass,The product is suitable for integration into top tube projects. 第 5 页 共 33 页... - Page 6 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 32.1mm M4*8 螺钉 第 6 页 共 33 页...
-
Page 7: Display Coding Rules
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 5.display coding rules As shown in above picture： Production serial number Manufacture year and week number Manufacture factory code，M0, M1，M2, M3 Hardware version number，C-CAN, U-UART, last 2 numbers are version Product model M0: Represents VeloFox self-made. -
Page 8: Product Manual
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 B. Product manual 1. Specifications ① Power supply：DC 24V/36V/48V/72V ② Rated current：40mA ③ Shutdown leakage current：<1uA ④ Screen specification：1.45" IPS color LCD screen. ⑤ Communication method：UART/ CAN-BUS ⑥ Operating temperature：-20°C ~ 60°C ⑦... -
Page 9: Interface
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 4 .Interface 4.1 Boot interface Boot logo interface is displayed for 3 seconds after the display is turned on. When the communication connection is established, display enters the main interface which shows information obtained from the controller. -
Page 10: Basic Interface And Operation
Adjustment button ① 2 buttons ：the power button、+/-Adjustment button. ② The standard cable exit method is straight out (optional to add any VeloFox RM protocol button). ③ The screen uses a 1.45-inch high-brightness, high-definition IPS LCD, meeting the customization and modification needs of the startup interface and partial UI interfaces. -
Page 11: Function Interface Introduction
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 4.3 Function interface introduction Boot interface and basic function interface Light on display Clock display Real-time speed display Supports dynamic effects customization at startup Trip distance display Battery information display Assist level display... - Page 12 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Other function interfaces Function interface I Interface I primarily displays speed information, including trip mileage, average speed, maximum speed, and total mileage, with the trip mileage (TRIP) being the same as on the main interface. The speed display value is a 3-digit number with one decimal place, with a maximum value of 99.9 KM/H.
- Page 13 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 controller does not provide the remaining range information, it will display ----. Functional Interface III Functional Interface III primarily displays the usage time statistics for different assist modes during riding. The statistical data is calculated by the display based on the actual riding state and is shown as a percentage.
- Page 14 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Functional Interface Ⅴ Function Interface V primarily displays the rider power and motor power ratio statistics, which requires support from the controller. Error code interface When the display receives the error info returned by controller, it will show a detailed error code on interface, indicating relevant electrical system fault information.
-
Page 15: Button Definition
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 5.Button definition 5.1 Button name Power button Power button Power button: Long press to turn on/off the display； Short press to toggle the light on and off. Adjust button:Short press to adjust the assist level (cycling through levels) and use the function switch key for setting operations. -
Page 16: Definition Of Button Operation
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 5.2 Definition of button operation Operation Description Type Press the button and soon released, while the button is released,the function Short press activated accordingly. Press the button and hold, when the hold time exceeds the setting Long press time(generally 2 seconds), the function activated accordingly. -
Page 17: Basic Function Operation
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 6. Basic function operation 6.1 Turn on/off the display To turn on, long press button until boot logo interface appears and shortly enters the basic interface. To turn off, long press button until display is turned off. -
Page 18: Light Control Function
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 automatically switch back to the Basic Interface. Function Display Screen I shows average speed, maximum speed, and total mileage for a single ride. Function Display Screen II shows remaining range, voltage, and remaining capacity. -
Page 19: Battery Power Indicator And Assist Power Output
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 6.6 Battery power indicator and assist power output When the battery level is normal, the battery percentage is displayed. Before establishing communication with the battery on startup, the percentage is not shown, and the battery level displays 100% with a 2Hz flash. - Page 20 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 technical support team for confirmation in case of any discrepancies. Within 10 seconds of powering on, long press the function key of the external button to enter the settings menu. When using external buttons, a combined long press of the “+” and “-” buttons will enter the settings menu.
- Page 21 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Default Value=KM/H Value=KM/H Unit KM/H—Metric Unit setting MPH—Imperial Factory setting can be Time writes the current Clock modified. time. Settings Value= 1,Back light level60% Value= 2Back Default Value= Backlight Backlight light level80%...
- Page 22 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Value= OFF and ON； Power on 参数值为 ON 的 Default Value： Passward Password 情况下，允许用 setting 户设定 4 位数密 码 Maintenance Default= Reminder MAINTENANCE Fixed value 5000km Settings According to Display Info...
- Page 23 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 According to Controller read only Controller Info communication info protocol Entering Advanced Refer to the Settings advanced *Advanced setting Advanced Set Secondary settings functions Parameter instructions for Configuration details. Interface All parameters...
-
Page 24: Advanced Setting Functions
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 8. Advanced setting functions *Warning The advanced setting function is based on specific protocol content, allowing to modify and set the controller and system parameter through display side. This feature is only available to specific groups of people, such as bike manufacturers, dealers and other entities with professional technical capabilities. - Page 25 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 After the password is typed correctly, advanced setting is entered, divided into two-page contents. Short press the +/- adjustment keys to pick and select.The triangular cursor on the right indicates the selected item.
- Page 26 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Dig-3: 3-Level Setting Value= Dig-5: 5-Level Assist Level Dig-3； Setting PAS lndicatin Mode Setting ICON: Dig-5； ICON English Version Levels Default value： Speed Step=1； Magnetic S-Sensor Pulse Value= 1--12 Motor Speed...
- Page 27 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Default value： Soft Start Slow-Starting Value= 0-3 Default value： Assist Magnetic Steel PAS pulse Value= 2-63 Step=1 Starting Pole Assist Start Number Magnet Count Default value： Current Step=0.5A Limiting Value Current Limit Value= 0-31.5A...
- Page 28 杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Default value： 31.5V Under-Voltage Step=0.5V Value= Protection Low Voltage Set Controller 10.0-52.0V Setting Undervoltage Protection Value 第 28 页 共 33 页...
-
Page 29: Data Clearance
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 9. Data clearance Data clearance is aimed at the removal of data information such as subtotal mileage TRIP, average speed, and maximum speed. After 10 seconds of normal startup, on the main page of the display, long press the +/- adjustment keys to enter the data clearing prompt status. -
Page 30: Error Information
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 10. Error information Display can warn bike faults. When faults are detected, error code will be shown on the interface and blink at 1Hz. When error code is shown, button functions will not be affected, meaning interfaces can be shown normally by pressing buttons. -
Page 31: Key Selection Recommendations
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 Check the install "21" shown at speed failure of the speed sensor position of the speed sensor "22" shown at speed Change battery Failure of BMS communication Check connector "30" shown at speed... -
Page 32: Wire Definition
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 12. Wire definition According to the system adaptation for the customer's actual vehicle model, the wiring status of the display is as shown in the figure below: Button wiring Display power wiring... -
Page 33: C.package Specifications
杭州威狐智能科技有限公司 文件编号 Hangzhou VeloFox Intelligent Technology Co,. Ltd. 版本号 C.Package specifications Standard delivery, in double corrugated box packaging. The inner layer is a double corrugated septum plus EPE foam product bag. Outer box size：580*390*168mm (L*W*H) D.Note In the use of the display, pay attention to the security, do not plug the display in and out when the power is on;...
