  • Page 1 AXOVIA MULTIPRO 3S io...
  • Page 2 AXOVIA MULTIPRO 3S io © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 3 Memorising the 3-button remote controls..........................50 9 Clearing the remote controls and all settings........................52 Clearing the memorised remote controls............................. 52 Clearing all settings ..................................52 10 Locking the programming buttons............................ 53 © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 4 11 Diagnostic and troubleshooting ............................54 11.1 Operating codes display.................................. 54 11.2 Programming codes display ................................55 11.3 Error and breakdown codes display .............................. 56 11.4 Memorised data ....................................56 12 Characteristics..................................58 © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 5 Any use made of this product outside the field of application described in this manual is prohibited (see “Field of applic- ation” section). The use of any accessory or component not recommended by Somfy is prohibited as this may place people at risk. Somfy cannot be held responsible for any damage resulting from non-compliance with the instructions in this guide.
  • Page 6 Illustration 1: Protection by safety distances [} 7]. No protection is required if the gate has hold-down control or if the danger zone is more than 2.5 m above the ground, or at any other permanent access level. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 7 Monitor the gate as it moves and keep people away from it until installation is complete. Do not use adhesive to mount the motorisation. WARNING Take care when using the manual unlocking device. Manual unlocking may result in uncontrolled movement of the gate. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 8 1.8 Regulations Somfy declares that, when used in accordance with these instructions, the product described in these instructions complies with the essential requirements of the applicable European directives, and in particular Machinery Directive 2006/42/EC and Radio Equipment Directive 2014/53/EU.
  • Page 9 This drive is designed to actuate a hinged gate with the following maximum dimensions: Maximum gate leaf dimensions Maximum width 2.5 m Maximum weight 300 kg Maximum full area 4 m² 2.2 Kit composition © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 10 Spare fuse (250V / 5A) Antenna Remote control* Removable terminal block Cable clamp Cable clamp screw Control box cover Control box cover screw * the contents may vary depending on the packs © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 11 Press 2 s = activate auto-programming Press 7 s = clear auto-programming and parameters Interrupts auto-programming Press 2 s = memorise radio control points Press 7 s = clear radio control points © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 12 AXOVIA MULTIPRO 3S io 2.4 Space requirements © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 13 If the gate has no reinforcements, fit some metal reinforcement plates (e.g.: 40x40 cm and 4 cm thick) for fastening to the gate leaves. Electric lock For a large gate leaf format (larger than 2 m) or in a windy area, Somfy recommends installing an electric lock. ©...
  • Page 14 AXOVIA MULTIPRO 3S io 3.2 Defining the dimensions 3.2.1 With the Fix&Go app The "Somfy Fix&Go" app helps you prepare for installing the portal, by giving you the best installation position for the motor. 3.2.2 With the dimensions table Gate opening angle Distance A between the hinge and the axis AM to be plotted Less than or equal to 90°...
