dejavoo Z9 Aura Quick Reference Manual

Quick Reference Guide |
Dejavoo Z9/Z11 Aura
Thank you for choosing Electronic
Payments
Electronic Payments only provides the fastest, most secure
payment terminals available. Installation is quick and easy.
Simply follow the instructions and begin processing credit card
transactions today!
Questions?
24/7 Technical Support (800) 966-5520 - Option 3
Merchant Support (800) 966-5520 - Option 4
Dejavoo Z9/Z11 Aura
Specifications
Printer
Camera & Scanner (Z9)
Security
Dimensions
Weight
What's in the box
• Credit Card Terminal
• 1m Power Cable
• AC/DC Power Adapter Block
• Privacy Shield
• USB Cable (Z9)
• USB Cable Extender (Z9)
• USB 5v Adapter (Z9)
• PSTN Dial Cable (Z11)
• Ethernet Cable (Z11)
• PIN Pad Cable (upon request)
• 2 Rolls of Receipt Paper
Wiring Diagram
58mm Thermal Printer Insert the power cable into
the 9V
5MP with auto-focus and
side of the bottom of the
flash, Supports 1D and 2D
terminal.
barcode quick scan, Zebra
barcode imager (Optional)
Insert the Ethernet cable into
LAN
the
PCI PTS 4.1
183 x 76 x 50 mm Insert the PSTN dial cable
into the
350 g
Receipt Paper Installation Instructions
Open the paper cover by
lifting the glossy black
paper latch on the top of the
terminal.
Drop the paper roll into the
paper tray. The thermal print
side of the paper will feed out
facing you.
Close the cover of the
terminal until you hear a
click, then tear off any excess
paper.
port on the right hand
port.
PHONE port.
