HALF GATE
INSTALLATION
SJ12 E , SJ16 E, SJ20 E
ANSI/CSA,CE, AS
VERTICAL MAST
243005AAA
January 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SJ12 E and is the answer not in the manual?

Questions and answers

Related Manuals for Skyjack SJ12 E

Summary of Contents for Skyjack SJ12 E

  • Page 1 HALF GATE INSTALLATION SJ12 E , SJ16 E, SJ20 E ANSI/CSA,CE, AS VERTICAL MAST 243005AAA January 2022...
  • Page 2 This field kit applies to serial numbers: SJ12 E/SJ16 E/SJ20 E: A601 000 906 - A601 999 999 Please refer to the website (www.skyjack.com) for contact information, other serial numbers, the most recent technical manuals, and USB software. The original instructions are in English.
  • Page 3 It may also be used to alert against unsafe practices. IMPORTANT IMPORTANT indicates a procedure essential for safe operation and which, if not followed, may result in a malfunction or damage to the equipment. SJ12 E , SJ16 E, SJ20 E 243005AAA...
  • Page 4 Notes 243005AAA SJ12 E , SJ16 E, SJ20 E...

  • Page 5: Table Of Contents

    Check and Adjust the Hinge Tension ..........14 SJ12 E , SJ16 E, SJ20 E...

  • Page 6: Section 1 - Kit Components

    Section 1 – Kit Components 243005AAA SJ12 E , SJ16 E, SJ20 E...
  • Page 7 • NUT, Nylon Lock - 5/16"-18 Gr. 5 119945 • RIVET, Pop (1/8" x 0.390" - AL LG FLG HD O-END) 172646 • LABEL, Anchorage Harness 172632 • LABEL, Control Box Location SJ12 E , SJ16 E, SJ20 E 243005AAA...

  • Page 8: Section 2 - Before You Start

    Wooden spacers x 1 - 3 cm (1-3/16") Crush and pinch hazards. Take extra care when working tight spaces. If you do not obey, there is a risk of minor to moderate injury. 243005AAA SJ12 E , SJ16 E, SJ20 E...

  • Page 9: Section 3 - Procedures

    4. Remove and discard the carriage bolts and nuts 3. Remove and discard the hinges, self-tapping from the right-side railing. screws and the gate that is already equipped. 5. Remove and discard the railing. Saloon Gate SJ12 E , SJ16 E, SJ20 E 243005AAA...

  • Page 10: Prepare The Half Gate

    Make sure the hinges are on the side that will face the inside of the platform and the adjustment screw if facing the bottom. 5.25 cm (2-1/16") 9.84 cm (3-7/8") 3 mm (1/8") 243005AAA SJ12 E , SJ16 E, SJ20 E...

  • Page 11: Install The Half Gate

    2. Secure the right-side railing to the platform and rear railing using carriage bolts (127437 x 6) and nuts (103984 x 6). 5. Make sure the top of the half gate is at the same height as the middle railings. SJ12 E , SJ16 E, SJ20 E 243005AAA...
  • Page 12 9. Use self-tapping screws (112329 x 6) to secure 12. Insert the end caps (100702 x 2) into the side the hinges to the side railing. railing. 10. Remove the c-clamps and spacers. 243005AAA SJ12 E , SJ16 E, SJ20 E...
  • Page 13 15. Attach the caution tapes (119803 x 4) around the 17. Apply the anchorage harness label (172646) entrance rail pad and control box location label (172632) to the platform. 172646 172632 SJ12 E , SJ16 E, SJ20 E 243005AAA...

  • Page 14: Check And Adjust The Hinge Tension

    Hold the wrench in that position, and install the locking screw. Remove the wrench. 5. Adjust the tension on all hinges until the gate releases and latches from a 45° opening. 243005AAA SJ12 E , SJ16 E, SJ20 E...
  • Page 15 Notes SJ12 E , SJ16 E, SJ20 E 243005AAA...
  • Page 16 www.skyjack.com...