  • Page 15 Fit the fastening bolts on the mounting plate, and then fully tighten them. Slide the spacers onto the bolts. Position and fasten the motor. Check that it is horizontal. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 16 Assemble the arms and position the gate leaf bracket without permanently assembling it with the fastening spindle. CAUTION Do not use any tool, to avoid damaging the rings. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 17 Place the gate in the closed position: the gate leaves must be pressed against the central closing stop. Unfold the arm towards the gate, positioning the two semi-arms as shown in the diagram. 3.4.2.1 Position of motor on the pillar in a windy area © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 18 In a windy area, it is necessary to ensure that dimension B is as large as possible (max. 350 mm). Dimension B < 200 mm CAUTION If dimension B is minimal, it is possible to shift the arm’s rotation axis using the bracket for narrow pillars (ref. 9014360). © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 19 è If the motor arm marking is located in the prohibited arm alignment zone, shift the closing stop one notch to return to the alignment zone subject to an impact force measurement. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 20 Once the setting is complete, permanently fasten the bracket using the central hole to prevent it from slipping over time. CAUTION Use all 3 fastening holes on the bracket to ensure that the arm is firmly held on the gate leaf throughout the product’s service life. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 21 Place the upper opening stop against the stop block (on the pillar mounting plate side). Lock the stops using the screw supplied. 3.4.7 Locking the motors Place the gate leaves in the intermediate position. Lock the motors. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 22 Assembly recommendations CAUTION The position of the arm must be identical to the diagram. The motor connections must be reversed in relation to the standard arm kits. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 23 The motor must be placed as close as possible to the edge of the pillar (dimension A = 0). 68 mm It must be checked that the obstacle detection complies with Annex A of standard EN 12 453. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 24 Fold the corners so that the bolt heads are locked Field of application Weight per gate leaf = max. 100 kg Length L in mm Medium motor arm + ball-joint arm Lock recommended © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 25 For a horizontal arm with the gate closed, the mounting plate must be installed 75 mm above axis AH. It must be checked that the obstacle detection complies with Annex A of standard EN 12 453. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 26 Fold the corners so that the bolt heads are locked Field of application Weight per gate leaf = max. 100 kg Length L in mm 1000 1200 1400 1600 1800 2000 2200 2400 2500 Lock obligatory © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 27 3.5.4 Special gate or pillar dimensions / Opening up to 120° Motor arm Gate arm Short Short 260 mm 420 mm Medium Medium 360 mm 620 mm Long Long 460 mm 820 mm © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 28 Lock recommended obligatory Assembly recommendations Length L Dimension B 90° Min. dim. Mounting plate position Installation dimension A is the same as in the standard kit (see Defining the dimensions [} 14]). © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 29 Fasten the control box using suitable screws for the bracket type. Check that the seal is correctly installed before closing the box. 3.7 Connecting the motors NOTICE Motor M1 actuates the gate leaf which opens first and closes last. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 30 The cable clamp supplied must be used. For all low-voltage cables, ensure that they can withstand traction of 100 N. Check that the conductors do not move when this traction is applied. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 31 Press the PROG button on the drive until the screen displays F0 (approx. 2 s). Press the outer left- and right-hand buttons on the remote control simultaneously until the indicator light flashes. Press the button on the remote control that will open the gate fully. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 32 In this mode, the radio controls work and the gate moves at reduced speed. CAUTION The “Awaiting configuration” mode must only be used when installing the motorisation. It is essential to perform an auto-pro- gramming procedure for normal use of the product. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 33 During auto-programming, if the gate is stationary, pressing SET will exit auto-programming mode. NOTICE Auto-programming mode can be accessed at any time, including when the auto-programming cycle has already been com- pleted and the display indicates “C1”. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 34 See the user booklet. 5.6 User training All users must be trained in how to safely use this motorised gate (standard use and unlocking principle) and in the mandatory periodic checks. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 35 220 - 230 V 50/60 Hz 24 Vdc Lamp 24V Cell SecCell Lock Sec. Prog Test 230Vac Batt. Flash 24V dc Ant. 1.5 mm² 0.75 mm² 1.5 mm² 1.5 mm² 0.75 mm² 0.75 mm² © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 36 Programmable (parameter P37) Common PEDESTRIAN/CLOSING control input Contact Core Antenna Braid 6.2 Description of the various peripherals 6.2.1 Photoelectric cells Operation without photoelectric cells Program P07=0 Bridge present between terminals 23 and 24. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 37 è An automatic operating test is carried out with each movement of the gate. è If the test is negative, the gate cannot be moved until the operating mode changes to dead-man operation (after 3 minutes). © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 38 è An automatic operating test is carried out with each movement of the gate. è If the test is negative, the gate cannot be moved until the operating mode changes to dead-man operation (after 3 minutes). © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 39 The auto-test is mandatory for connecting any active safety edge, to ensure that the installation is compliant with the stand- ards in force. NOTICE The safety edge is only active during closing. For a safety edge active when opening, use the programmable safety input and programme P10 = 1. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 40 6.2.7 Lock Does not work if the drive is being powered by a 9.6V bat- tery. c./Cell Lock Sec. Prog T © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 41 NOTICE Lamp ..Lighting output power: • either 5 fluocompact or LED lights • or 2 power supplies for low-voltage LEDs • or 1 halogen light, max. 500 W © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 42 Fixed display = selected value of the parameter Flashing display = selectable value of the parameter 7.2 Meaning of the different parameters NOTICE The value in bold is the default value of the parameter. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 43 Automatic closing time delay in complete operating mode Values 0 to 30 (value x 10 s = time delay value) 2: 20 s Comments If the selected value is 0, automatic closing is instantaneous. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 44 1: Safety device without auto-test. 2: The auto-test is run for every operating cycle via test output. 3: The auto-test is run for every operating cycle via cell power supply output power supply switch- ing. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 45 0 to 60 (value x 10 s = time delay value) 6: 60 s Comments If the value 0 is selected, the exterior lighting goes out as soon as the motorised product stops moving. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 46 Annex A of standard EN 12 453. If necessary, install a safety edge and check that compliance has been achieved. WARNING! Failure to follow this advice may result in serious injury, for example due to crushing by the motorised product. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 47 If the torque is too low, there may be untimely obstacle detection. If the torque is too high, the installation may not comply with the standard. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 48 Annex A of standard EN 12453. If necessary, install a safety edge and check that compliance has been achieved. WARNING! Failure to follow this advice may result in serious injury, for example due to crushing by the motorised product. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 49 Briefly press the button selected to control the function (complete opening, partial opening, lighting, auxiliary output). ð The motorisation screen displays "Add". Complete opening control Partial opening control Exterior lighting control © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 50 Press "PROG" at the back of the remote control. ð The motorisation screen displays "Add". 8.3.2 By copying a previously memorised remote control CAUTION This operation must be carried out close to the drive. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 51 Complete closing open or closed: partial Partial opening Complete opening Complete closing opening If the motorised product is moving: stop Aux 230 V Aux. output ON Aux. output OFF Integrated lighting © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 52 9.1 Clearing the memorised remote controls Press the PROG button until the screen displays rSt (approx. 7 sec.). 9.2 Clearing all settings Press the SET button until the screen displays H0 (approx. 7 sec.). © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 53 Failure to follow this advice may result in serious injury, for example due to crushing by the motorised product. Press the “SET”, “+” and “-” buttons simultaneously. The screen displays C.1. The programmes are locked. To access programming again, repeat the same procedure. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 54 9.6 V power supply Displayed during operation with 9.6 V battery. 24 V power supply Displayed during operation with 24 V battery or solar power supply of product is compatible. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 55 Awaiting programming of a radio control Pressing a button on the control point assigns this button to point to control the auxiliary output the auxiliary output control. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 56 1.2 A Hardware fault Hardware auto-tests unsatisfactory Issue a movement command. If the fault is still present, contact Somfy. Accessories power supply fault The accessories power supply has cut out Maximum accessories consumption = 1.2 following an overload (excessive con- sumption).
  • Page 57 Number of radio control points memorised on the auxiliary output control d0 to d9 Log of the last 10 faults (d0 most recent to d9 the oldest) The fault history is cleared by pressing OK for 7 sec. © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 58 Coupling speed when closing Programmable with 5 possible values Diagnostics Saving and consulting data: cycle counter, cycle counter with obstacle detection, number of radio channels memorised, log of last 10 faults recorded © Copyright 2023 SOMFY ACTIVITES SA. All rights reserved.
  • Page 59 SOMFY ACTIVITES SA 50 avenue du Nouveau Monde 74300 CLUSES FRANCE www.somfy.com 5174901A...
